Introduction
A1.
This is the 15th Monthly Environment Monitoring and Audit (EM&A) Report for
Remaining Phase Development of Kwu Tung North and Fanling North New Development
Areas (the Project) for the reporting period between 1 and 31 March 2026. This
report was prepared by Aurecon Hong Kong Limited (Aurecon) under Service
Contract No. NDO 05/2024 Remaining Phase Development of Kwu Tung North and
Fanling North New Development Areas - Environmental Team (hereinafter called
the Service Contract).
A2.
Since only construction works
were undertaken under Works Contract No. ND/2024/01, Works Contract No.
ND/2024/02, Works Contract No. ND/2024/03, Works Contract No. ND/2024/04, Works
Contract No. ND/2024/06 and Works Contract No. ND/2024/07 during the reporting
month, this report documents the findings of EM&A works at Works Contract
No. ND/2024/01, Works Contract No.
ND/2024/02, Works Contract No. ND/2024/03, Works Contract No. ND/2024/04, Works Contract No. ND/2024/06 and
Works Contract No. ND/2024/07 under the Project during the reporting period
only. No construction works occurred in the remaining contracts during the
reporting period for Works Contract ND/2024/05 and ND/2024/08.
A3.
This Project involves eight (8)
Environmental Permits (EPs) (i.e. EP-465/2013/A, EP-466/2013/A, EP-467/2013/A,
EP-468/2013/A, EP-470/2013/A, EP-471/2013/A, EP-472/2013/A and EP-476/2013).
Details of each EPs are summarised in Table A1.
Table A1 Works Contracts under
relevant Environmental Permits in the Reporting Month
|
Environmental Permit No.
|
Works Contracts
|
Title of Designated
Project
|
Designated Project (DP)
|
|
EP-465/2013/A
|
ND/2024/03
ND/2024/04
ND/2024/05
|
San Tin Highway and
Fanling Highway Kwu Tung Section Widening (Between San Tin Interchange and Po
Shek Wu Interchange)
|
DP1
|
|
EP-466/2013/A
|
ND/2024/03
ND/2024/05
|
Castle Peak Road Diversion
|
DP2
|
|
EP-467/2013/A
|
ND/2024/01
ND/2024/02
ND/2024/03
ND/2024/05
|
Kwu Tung North New
Development Area Road P1 and P2 and Associated New Kwu Tung Interchange and
Pak Shek Au Interchange Improvement
|
DP3
|
|
EP-468/2013/A
|
ND/2024/01
ND/2024/02
|
Kwu Tung North New
Development Area Road D1 to D5
|
DP4
|
|
EP-469/2013
|
-
|
Sewage Pumping Stations in
Kwu Tung North New Development Area
|
DP5
|
|
EP-470/2013/A
|
ND/2024/06
|
Utilization of Treated Sewage Effluent (TSE) from
Shek Wu Hui Sewage Treatment Works
|
DP7
|
|
EP-471/2013/A
|
ND/2024/04
|
Po Shek Wu Interchange Improvement
|
DP8
|
|
EP-472/2013/A
|
ND/2024/08
|
Fanling Bypass Western
Section
|
DP9
|
|
EP-473/2013/A
|
-
|
Fanling Bypass Eastern
Section
|
DP10
|
|
EP-474/2013
|
-
|
Shek Wu Hui Sewage Treatment
Works - Further Expansion at Fanling North New Development Area
|
DP11
|
|
EP-476/2013
|
ND/2024/07
ND/2024/08
|
Sewage Pumping Stations in
Fanling North New Development Area (FLNDA)
|
DP13
|
Key
Construction Works in the Reporting Period
A4.
Apart from the construction
works undertaken under Works Contract No. ND/2024/01 since 20 January 2025, construction
works under Works Contract No. ND/2024/07 commenced since 27 February 2025, construction
works under Works Contract No. ND/2024/06 commenced since 10 March 2025, construction
works under Works Contract No. ND/2024/04 commenced since 10 May 2025, construction
works under Works Contract No. ND/2024/03 commenced since 2 June 2025, construction
works under Works Contract No. ND/2024/02 has also been commenced since 9 February
2026. No construction works occurred in the remaining Works Contracts (i.e. Works
Contract ND/2024/05 and ND/2024/08) during the reporting period. The
commencement dates of each Works Contracts are summarized in Table A2.
Table
A2 Commencement Dates of Each Works Contracts
|
Works Contracts
|
Commencement Dates
|
|
ND/2024/01
|
20 January 2025
|
|
ND/2024/02
|
9 February 2026
|
|
ND/2024/03
|
2 June 2025
|
|
ND/2024/04
|
10 May 2025
|
|
ND/2024/05
|
Not Yet
Commenced
|
|
ND/2024/06
|
10 March 2025
|
|
ND/2024/07
|
27 February 2025
|
|
ND/2024/08
|
April 2026 (Tentative)
|
A5.
A summary of construction
activities undertaken during the reporting period is presented below:
Works
Contract No. ND/2024/01:
· All Site Resumption Area(s)
1.
Tree survey
2.
Site
Clearance
· Portion III (3), IV (4), V (5), VII (7) and XXXV
(35)
1.
Site
Formation
· Portion VI (6), XVIII
(18), XXXVIII (38)
1.
Site
Clearance
2.
Excavation
· Portion VIII (8)
1.
Site
Clearance &
Demolition
2.
Asbestos
Abatement Works
· Portion XI (11), XXIII (23)
1.
Formwork
Erection, Rebar Fixing, Concreting Works
· Portion XL (40)
1.
Retaining
Wall Construction
2.
Drainages
System Construction
3.
ELS
work
· Portion LIX (59)
1.
Treatment of
High Arsenic-Containing Soil (HAS)
· Portion XVII (17), XVII (18), XXI (21), XXXIV (34),
XXXV (35), XLI (41), XLII (42)
1.
Excavation
works
2.
Drainage Pipe Installation
· Portion XII (12), XV (15), XXV (25), XXVII (27), XXX (30), XXXI (31), XXXII (33), XLII (42) and XLIV (44), Portion LI
(51)
1.
Site
Clearance
· Portion XVI (16), XLII (42) and LIII (53)
1.
Site
Clearance & Demolition
n
n Works Contract No. ND/2024/02:
· Site clearance in Area B, D, L
· Site formation works in Area D
· Temporary storage fill bank in Kwu Tung Grass
Soccer Pitch
· Demolition works for Community Sports in Area J
· Asbestos survey in the resumed areas
Works
Contract No. ND/2024/03:
Fanling Highway
& Castle Peak Road area
· Pak Sau Road Po Lau Road
1.
Tree Works
· Po Lau Road Sheung Yue River
1.
Asbestos
Removal Works at Portion IX
2.
Box Culvert
Bay 37 Bay 42 ELS
3.
Tree Works
· TTA Stage 1 Works
1.
Tree Works
New Tsung Pak Long Road
·
Box culvert
Bay 10 to 12, 14 to 16 Drainage/Watermains
1.
Drainage,
Sewerage & Watermain with Backfilling at Box Culvert Bay 15 & 16
2.
Box Culvert
Bay 14 ELS
· Box culvert Bay 17 to 19 & Drainage/Watermains
1.
Box Culvert
Bay 17 to 19 ELS, Base Slab, Wall and Top Slab
2.
Box culvert
Bay 17 & 19 Base Slab
· Retaining Wall RW01
1.
Pre-drilling
· Retaining Wall RW05A
1.
RW05A ELS
· Kwu Tung Road Bridge
1.
Site
Clearance and Tree Works
2.
Site
formation and cutback the existing slope
3.
Predrilling
4.
Foundation
& Piling
·
Works Areas
WA1, WA2, WA3, WA4 & WA5
1.
Site
Formation at PMs Site Office
2.
Site
Clearance, haul road and Temporary Drainage
3.
Asbestos
removal
Fanling Highway Cross River
Bridge (along Sheung Yue River)
· Portion XI East Abutment & pier foundation
1.
Trial Pits
for UUs
2.
Piling Works
·
Road L3
Viaduct
1.
Piling Works
2.
Pile Cap
L3A-02
· Kwu Tung Interchange Foundation & Substructure
- Bridge B1 & C1
1.
Piling Works
· Widening of Existing Bridge No.N526
1.
Tree Works
2.
ELS
3.
Pre-drilling
n
n Works Contract No. ND/2024/04:
· Site Clearance
· Site Establishment
· Tree Felling
· Trial Pit
· Pre-drilling
· Ground Investigation
· Existing Sewage Diversion
· Demolition of Existing Structures
· Haul Road Construction
· Bored Piling
· ELS Construction
· Slope Works
· Sheet Piling
n
n Works Contract No. ND/2024/06:
· Portion A
1.
Excavation to +90 mPD of Portion A
2.
Forming Haul Road from Area C to Portion A
· Portion C, Portion D, Portion E and Portion F
1.
Trench and Watermains Laying Works
· Pit B and Pit C
1.
Excavation
n
Works Contract No. ND/2024/07:
· Area C
1.
Tree Felling
2.
Site Formation
· Area D and Area E
1.
Site Formation
2.
Asbestos Removal
· Area G
1.
Site Clearance
2.
Site Formation
3.
Asbestos Removal
· Area H, Area I and Area R
1.
Asbestos Removal
· Area J
1.
Road Construction
· Area K
1.
Sewerage (DN1350) Construction Road Construction, Site Clearance
· Area O
1.
New Shrine Construction
· Area P
1.
Site Formation
2.
Drainage Construction
· Area Q
1.
Temporary Road Construction
2.
Drainage Construction
3.
Tree Transplant (1st Pruning)
4.
Storm Pipe (DN1650) Construction
5.
Tree Felling
· Portion 1b
1.
Assembly Yard for Bridge Construction
2.
Storage Yard for Concrete Pipe
· Portion 3b
1.
Sewerage Construction
· Portion 6c
1.
Improvement of Junction
· Portion 9b
1.
Rebar Yard
· Footbridge FB-4 (North)
1.
Lift Tower Construction
2.
ABWF Works
· Footbridge FB-4 (South)
1.
Piling Works
2.
ABWF Works
· Footbridge FB-5
1.
Pier Head Construction
2.
Lift Tower Construction
3.
Sump Pit Construction
n
Works
Contract No. ND/2024/05 and ND/2024/08:
· No construction work during the reporting period.
Environmental
Monitoring and Audit Programme
A6.
The environmental monitoring
activities, including 1-hour Total Suspended Particulates (TSP) monitoring,
24-hour TSP monitoring, noise monitoring, ecological survey, 24-hour Respirable
Suspended Particulates (RSP) (Ambient Arsenic) monitoring for land contamination
and environmental site inspection, were undertaken by Environmental Team (ET)
under Service Contract No. NDO 04/2019 (i.e. First Phase ET Wellab) and under
Service Contract No. NDO 05/2024 (i.e. Remaining Phase ET - Aurecon) during the
reporting period in accordance with the approved Updated EM&A Manual. A
summary of the monitoring and audit activities during the reporting period is
presented in Table A3.
Table
A3 Summary of EM&A Activities in the Reporting Period
|
EM&A
Activities
|
Monitoring Station(s)
|
Works Contract(s)(5)
|
|
ND/2024/01
|
ND/2024/02
|
ND/2024/03
|
ND/2024/04
|
ND/2024/05
|
ND/2024/06
|
ND/2024/07
|
ND/2024/08
|
|
1-hour TSP Monitoring(1)
|
KTN-DMS1(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
KTN-DMS2(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
KTN-DMS3(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
KTN-DMS4(B)(2)(3)
|
3, 9, 13, 19, 25, 31 March 2026
|
N/A
|
3, 9, 13, 19, 25, 31 March 2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS1(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
4, 10, 16, 20, 26 March 2026
|
N/A
|
|
FLN-DMS2(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS3(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS4(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS5(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
3, 9, 13, 19, 25, 31 March 2026
|
N/A
|
|
FLN-DMS6(A)(2)(3)
|
N/A
|
N/A
|
5, 11, 17, 23, 28 March 2026(6)
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS7(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
24-hour TSP Monitoring(1)
|
KTN-DMS1(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
KTN-DMS2(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
KTN-DMS3(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
KTN-DMS4(B)(2)(3)
|
3, 9, 13, 19, 25, 31 March 2026
|
N/A
|
3, 9, 13, 19, 25, 31 March 2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS1(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
3, 9, 13, 19, 25, 31 March 2026
|
N/A
|
|
FLN-DMS2(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS3(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS4(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS5(A)(2)(3)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
3, 9, 13, 19, 25, 31 March 2026
|
N/A
|
|
FLN-DMS6(A)(2)(3)
|
N/A
|
N/A
|
5, 11, 17, 23, 28 March 2026(6)
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS7(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Noise Monitoring(1)
|
CP-KTN-NMS1(2)
|
5, 11, 17, 23 March 2026(6)
|
5, 11, 17, 23 March 2026(6)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-KTN-NMS2(2)
|
3, 9, 19, 25, 31 March 2026
|
3, 9, 19, 25, 31 March 2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-KTN-NMS3(2)
|
3, 9, 19, 25, 31 March 2026
|
3, 9, 19, 25, 31 March 2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-KTN-NMS4(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-KTN-NMS5(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
3, 9, 19, 25, 31 March 2026
|
N/A
|
N/A
|
|
CP-KTN-NMS6(2)
|
3, 9, 19, 25, 31 March 2026
|
3, 9, 19, 25, 31 March 2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-KTN-NMS7(2)
|
5, 11, 17, 23 March 2026(6)
|
5, 11, 17, 23 March 2026(6)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-FLN-NMS1(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
4, 10, 16, 26 March 2026
|
N/A
|
|
CP-FLN-NMS3(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-FLN-NMS4(A)(2)(3)
|
N/A
|
N/A
|
N/A
|
6, 12, 18, 24, 30 March 2026(6)
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-FLN-NMS5(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
6, 12, 18, 24, 30 March 2026(6)
|
N/A
|
|
CP-FLN-NMS6(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
6, 12, 18, 24, 30 March 2026(6)
|
N/A
|
|
Ecological Monitoring (4)
|
Monitoring of Measures to Minimise Disturbance to Water Birds on Ng
Tung River, Sheung Yue River, and Long Valley
|
Weekly Monitoring:
2, 5, 9, 11, 17, 20, 23, 24, 30, 31 March 2026 (Transect T1, T2, T3 and T5)
Additional Nighttime Monitoring at Long Valley:
17, 31
March 2026 (Transect T5)
|
Weekly Monitoring: 2, 3, 5, 9, 10, 11, 12, 17, 19, 20, 23, 24, 26, 30,
31 March 2026 (Transect T1, T2, T3, T4 and T5)
Additional Nighttime Monitoring at Long Valley:
17, 31
March 2026 (Transect T5)
|
Weekly Monitoring:
2, 5, 9, 11, 17, 20, 23, 24, 30, 31 March 2026 (Transect T1, T2, T3 and T5)
Additional Nighttime Monitoring at Long Valley:
17, 31
March 2026 (Transect T5)
|
Weekly Monitoring: 3, 5,
10, 12, 17, 19, 24, 26, 31 March 2026 (Transect T4)
|
N/A
|
Weekly Monitoring:
2, 5, 9, 11, 17, 20, 23, 24, 30, 31 March 2026 (Transect T1, T2, T3 and T5)
|
Weekly Monitoring: 2, 3, 5, 9, 10, 11, 12, 17,
19, 20, 23, 24, 26, 30, 31 March 2026 (Transect T1, T2, T3 and T4)
|
Weekly Monitoring: 2, 3, 5, 9, 10, 11, 12, 17,
19, 20, 23, 24, 26, 30, 31 March 2026 (Transect T1, T2, T3 and T4)
|
|
Monitoring of Measures to Minimise Impacts to Ma Tso Lung Stream and
Siu Hang San Tsuen Stream
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Monitoring of Measures to Minimise Impacts on Ecological Sensitive
Habitats from Disturbance and Pollution
|
Monthly Monitoring: 6 March 2026 (Transect T1)
|
Monthly Monitoring: 6 March 2026 (Transect T1 and T6)
|
Monthly Monitoring: 3 March 2026 (Transect T4)
|
N/A
|
N/A
|
Monthly Monitoring: 25 March 2026 (Transect T2)
|
Monthly Monitoring: 3 March 2026 (Transect T3)
|
Monthly Monitoring: 3 March 2026 (Transect T3)
|
|
24-hour RSP (Ambient Arsenic) Monitoring for Land
Contamination (1)
|
KTN-DMS-4A(2)(3)
|
3, 9, 13, 19, 25, 31 March 2026
|
N/A
|
3, 9, 13, 19, 25, 31 March 2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Water Quality Monitoring(1)
|
KTN-IS1
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
KTN-CS1
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-IS1
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-CS1
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Landfill Gas Monitoring
|
250m Landfill Consultation Zone of Ma Tso Lung
Landfill
|
N/A(7)
|
N/A(7)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Environmental Site Inspection
|
Site Area under Works Contract No. ND/2024/01
|
3, 10, 19, 27 March 2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Site Area under Works Contract No. ND/2024/02
|
N/A
|
3, 10, 19, 27 March 2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Site Area under Works Contract No. ND/2024/03
|
N/A
|
N/A
|
2, 9, 20, 25, 30 March 2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Site Area under Works Contract No. ND/2024/04
|
N/A
|
N/A
|
N/A
|
6, 13, 20, 24 March 2026
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Site Area under Works Contract No. ND/2024/06
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
2, 9, 16, 23, 30 March 2026
|
N/A
|
N/A
|
|
Site Area under Works Contract No. ND/2024/07
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
5, 12, 19, 26 March 2026
|
N/A
|
Remarks:
(1)
For 1-hour and 24-hour TSP & 24-hour RSP (Ambient Arsenic) monitoring, monitoring stations that are specifically
within the 500m buffer area projected from the site boundary of works
contract(s) will be considered being the representative monitoring stations for
the corresponding works contract(s) and the associated impact monitoring
exercises will be kicked off once the nearest works contracts have been
commenced and undertaken during the reporting period/month.
For Noise
Monitoring, monitoring stations that are specifically within the 300m buffer
area projected from the site boundary of works contract(s) will be considered
being the representative monitoring stations for the corresponding works
contract(s) and the associated impact monitoring exercises will be kicked off
once the nearest works contracts have been commenced and undertaken during the
reporting period/month.
(2)
New monitoring station IDs are presented. The
corresponding monitoring station IDs are as follows:
|
1-hour and 24-hour TSP / 24-hour RSP
(Ambient Arsenic)
KTN-DMS1 = DMS1
KTN-DMS2 = DMS2
KTN-DMS3 = DMS3
KTN-DMS4(A)/4(B) = DMS4
FLN-DMS1 = DMS7
FLN-DMS2 = DMS9
FLN-DMS3 = DMS11
FLN-DMS4 = DMS6
FLN-DMS5/5(A) = DMS8
FLN-DMS6(A) = DMS10
FLN-DMS7 = DMS5
|
Noise
CP-KTN-NMS1
= CP-NMS1
CP-KTN-NMS2 = CP-NMS2
CP-KTN-NMS3 = CP-NMS3
CP-KTN-NMS4 = CP-NMS5
CP-KTN-NMS5 = CP-NMS7
CP-KTN-NMS6 =N/A
CP-KTN-NMS7 = CP-NMS4
CP-FLN-NMS1 = CP-NMS10
CP-FLN-NMS3 = CP-NMS12
CP-FLN-NMS4(A) = CP-NMS6
CP-FLN-NMS5 = CP-NMS8
CP-FLN-NMS6 = CP-NMS9
|
(3) Alternative
monitoring stations to the corresponding original monitoring stations.
(4) The monitoring date for the reporting month
was conducted by the ET from the First Phase of KTN/FLN NDAs Project, except
Transect T4 for the ecological monitoring item Monitoring of
Measures to Minimise Disturbance to Water Birds on Ng Tung River, Sheung Yue
River, and Long Valley, and Transect T2 for the ecological monitoring item Monitoring
of Measures to Minimise Impacts on Ecological Sensitive Habitats from
Disturbance and Pollution. No
ecological monitoring was conducted for the Monitoring of Measures to Minimise
Impacts to Ma Tso Lung Stream and Siu Hang San Tsuen Stream for this reporting
month as this monitoring is only conducted during wet season (April October).
Detailed divisions of work between First Phase ET and Remaining Phase can be
referred to Section 6 and relevant appendix.
(5) N/A No relevant monitoring is required
according to the approved updated EM&A Manual.
(6) The monitoring date for the reporting month
was conducted by the ET from the Remaining Phase of KTN/FLN NDAs Project.
(7) As confirmed by the Supervisor Team, no ground disturbance works were
carried out in the work area within 250m Landfill Consultation Zone of Ma Tso
Lung Landfill including construction of the infrastructure, development works,
excavation works and works involve confined spaces. Routine gas monitoring
should be undertaken during groundwork construction and in all excavations.
Breaches
of Action Levels (AL) and Limit Levels (LL)
A7.
Summary of the environmental
exceedances of the reporting period is tabulated in Table A4.
Table A4 Summary of Exceedances in the
Reporting Period
|
Environmental
Monitoring
|
Parameter(s)
|
No. of Exceedances
|
Total No. of Exceedances
|
No. of Non-project
Related Exceedances
|
Total
No. of
Non-project Related Exceedances
|
No.
of Exceedances
Related
to the Project
|
Total
No. of Exceedances
Related
to the Project
|
|
AL
|
LL
|
AL
|
LL
|
AL
|
LL
|
|
Air Quality
|
1-hour TSP
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
|
24-hourTSP
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
|
24-hour RSP
(Ambient Arsenic)
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
|
Noise
|
Leq(30mins)
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
|
Ecological Monitoring
|
Avifauna
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
|
Non-aquatic fauna
|
2
|
1
|
3
|
2
|
1
|
3
|
0
|
0
|
0
|
Air Quality
A8.
No AL or LL
exceedance was recorded for air quality monitoring in the reporting period.
Noise
A9.
No AL or LL exceedance was recorded for
construction noise monitoring in the reporting period.
Ambient Arsenic
A10. No AL or LL exceedance was recorded for ambient arsenic monitoring in
the reporting period.
Ecological Monitoring
A11. 2 AL and 1 LL exceedances were recorded for the
monitoring of measures to minimise impacts on ecological sensitive habitats
from disturbance and pollution. All exceedances were deemed as non-project
related with potential influences by abiotic factors.
Built Heritage Monitoring (Vibration Monitoring)
A12. No exceedance of limits was recorded for vibration monitoring in the reporting period.
Complaint Log
A13.
Total of 2 complaints were received
during the reporting period.
A14. The first environmental complaint related to construction dust and
wastewater generated from FLN NDA constructions sites, particularly at Ma Sik
Road and Ma Tak Road on 16 March 2026 under works contract ND/2024/07. The
complaint was received by EPD on 16 March 2026 and referred to CEDD, IEC and ET
on 18 March 2026. The complaint case has been investigated by the Contractor
and ET, investigation was closed out on 2 April 2026. The investigation
findings indicate that the complaint was not project related.
A15. The second environmental complaint related to construction noise
generated from FLN NDA constructions sites during restricted hours,
particularly at Po Shek Wu Road near Tai Tau Leng Village Vehicular Access on
26 March 2026 under works contract ND/2024/04. The complaint was received via
1823 on 26 March 2026 and referred to CEDD. CEED referred the complaint to
Engineers Representative (ER) on 27 March 2026. The Contractor, IEC and ET received
the complaint from ER on 27 March 2026. The complaint case has been
investigated by the Contractor and ET, investigation was closed out on 10 April
2026. The investigation findings indicate no non-compliance on conditions
stipulated on the valid Construction Noise Permit (CNP).
A16. The details of the complaint and investigation result are shown in Appendix 12.1.
Notification of Summons
and Successful Prosecutions
A17. No notification of summons or successful prosecutions was received
in the reporting period.
Reporting Changes
A18. There was no change to be reported that may affect the on-going
EM&A programme.
Future Key Issues
A19. The major site activities for the next reporting period are
summarized below and shown in Appendix 1.1:
Works Contract No.
ND/2024/01:
· All Site Resumption Area(s)
1.
Tree survey
2.
Site Clearance
· Portion III (3), IV (4), V (5),
VII (7) and XXXV (35)
1.
Site Formation
· Portion VIII (8)
1.
Site Clearance & Demolition
· Portion XVIII (18), XXXVIII (38)
1.
Excavation works
2.
Construction of CHC Box Culvert
· Portion XI (11), XXIII (23)
1.
Erection of Substructure of Metropolis Community Liaison and Visitor
Centre
· Portion XL (40)
1.
Retaining
Wall Construction
2.
Drainages
System Construction
3.
ELS
work
· Portion LIX (59)
1.
Treatment of
High Arsenic-Containing Soil (HAS)
2.
Erection of
Shredding Facility
· Portion XVII (17), XVII (18), XXI (21), XXXIV (34),
XXXV (35), XLI (41), XLII (42)
1.
Excavation
Works
2.
Drainage Pipe
Installation
3.
ELS Works
· Portion XXV (25), XXVII (27), XXXIII (33), XLII
(42) and XLIV (44)
1. Site Clearance
2. Site Formation
3. Construction of Box Culvert
n
Works Contract No.
ND/2024/02:
1.
Site clearance in Area A, B, C, D, T, L
2.
Site formation works in Area D
3.
Temporary storage fill bank
in Kwu Tung Grass Soccer Pitch
4.
Demolition works for Community Sports in Area
J
5.
Asbestos Survey
6.
Ground Investigation Works
n
Works Contract No.
ND/2024/03:
Fanling Highway &
Castle Peak Road area
· Pak Sau Road Po Lau Road
1.
Relocation/Reprovision/Removal
of Existing TCSS, Fire Hydrant, Signage & Streetlighting
2.
Tree Works
· Po Lau Road Sheung Yue River
1.
Asbestos
Removal Works at Portion IX
2.
Box Culvert
Bay 37 Bay 42 ELS
· TTA Stage 1 Works
1. Tree Works
2. Removal or relocation of
directly impacted Shrine/historical building at HKT08 & KT72
3. Demolish of Central Divider
& Barrier along FL Highway E/B
New Tsung Pak Long Road
·
Box culvert
Bay 10 to 12, 14 to 16 Drainage/Watermains
1. Drainage, Sewerage &
Watermain with Backfilling at Box Culvert Bay 15 & 16
2. Box Culvert Bay 10-13
& 14 ELS
3. Removal of ELS and Temp
Road Diversion
· Box culvert Bay 17 to 19 & Drainage/Watermains
1.
Box Culvert
Bay 17 to 19 ELS, Base Slab, Wall and Top Slab
· TTA Stage 1B
1.
Box Culvert
Bay 3, 5 to 7, 7A ELS
2.
Box Culvert
Base Slab
· Retaining Wall RW05A
1.
RW05A ELS
2.
Base Slab and
Wall
· Kwu Tung Road Bridge
1.
Site
Clearance and Tree Works
2.
Site
formation and cutback the existing slope
3.
Foundation
& Piling
·
Works Areas
WA1, WA2, WA3, WA4 & WA5
1.
Site
Clearance and Site Formation at PMs Site Office
2.
Temporary
Drainage
3.
Asbestos
removal
Fanling Highway Cross River
Bridge (along Sheung Yue River)
· Portion XI East Abutment & pier foundation (No works at wet season between
1 Apr 2026 and 31 Oct 2026)
1.
Trial Pits
for UUs
2.
Piling Works
·
Road L3
Viaduct
1.
Piling Works
2.
Pile Cap
L3A-02
Kwu Tung Interchange
Foundation & Substructure
· Bridge B1 & C1
1.
Piling Works
2.
ELS
· Bridge B2 & C2
1.
Piling Work
· Footbridges No. 4 at TTA Stage 1
1.
Ground Investigation
2.
Underground Utilities Works
· Footbridges No. 5 at TTA Stage 2
1. Predrilling
· Widening of Existing Bridge No.N526
1.
Tree Works
2.
ELS
3.
Pilling
n
Works Contract No.
ND/2024/04:
1.
Site Clearance
2.
Site Establishment
3.
Tree Felling
4.
Trial Pit
5.
Predrilling
6.
Ground Investigation
7.
Existing Sewage Diversion
8.
Demolition of Existing Structures
9.
Haul Road Construction
10.Bored Piling
11.ELS Construction
12.Slope Works
13.Pier Cap Construction
14.Sheet Pilling
n
n Works Contract No. ND/2024/06:
· Portion A
1.
Excavation to +90 mPD of
Portion A
2. Forming Haul Road form Area C to Portion A
· Portion C, D, E
& F
1.
Trench
and Watermans Laying Works
· Area N
1.
Jacking Pit
Excavation
· Pre-boring of Pit B & C
n
Works Contract No. ND/2024/07:
1. Site Clearance
2. Site Formation
3. Ground Investigation
4. Pre-bored Socketed H Pile Construction
5. Bridge Construction
6. Bridge Deck Connection (Footbridge FB5)
7. Lift Tower Construction
8. Sump Pit Construction
9. ABWF Works
10.Drainage Construction
11.Improvement of Junction
12.Road Construction
13.Temporary Road Construction
14.Open Landscaping Works
15.Tree Felling & Transplantation
16.Asbestos Containing Materials Survey & Removal
17.Land Contamination (Environmental Ground Investigation)
18.Internal Movement, Importation & Exportation of C&D materials
19.Sewage Construction
20. Old Shrine Removal and New Shrine Construction
21. Storm pipe Construction
22. Box Culvert Construction
23.Temporary Drainage Diversion
24. Rebar Yard
25.Storage Yard for Concrete Pipe
n
Works Contract No. ND/2024/05
and ND/2024/08:
1. The construction work has not commenced in the
reporting month.
1
Introduction
1.1
Project Background
1.1.1 The
Kwu Tung North and Fanling North New Development Areas
(KTN and FLN NDAs) development are implemented in two phases, comprising First
Phase and Remaining Phase developments. The construction works for the
First Phase development commenced in December 2019. The construction works for
the Remaining Phase development (the Project), including
site clearance and formation, roads, drainage, sewerage and water supply
systems, commenced progressively from the January 2025.
1.1.2 The
Project is delivered under eight (8) Works Contracts as below.
·
Contract No. ND/2024/01: Site Formation and
Infrastructure Works (South);
· Contract
No. ND/2024/02: Site Formation and Infrastructure Works (North);
· Contract
No. ND/2024/03: Improvement Works of Fanling Highway (Kwu Tung Portion) and
Associated Works;
· Contract
No. ND/2024/04: Improvement Works of Tai Tau Leng Roundabout and Po Shek Wu
Road and Associated Works;
· Contract
No. ND/2024/05: Improvement Works of Fanling Highway (Pak Shek Au Portion) and
Associated Works;
· Contract
No. ND/2024/06: Fresh Water and Flushing Water Service Reservoirs and
Associated Works;
· Contract
No. ND/2024/07: Site Formation and Infrastructure Works (East); and
· Contract
No. ND/2024/08: Site Formation and Infrastructure Works (West).
1.1.3
The EIA Report (AEIAR-175/2013) for NENT NDA was
approved with conditions under EIAO in 2013. The Environmental Permits for
corresponding Designated Projects were also issued by DEP in November 2013.
Subsequent to the findings of preliminary design and P&E Review for
accommodating additional population in KTN and FLN NDAs, VEP were subsequently
applied for eight EPs under the Project (i.e. EP-465/2013/A, EP-466/2013/A,
EP-467/2013/A, EP-468/2013/A, EP-470/2013/A, EP-471/2013/A, EP-472/2013/A and
EP-476/2013).
1.1.4
Aurecon was commissioned by Civil
Engineering and Development Department (CEDD) to provide
EM&A services for the works contracts in relation to the Project pursuant
to the requirements as specified in relevant EPs, the EM&A Manual issued in
the EIA stage, the Updated EM&A Manual prepared for Contract No. NDO
14/2018 and the approved EIA Report for the Project to discharge the duties of
the ET for the Project.
1.1.5
This is the 15th Monthly EM&A Report
summarizing the findings of EM&A works at Works Contract No. ND/2024/01
under the Project with EP-467/2013/A and EP-468/2013/A, Works Contract No.
ND/2024/02 under the Project with EP-467/2013/A and EP-468/2013/A, Works
Contract No. ND/2024/03 under the Project with EP-465/2013/A, EP-466/2013/A and
EP-467/2023/A, Works Contract No. ND/2024/04 under the Project with
EP-465/2013/A and EP-471/2013/A, Works Contract No. ND/2024/06 under
Environmental Permit No. EP-470/2013/A and for Contract No. ND/2024/07 under
Environmental Permit No. EP-476/2013 during the reporting period from 1 to 31
March 2026. No construction works occur in the remaining contracts during the
reporting period for Contract No. ND/2024/05 and ND/2024/08.
Table
1.1 Parties Involved in Project Organization for all Works Contracts
|
|
Works Contract(s)
|
|
Parties
|
ND/2024/01
|
ND/2024/02
|
ND/2024/03
|
ND/2024/04
|
ND/2024/05
|
ND/2024/06
|
ND/2024/07
|
ND/2024/08
|
|
Project Proponent
|
CEDD
|
|
Supervisor / Engineers Representative (ER)
|
AECOM Asia Co. Ltd.
|
AECOM Asia Co.
Ltd.
|
AECOM Asia Co. Ltd
|
AECOM Asia Co. Ltd
|
AECOM Asia Co. Ltd
|
Binnies Hong Kong Limited
|
AtkinsRιalis
|
AtkinsRιalis
|
|
Contractor
|
Build King - Richwell Engineering Joint
Venture
|
Build King Richwell Civil Joint Venture
|
China State -
STEC Joint Venture
|
CW CRCC (ND202404) Joint Venture
|
Lanon Sinohydro Excel JV
|
Wo Hing-Tsun Yip Joint Venture
|
Build King Richwell Civil Joint Venture
|
Gammon - STEC Joint Venture
|
|
ET
|
Aurecon Hong Kong Limited
|
|
Independent Environmental Checker (IEC)
|
Mott MacDonald Hong Kong Limited
|
|
|
|
|
|
|
|
|
|
|
Works Contract No. ND/2024/01:
· All Site Resumption Area(s)
3.
Tree survey
4.
Site
Clearance
· Portion III (3), IV (4), V (5), VII (7) and XXXV
(35)
2.
Site
Formation
· Portion VI (6), XVIII (18), XXXVIII (38)
3.
Site
Clearance
4.
Excavation
· Portion VIII (8)
3.
Site
Clearance & Demolition
4.
Asbestos
Abatement Works
· Portion XI (11), XXIII (23)
2.
Formwork
Erection, Rebar Fixing, Concreting Works
· Portion XL (40)
4.
Retaining
Wall Construction
5.
Drainages
System Construction
6.
ELS
work
· Portion LIX (59)
2.
Treatment of
High Arsenic-Containing Soil (HAS)
· Portion XVII (17), XVII (18), XXI (21), XXXIV (34),
XXXV (35), XLI (41), XLII (42)
3.
Excavation
works
4.
Drainage Pipe Installation
· Portion XII (12), XV (15), XXV (25), XXVII (27), XXX (30), XXXI (31), XXXII (33), XLII (42) and XLIV (44), Portion LI
(51)
2.
Site
Clearance
· Portion XVI (16), XLII (42) and LIII (53)
2.
Site
Clearance & Demolition
n
n Works Contract No. ND/2024/02:
· Site clearance in Area B, D, L
· Site formation works in Area D
· Temporary storage fill bank in Kwu Tung Grass
Soccer Pitch
· Demolition works for Community Sports in Area J
· Asbestos survey in the resumed areas
Works Contract No.
ND/2024/03:
Fanling Highway
& Castle Peak Road area
· Pak Sau Road Po Lau Road
1.
Tree Works
· Po Lau Road Sheung Yue River
1.
Asbestos
Removal Works at Portion IX
2.
Box Culvert
Bay 37 Bay 42 ELS
3.
Tree Works
· TTA Stage 1 Works
1.
Tree Works
New Tsung Pak Long Road
·
Box culvert
Bay 10 to 12, 14 to 16 Drainage/Watermains
1.
Drainage,
Sewerage & Watermain with Backfilling at Box Culvert Bay 15 & 16
2.
Box Culvert
Bay 14 ELS
· Box culvert Bay 17 to 19 & Drainage/Watermains
1.
Box Culvert
Bay 17 to 19 ELS, Base Slab, Wall and Top Slab
2.
Box culvert
Bay 17 & 19 Base Slab
· Retaining Wall RW01
1.
Pre-drilling
· Retaining Wall RW05A
1.
RW05A ELS
· Kwu Tung Road Bridge
1.
Site
Clearance and Tree Works
2.
Site
formation and cutback the existing slope
3.
Predrilling
4.
Foundation
& Piling
·
Works Areas
WA1, WA2, WA3, WA4 & WA5
1.
Site
Formation at PMs Site Office
2.
Site
Clearance, haul road and Temporary Drainage
3.
Asbestos
removal
Fanling Highway Cross River
Bridge (along Sheung Yue River)
· Portion XI East Abutment & pier foundation
1.
Trial Pits
for UUs
2.
Piling Works
·
Road L3
Viaduct
1.
Piling Works
2.
Pile Cap
L3A-02
· Kwu Tung Interchange Foundation & Substructure
- Bridge B1 & C1
1.
Piling Works
· Widening of Existing Bridge No.N526
1.
Tree Works
2.
ELS
3.
Pre-drilling
n
n Works Contract No. ND/2024/04:
· Site Clearance
· Site Establishment
· Tree Felling
· Trial Pit
· Pre-drilling
· Ground Investigation
· Existing Sewage Diversion
· Demolition of Existing Structures
· Haul Road Construction
· Bored Piling
· ELS Construction
· Slope Works
· Sheet Piling
n
n Works Contract No. ND/2024/06:
· Portion A
1.
Excavation to +90 mPD of Portion A
2.
Forming Haul Road from Area C to Portion A
· Portion C, Portion D, Portion E and Portion F
1.
Trench and Watermains Laying Works
· Pit B and Pit C
1.
Excavation
n
Works Contract No.
ND/2024/07:
· Area C
1.
Tree Felling
2.
Site Formation
· Area D and Area E
1.
Site Formation
2.
Asbestos Removal
· Area G
1.
Site Clearance
2.
Site Formation
3.
Asbestos Removal
· Area H, Area I and Area R
1.
Asbestos Removal
· Area J
1.
Road Construction
· Area K
1.
Sewerage (DN1350) Construction Road Construction, Site Clearance
· Area O
1.
New Shrine Construction
· Area P
1.
Site Formation
2.
Drainage Construction
· Area Q
1.
Temporary Road Construction
2.
Drainage Construction
3.
Tree Transplant (1st Pruning)
4.
Storm Pipe (DN1650) Construction
5.
Tree Felling
· Portion 1b
1.
Assembly Yard for Bridge Construction
2.
Storage Yard for Concrete Pipe
· Portion 3b
1.
Sewerage Construction
· Portion 6c
1.
Improvement of Junction
· Portion 9b
1.
Rebar Yard
· Footbridge FB-4 (North)
1.
Lift Tower Construction
2.
ABWF Works
· Footbridge FB-4 (South)
1.
Piling Works
2.
ABWF Works
· Footbridge FB-5
1.
Pier Head Construction
2.
Lift Tower Construction
3.
Sump Pit Construction
n
Works Contract No.
ND/2024/05 and ND/2024/08:
· No construction work during the reporting period.
Table 1.2 Status of Environmental License,
Notifications and Permits for Works Contract No. ND/2024/01
|
Permit / License Name/No.
|
Valid Period
|
Status
|
|
From
|
To
|
|
Environmental Permit
|
|
EP-467/2013/A
|
27/01/2017
|
N/A
|
Valid
|
|
EP-468/2013/A
|
27/01/2017
|
N/A
|
Valid
|
|
Notification pursuant to Air Pollution Control (Construction
Dust) Regulation
|
|
10008709
|
02/09/2024
|
N/A
|
Valid
|
|
Billing Account for Disposal of Construction Waste
|
|
7052236
|
20/09/2024
|
N/A
|
Valid
|
|
Registration of Chemical Waste Producer
|
|
WPN: 5213-548-B2781-01
|
06/12/2024
|
N/A
|
Valid
|
|
Effluent Discharge License under Water Pollution Control
Ordinance
|
|
WT00045924-2024
|
15/01/2025
|
31/01/2030
|
Valid
|
|
WT00046627-2025
|
03/06/2025
|
30/06/2030
|
Valid
|
|
WT00046736-2025
|
10/06/2025
|
30/06/2030
|
Valid
|
|
WT00046982-2025
|
03/10/2025
|
31/10/2030
|
Valid
|
|
WT00047583-2025
|
19/01/2026
|
31/01/2031
|
Valid
|
|
WT00048070-2025
|
28/01/2026
|
31/01/2031
|
Valid
|
|
Construction Noise Permit (CNP)
|
|
|
|
|
GW-RN1540-25
|
26/12/2025
|
25/03/2026
|
Valid until 25/03/2026
|
|
GW-RN0390-26
|
26/03/2026
|
25/07/2026
|
Valid
|
|
GW-RN1593-25
|
04/01/2026
|
30/06/2026
|
Valid
|
|
GW-RN0041-26
|
16/01/2026
|
15/04/2026
|
Valid
|
|
GW-RN0254-26
|
27/02/2026
|
26/05/2026
|
Valid
|
|
GW-RN0166-26
|
08/02/2026
|
07/05/2026
|
Valid
|
Table
1.3 Status of Environmental License,
Notifications and Permits for Works Contract
No. ND/2024/02
|
Permit / License Name/No.
|
Valid Period
|
Status
|
|
From
|
To
|
|
Environmental Permit
|
|
EP-467/2013/A
|
27/01/2017
|
N/A
|
Valid
|
|
EP-468/2013/A
|
27/01/2017
|
N/A
|
Valid
|
|
Notification pursuant to Air Pollution Control (Construction
Dust) Regulation
|
|
10024940
|
23/12/2025
|
N/A
|
Valid
|
|
Billing Account for Disposal of Construction Waste
|
|
7057203
|
05/01/2026
|
N/A
|
Valid
|
|
Registration of Chemical Waste Producer
|
|
WPN:5213-545-B2803-01
|
11/02/2026
|
N/A
|
Valid
|
|
Effluent Discharge License under Water Pollution Control
Ordinance
|
|
WT00048304-2026
|
18/03/2026
|
31/03/2031
|
Valid
|
|
Application
Ref. No.10027555
|
Applied on 11/03/2026
|
TBC
|
Under application
|
|
Construction Noise Permit (CNP)
|
|
|
|
|
NIL
|
NIL
|
NIL
|
NIL
|
Table
1.4 Status of Environmental License,
Notifications and Permits for Works Contract
No. ND/2024/03
|
Permit / License Name/No.
|
Valid Period
|
Status
|
|
From
|
To
|
|
Environmental Permit
|
|
EP-465/2013/A
|
20/01/2017
|
N/A
|
Valid
|
|
EP-466/2013/A
|
18/08/2022
|
N/A
|
Valid
|
|
EP-467/2013/A
|
27/01/2017
|
N/A
|
Valid
|
|
Notification pursuant to Air Pollution Control (Construction
Dust) Regulation
|
|
10008101
|
15/08/2024
|
N/A
|
Valid
|
|
Billing Account for Disposal of Construction Waste
|
|
7052008
|
21/08/2024
|
N/A
|
Valid
|
|
Registration of Chemical Waste Producer
|
|
WPN:5213-548-C5047-01
|
22/01/2025
|
N/A
|
Valid
|
|
Effluent Discharge License under Water Pollution Control
Ordinance
|
|
WT00046044-2025
|
07/11/2025
|
28/02/2030
|
Valid
|
|
Construction Noise Permit (CNP)
|
|
|
|
|
GW-RN1496-25
|
19/12/2025
|
18/03/2026
|
Valid until 18/03/2026
|
|
GW-RN0243-26
|
19/03/2026
|
18/06/2026
|
Valid
|
Table
1.5 Status of Environmental License,
Notifications and Permits for Works Contract
No. ND/2024/04
|
Permit / License Name/No.
|
Valid Period
|
Status
|
|
From
|
To
|
|
Environmental Permit
|
|
EP-465/2013/A
|
20/01/2017
|
N/A
|
Valid
|
|
EP-471/2013/A
|
10/10/2022
|
N/A
|
Valid
|
|
Notification pursuant to Air Pollution Control (Construction
Dust) Regulation
|
|
10012919
|
06/01/2025
|
N/A
|
Valid
|
|
Billing Account for Disposal of Construction Waste
|
|
7053746
|
13/02/2025
|
N/A
|
Valid
|
|
Registration of Chemical Waste Producer
|
|
WPN:5213-626-C5043-01
|
28/01/2025
|
N/A
|
Valid
|
|
Effluent Discharge License under Water Pollution Control
Ordinance
|
|
WT00047165-2025
|
15/12/2025
|
31/08/2030
|
Valid
|
|
WT00048247-2026
|
18/03/2026
|
31/03/2031
|
Valid
|
|
Construction Noise Permit (CNP)
|
|
|
|
|
GW-RN1044-25
|
17/09/2025
|
16/03/2026
|
Valid until 16/03/2026
|
|
GW-RN1377-25
|
24/11/2025
|
23/03/2026
|
Valid until 23/03/2026
|
|
GW-RN1457-25
|
10/12/2025
|
09/03/2026
|
Valid
|
|
GW-RN0021-26
|
11/01/2026
|
31/03/2026
|
Valid until 31/03/2026
|
|
GW-RN1510-25
|
01/01/2026
|
30/04/2026
|
Valid
|
|
GW-RN0230-26
|
24/02/2026
|
31/05/2026
|
Valid
|
|
GW-RN0251-26
|
28/02/2026
|
27/05/2026
|
Valid
|
|
GW-RN0201-26
|
01/03/2026
|
31/05/2026
|
Valid
|
|
GW-RN0205-26
|
01/03/2026
|
31/05/2026
|
Valid
|
|
GW-RN0381-26
|
24/03/2026
|
23/07/2026
|
Valid
|
Table
1.6 Status of Environmental License,
Notifications and Permits for Works Contract
No. ND/2024/06
|
Permit / License Name/No.
|
Valid Period
|
Status
|
|
From
|
To
|
|
Environmental Permit
|
|
EP-470/2013/A
|
13/05/2022
|
N/A
|
Valid
|
|
Notification pursuant to Air Pollution Control (Construction
Dust) Regulation
|
|
10007695
|
06/08/2024
|
N/A
|
Valid
|
|
Billing Account for Disposal of Construction Waste
|
|
7051899
|
28/08/2024
|
N/A
|
Valid
|
|
Registration of Chemical Waste Producer
|
|
WPN:5213-624-W3824-01
|
04/09/2024
|
N/A
|
Valid
|
|
Effluent Discharge License under Water Pollution Control
Ordinance
|
|
WT00046560-2025
|
15/05/2025
|
31/05/2030
|
Valid
|
|
WT00046847-2025
|
11/07/2025
|
31/07/2030
|
Valid
|
|
WT00046588-2025
|
29/05/2025
|
31/05/2030
|
Valid
|
|
Construction Noise Permit (CNP)
|
|
|
|
|
GW-RN1439-25
|
29/12/2025
|
28/04/2026
|
Valid
|
Table
1.7 Status of Environmental License,
Notifications and Permits for Works Contract
No. ND/2024/07
|
Permit / License Name/No.
|
Valid Period
|
Status
|
|
From
|
To
|
|
Environmental Permit
|
|
EP-476/2013
|
21/11/2013
|
N/A
|
Valid
|
|
Notification pursuant to Air Pollution Control (Construction
Dust) Regulation
|
|
10007874
|
09/08/2024
|
N/A
|
Valid
|
|
Billing Account for Disposal of Construction Waste
|
|
7051974
|
20/08/2024
|
N/A
|
Valid
|
|
Registration of Chemical Waste Producer
|
|
WPN:5213-625-B2775-01
|
19/08/2024
|
N/A
|
Valid
|
|
Effluent Discharge License under Water Pollution Control
Ordinance
|
|
WT00045532-2024
|
10/12/2024
|
31/12/2029
|
Valid
|
|
WT00046059-2025
|
14/02/2025
|
28/02/2030
|
Valid
|
|
WT00046059-2025
|
17/06/2025
|
28/02/2030
|
Valid
|
|
WT00046342-2025
|
15/05/2025
|
31/05/2030
|
Valid
|
|
WT00046692-2025
|
29/05/2025
|
31/05/2030
|
Valid
|
|
WT00046655-2025
|
03/06/2025
|
30/06/2030
|
Valid
|
|
WT00046819-2025
|
31/07/2025
|
31/07/2030
|
Valid
|
|
WT00047343-2025
|
29/09/2025
|
30/09/2030
|
Valid
|
|
WT00047250-2025
|
12/11/2025
|
30/11/2030
|
Valid
|
|
Construction Noise Permit (CNP)
|
|
|
|
|
GW-RN1224-25
|
01/11/2025
|
30/04/2026
|
Valid
|
|
GW-RN1473-25
|
12/12/2025
|
31/05/2026
|
Valid
|
|
GW-RN1480-25
|
19/12/2025
|
18/03/2026
|
Valid
|
|
GW-RN0069-26
|
19/01/2026
|
18/06/2026
|
Valid
|
|
GW-RN0168-26
|
18/02/2026
|
17/06/2026
|
Valid
|
|
GW-RN0179-26
|
23/02/2026
|
22/08/2026
|
Valid
|
2.1.1 In accordance with the EM&A Manual, the approved
updated EM&A Manual for the First Phase, the ET shall carry out impact
monitoring during the construction phase of the Project. 1-hour and 24-hour TSP
to monitor the air quality for the Works Contacts.
2.1.2
Impact
1-hour TSP monitoring was conducted for at least three times every 6 days,
while the impact 24-hour TSP monitoring was conducted for at least once every 6
days at the designated air quality monitoring stations.
2.2.1
According to the EM&A Manual,
the approved updated EM&A Manual for the First Phase, the designated
locations for impact air quality monitoring in related to the work contracts in
the reporting period are listed in Table
2.1 and their locations are shown in Figure
2.1 and Figure 2.2.
Table
2.1 Summary of Impact Air Quality Monitoring Stations in related to the Works Contracts
in the Reporting Period
|
Monitoring
Station(s)
|
Works
Contract(s)
|
ASR
ID in EIA
|
Planned(3) or Existing
|
Monitoring
Location(s)
|
|
KTN-DMS1
|
ND/2024/01,
ND/2024/02,
ND/2024/03
|
KTN-19
|
Planned
|
Nursery Classes and Kindergarten; Post
Offices
|
|
KTN-DMS2
|
ND/2024/01,
ND/2024/02
|
KTN-90
|
Planned
|
Nursery Classes and Kindergarten (2 nos);
District Elderly Community Centre
|
|
KTN-DMS3
|
ND/2024/01,
ND/2024/02,
ND/2024/03
|
KTN-326
|
Planned
|
Village Resite
|
|
KTN-DMS4(B)(1)(2)
|
ND/2024/01,
ND/2024/03
|
KTN-E70
|
Existing
|
Temporary Structure at Pak Shek Au
|
|
FLN-DMS1
|
ND/2024/07
|
FLN-E62
|
Existing
|
Scattered Village Houses North of Proposed
Potential Ecopark
|
|
FLN-DMS2
|
ND/2024/06, ND/2024/07
|
FLN-E243
|
Planned
|
Residential Building, Nursery Classes and
Kindergartens, Neighbourhood Elderly Community Centre, Residential Home for
the Elderly, Post Office
|
|
FLN-DMS5, FLN-DMS5(A)
|
ND/2024/07
|
FLN-E124
|
Existing
|
Noble Hill / Good View New Village
|
|
FLN-DMS6(A)
|
ND/2024/03,
ND/2024/04
|
DMS-10
|
Existing
|
Choi Ngan House, Choi Po Court
|
|
FLN-DMS7
|
ND/2024/06, ND/2024/07
|
FLN-20
|
Planned
|
Planned premise for Weapon Training
Division
|
Remarks:
(1) KTN-DMS4(B) is the
alternative air monitoring stations proposed to replace KTN-DMS4.
(2) As KTN-DMS4 - Temporary structure near Fanling
Highway (near Pak Shek Au) is no longer as existing ASR, air quality monitoring
station should be relocated to the alternative dust monitoring location
according to the updated EM&A Manual, Section 2.6.2. According to Figure
3.1 of Approved EIA report and site visits conducted in June 2022, ASR at near
KTN-E70 Temporary Structure near Fanling Highway near Pak Shek Au is
considered as the most representative alternative station KTN-DMS4(B) for air
quality monitoring for KTN-DMS4 (i.e. KTN-E162).
(3) Impact monitoring will be
carried out when the planned sensitive receivers are commissioned.
2.3.1 In
accordance with the requirements for placement of equipment, as set out of the
EM&A Manual of the Project, the approved updated EM&A Manual for the
First Phase, the monitoring parameter, frequency and duration of impact air
quality monitoring are listed in Table 2.2.
Table
2.2 Parameters Measured in the Impact Air Quality Monitoring
|
Parameter(s)
|
Frequency(1)(2)
|
|
1-hour TSP
|
Three times / 6 days
|
|
24-hour TSP
|
Once / 6 days
|
Remarks:
(1) The air
quality monitoring (1-hour and 24-hour TSP) was conducted by First Phase ET
during the reporting period.
(2) The air
quality monitoring (1-hour and 24-hour TSP) was conducted by Remaining Phase ET
during the reporting period.
2.4.1 Direct reading dust meters and
High-Volume TSP Samplers were used for measuring the impact air quality
monitoring (i.e. 1-hour TSP and 24-hour TSP) during the reporting period in
accordance with the Service Contract No. NDO 04/2019 Monthly EM&A Report.
According to Section 2.4.5 of the EM&A Manual, the approved updated
EM&A Manual for First Phase ET, the proposed use of direct reading dust
meter was submitted to and agreed by the First Phase IEC. HVS for 24-hour TSP
monitoring will be adopted once secured supply of electricity become available
at FLN-DMS5(A) and KTN-DMS4(B).
2.4.2 Table 2.3 summarizes the equipment used in the air quality
monitoring programme. Copies of the calibration certificates for air quality
monitoring equipment are shown in Appendix 2.2.
Table 2.3 Air Quality Monitoring Equipment
|
Monitoring
Station(s)
|
Equipment
|
Model
|
Manufacturer
|
Quantity
|
|
KTN-DMS4(B)(1), FLN-DMS5(1),
FLN-DMS5(A)(1)
|
Dust Monitor
(1-hour and 24-hour TSP)
|
AEROCET-831
|
Met One
Instruments
|
9
|
|
FLN-DMS1(1)
|
Dust Monitor
(1-hour TSP)
|
|
HVS Sampler
(24-hour TSP)
|
TE-5170
|
Tisch
|
1
|
|
FLN-DMS6(A)(2)
|
Dust Monitor
(1-hour and 24-hour TSP)
|
LD-5R
|
Sibata
|
1
|
Remarks:
(1) The air
quality monitoring (1-hour and 24-hour TSP) was conducted by First Phase ET
during the reporting period.
(2) The air
quality monitoring (1-hour and 24-hour TSP) was conducted by Remaining Phase ET
during the reporting period.
2.5
Monitoring Methodology and QA/QC Procedure
2.5.1 Direct reading dust meter was
deployed for the air quality monitoring as shown in Table
2.3.
Instrumentation
(AEROCET-831)
2.5.2 The measuring procedures of the dust meters were in
accordance with the Manufacturers Instruction Manual as follows:
· Place the dust meter at least 1.3 meters above
ground;
· Press and hold the Power key momentarily to power
on the unit and make sure that the battery level was not flash or in low level;
· Allow the instrument to stand for about 3 second to
display the Sample Screen minutes;
· Press the START / STOP key to run the internal
vacuum pump for 1 minute and be ready to use;
· Use the select dial to select the PM range and
press the START / STOP key to start a measurement;
· Finally, push the START/STOP key to stop the
measurement after 24-hour sampling;
· Information such as sampling date, time, value and
site condition were recorded during the monitoring period; and
· All data
were recorded in the data logger for further data processing.
Maintenance/Calibration
2.5.3
The following maintenance/calibration
was required for the HVS:
· Check and calibrate the
meters by High Volume Sampler (HVS) to check the validity
and accuracy of the results measured by direct reading method at 2-month
intervals throughout all stages of the air quality monitoring.
Instrumentation
(TISCH Model: TE-5170 / TE-5170X)
2.5.4 The following guidelines were
adopted during the installation of HVS:
·
A horizontal
platform with appropriate support was provided to secure the samplers against
gusty wind. the dust meter at least 1.3 meters above ground;
·
No two samplers
were placed less than 2 metres apart.
·
The distance
between the sampler and an obstacle, such as buildings, was at least twice the
height that the obstacle protrudes above the sampler.
·
A minimum of 2
metres of separation from walls, parapets and penthouses was required for
rooftop samples.
·
A minimum of 2
metres separation from any supporting structure, measured horizontally was
required.
·
No furnaces or
incineration flues were nearby.
·
Airflow around
the sampler was unrestricted.
·
The sampler were
more than 20 metres from the drip line.
·
Any wire fence
and gate, to protect the sampler, should not cause any obstruction during
monitoring.
·
Permission and
access to monitoring stations have been obtained to set up the samplers.
·
A secured supply
of electricity was provided to operate the samplers.
Filters
Preparation
2.5.5 Wellab Limited (HOKLAS Registration No. HOKLAS083) is a
HOKLAS accredited laboratory and responsible for the preparation of 24-hour
conditioned and pre-weighed filter papers for the monitoring team.
2.5.6 All filters were equilibrated in the conditioning
environment for 24 hours before weighing. The conditioning environment
temperature was around 25°C and not variable by more than ±3°C; the relative
humidity (RH) was < 50% and not variable by more than ±5%. A convenient
working RH was 40%.
Operating/Analytical Procedures
2.5.7 Operating/analytical procedures for the air quality
monitoring were highlighted as follows:
·
Prior to the
commencement of dust sampling, the flow rate of the HVS was properly set
(between 1.1 m3 /min. and 1.4 m3 /min.) in accordance
with the manufacturer's instruction to within the range recommended in USEPA
Standard Title 40, CFR Part 50;
·
The power supply
was checked to ensure the sampler worked properly;
·
On sampling, the
sampler was operated for 5 minutes to establish thermal equilibrium before
placing any filter media at the designated air quality monitoring station;
·
The filter
holding frame was then removed by loosening the four nuts and carefully a
weighted and conditioned filter was centered with the stamped number upwards,
on a supporting screen;
·
The filter was
aligned on the screen so that the gasket formed an airtight seal on the outer
edges of the filter. The filter holding frame was then tightened to the filter
holder with swing bolts. The applied pressure should be sufficient to avoid air
leakage at the edges;
·
The shelter lid
was closed and secured with the aluminium strip;
·
The timer was
then programmed. Information was recorded on the record sheet, which included
the starting time, the weather condition and the filter number (the initial
weight of the filter paper can be found out by using the filter number);
·
After sampling,
the filter was removed and kept in a clean and tightly sealed plastic bag. The
filter paper was then returned to the HOKLAS accredited laboratory (Wellab
Ltd.) for reconditioning in the humidity-controlled chamber followed by
accurate weighting by an electronic balance with a readout down to 0.1mg. The
elapsed time was also recorded; and
·
Before weighing,
all filters were equilibrated in a conditioning environment for 24 hours. The
conditioning environment temperature should be between 25°C and 30°C and did
not vary by more than ±3°C; the RH should be < 50% and did not vary by more
than ±5%. A convenient working RH is 40%. Weighing results were returned for
further analysis of TSP concentrations collected by each filter
Maintenance/Calibration
2.5.8
The following maintenance/calibration
was required for the HVS:
· The high-volume motors
and their accessories were properly maintained. Appropriate maintenance such as
routine motor brushes replacement and electrical wiring checking were made to
ensure that the equipment and necessary power supply are in good working
conditions; and
· All HVS were calibrated
(five point calibration) using Calibration Kit prior to the commencement of
baseline monitoring and thereafter at bi-monthly intervals.
Instrumentation
(Sibata Model: LD-5R)
2.5.9 The measuring procedures of the dust meters were in
accordance with the Manufacturers Instruction Manual as follows:
· Placed the dust meters at
least 1.3m above ground
· Set POWER to ON and
make sure that the battery level not flashed or in low level;
· Pulled the air sampling
inlet cover up;
· Pushed the knob at
MEASURE position;
· Set time/mode setting to
[BG] by pushing the time setting switch. Then, started the background
measurement by pushing the start/stop switch once. It took 6 sec. to complete
the background measurement;
· Turned knob to SENSI. ADJ
position and pressed in;
· Pushed Start/Stop switch
once;
· Gently returned knob to
the MEASURE position;
· Pushed the time setting
switch to change the time setting display to [LOG] at the bottom left of the
liquid crystal display;
· Removed the cap and
started measurement; and
· Information such as
sampling date, time, count value and site condition were recorded during the
monitoring period.
Maintenance/Calibration
2.5.10
The following maintenance/calibration
was required for the direct reading dust meter:
· Direct reading dust meter
shall be used in determining 1-hour TSP and 24-hour TSP at air quality
monitoring points. The direct reading dust meters have been calibrated against
high volume samplers (HVSs) bi-monthly. A 2-day, three 3-hour measurement
results per day from direct reading dust meters were taken to compare with the
sampling results from the HVSs. The correlation between the direct reading dust
meters and the HVSs were then concluded. By accounting for the correlation
factor, the direct reading dust meters are considered to achieve comparable
results as that of the HVSs.
· The HVS used to calibrate
the direct dust monitor will need to be calibrated bi-monthly. Details of
maintenance and calibration for the HVS refers to Section 2.5.8.
Calibration for the air quality monitoring equipment is attached to the Appendix
2.2.
Table
2.4 Action and Limit Levels for 1-hour TSP Air
Quality Monitoring
|
Monitoring
Station
|
AL
(μg/m3)
|
LL
(μg/m3)
|
|
KTN-DMS4(B)
|
297
|
500
|
|
FLN-DMS1
|
303
|
500
|
|
FLN-DMS5
|
279
|
500
|
|
FLN-DMS6(A)
|
286
|
500
|
Table
2.5 Action and Limit Levels for 24-hour of TSP
Air Quality Monitoring
|
Monitoring
Station
|
AL
(μg/m3)
|
LL
(μg/m3)
|
|
KTN-DMS4(B)
|
192
|
260
|
|
FLN-DMS1
|
150
|
260
|
|
FLN-DMS5(A)
|
153
|
260
|
|
FLN-DMS6(A)
|
157
|
260
|
2.7.1 Air
quality monitoring was conducted as scheduled in the reporting period. The air quality monitoring schedule during the
reporting period is shown in the Appendix 2.1.
2.7.2 The
1-hour and 24-hour TSP air quality monitoring result in the reporting period
are summarized in Table 2.6 and 2.7. No Action or Limit levels exceedance was
recorded in the reporting period.
Details of the results and graphical presentation are shown in Appendix 2.2.
The
weather information during the reporting period is presented in Appendix 2.3.
Table
2.6 Summary Table of 1-hour TSP Monitoring Result during the Reporting Month
|
Monitoring
Station
|
Averaged
Measured Value (μg/m3)
|
Maximum
Measured
Value
(μg/m3)
|
Minimum
Measured Value (μg/m3)
|
Action
Level (μg/m3)
|
Limit
Level, (μg/m3)
|
|
KTN-DMS4(B)(1)
|
44
|
57
|
27
|
297
|
500
|
|
FLN-DMS1(1)
|
55
|
73
|
34
|
303
|
500
|
|
FLN-DMS5(1)
|
44
|
61
|
35
|
279
|
500
|
|
FLN-DMS6(A)(2)
|
66
|
78
|
51
|
286
|
500
|
Remarks:
(1) The air
quality monitoring (1-hour and 24-hour TSP) was conducted by First Phase ET
during the reporting period.
(2) The air
quality monitoring (1-hour and 24-hour TSP) was conducted by Remaining Phase ET
during the reporting period.
Table
2.7 Summary Table of 24-hour TSP Monitoring Result during the Reporting Month
|
Monitoring
Station
|
Averaged
Measured Value (μg/m3)
|
Maximum
Measured
Value
(μg/m3)
|
Minimum
Measured
Value (μg/m3)
|
Action
Level (μg/m3)
|
Limit
Level, (μg/m3)
|
|
KTN-DMS4(B)(1)
|
47
|
58
|
32
|
192
|
260
|
|
FLN-DMS1(1)
|
34
|
47
|
19
|
150
|
260
|
|
FLN-DMS5(A) (1)
|
58
|
72
|
35
|
153
|
260
|
|
FLN-DMS6(A)(2)
|
71
|
78
|
56
|
157
|
260
|
Remarks:
(1) The air
quality monitoring (1-hour and 24-hour TSP) was conducted by First Phase ET
during the reporting period.
(2) The air
quality monitoring (1-hour and 24-hour TSP) was conducted by Remaining Phase ET
during the reporting period.
2.7.3
According to the observation record from Monthly EM&A Report (March 2026) prepared under
Service Contract No. NDO 04/2019, the major dust source KTN-DMS4(B), FLN-DMS1,
FLN-DMS5 and FLN-DMS5(A) included excavator, concrete mixer truck, crane, road traffic, dump truck etc. For station conducted
by Remaining Phase ET, the major dust source for FLN-DMS6(A) is from road
traffic.
2.8
Event and Action Plan
2.8.1 Should
any non-compliance of the criteria occur, action in accordance with the Event
and Action Plan in Appendix 2.4 shall be followed.
Investigation of the exceedances of environmental quality performance limits
should be conducted, and the ET will immediately notify the IEC and EPD, as
appropriate. The notification should be
followed up with advice to the IEC and EPD on the results of the investigation,
proposed actions and success of the action taken, with any necessary follow-up
proposals.
3
Construction Noise Monitoring
3.1.1
In accordance with the approved
Updated EM&A Manual, the ET shall carry out impact monitoring during the
construction phase of the Project in terms of the
A-weighted equivalent continuous sound pressure level (Leq) to
monitor the construction noise arising from the construction activities. The
regular monitoring frequency for each monitoring station was on a weekly basis
and one set of measurements between 0700 and 1900 hours on normal weekdays
shall be conducted.
3.2.1 According
to the approved Updated EM&A Manual, the monitoring designated locations
for construction noise monitoring in related to the works contracts in the
reporting period are listed in Table 3.1
and shown in Figure 3.1 and Figure 3.2.
Table
3.1 Construction Noise Monitoring Stations near in related to the Works Contracts
in the Reporting period
|
Monitoring
Station(s)
|
Works Contract(s)
|
NSR
EIA ID(s)
|
Location(s)
|
Planned(2)
Or
Existing
|
Type
of Measurement
|
|
CP-KTN-NMS1
|
ND/2024/01,
ND/2024/02
|
CP-NMS1
|
Residential Building at Ma Tso Lung
|
Existing
|
Free-Field(1)
|
|
CP-KTN-NMS2
|
ND/2024/01,
ND/2024/02
|
CP-NMS2
|
Residential Building at Ma Tso Lung
|
Existing
|
Free-Field(1)
|
|
CP-KTN-NMS3
|
ND/2024/01,
|
CP-NMS3
|
Fung Kong Garden
|
Existing
|
|
CP-KTN-NMS4(3)
|
ND/2024/01,
ND/2024/02,
ND/2024/03
|
CP-NMS5
|
Primary School
|
Planned
|
|
CP-KTN-NMS5
|
ND/2024/06
|
CP-NMS7
|
N/A
|
Existing
|
Free-Field(1)
|
|
CP-KTN-NMS6
|
ND/2024/01,
ND/2024/02
|
N/A
|
Ho Sheung Heung, Hau Ku ShekAncestral Hall, Hung Shing Temple & Pai Fung Temple and Sin
Wai Nunnery
|
Existing
|
Faηade
|
|
CP-KTN-NMS7
|
ND/2024/01, ND/2024/02
|
CP-NMS4
|
Oi Lok Home
|
Existing
|
Free-Field(1)
|
|
CP-FLN-NMS4(A)(4)
|
ND/2024/04
|
CP-NMS6
|
Choi Ying House,
Choi Po Court
(Choi Yuen Estate)
|
Existing
|
Free-Field(1)
|
|
CP-FLN-NMS1
|
ND/2024/06, ND/2024/07
|
CP-NMS10
|
Belair Monte
|
Existing
|
Facade
|
|
CP-FLN-NMS3(3)
|
ND/2024/06,
ND/2024/07
|
CP-NMS12
|
Secondary School
|
Planned
|
Free-Field(1)
|
|
CP-FLN-NMS5
|
ND/2024/07
|
CP-NMS8
|
Man Kok Village
|
Existing
|
Free-Field(1)
|
|
CP-FLN-NMS6
|
ND/2024/07
|
CP-NMS9
|
Woodland Crest
|
Existing
|
Faηade
|
Remarks:
(1)
For Free
Field measurement, +3 dB(A) should be added to the measured results.
(2) Impact monitoring will be carried out when the
planned sensitive receivers are commissioned.
(3) As confirmed with Engineer Representative, the
planned school at CP-KTN-NMS4 and CP-FLN-NMS3 are not constructed yet. Thus, the impact noise monitoring will be
carried out at monitoring station CP-KTN-NMS4 and CP-FLN-NMS3 after the
construction and occupation of the planned school. No noise monitoring of the mentioned station
was carried out in this reporting period.
(4) Alternative
monitoring stations to the corresponding original monitoring stations.
3.3
Noise Monitoring Parameter, Frequency and Duration
3.3.1 Construction
noise level was measured by the ET and measured in terms of the A-weighted
equivalent continuous sound pressure level (Leq). Leq(30mins) used as the monitoring
parameter for the construction noise monitoring.
3.3.2 As
supplementary information for data auditing, statistical results such as L10
and L90 were also obtained for reference.
3.3.3 Table 3.2
summarizes the monitoring parameters, duration, and frequency of construction
noise monitoring.
Table
3.2 Construction Noise Monitoring Parameter, Frequency and Duration
|
Monitoring Station
|
Parameter
|
Frequency and Duration
|
|
CP-KTN-NMS1(2), CP-KTN-NMS2(1), CP-KTN-NMS3(1), CP-KTN-NMS5(1), CP-KTN-NMS6(1),CP-KTN-NMS7(2),CP-FLN-NMS1(1), CP-FLN-NMS4(A)(2), CP-FLN-NMS5(2), CP-FLN-NMS6(2)
|
Leq(30mins), L10 and
L90 (as six
consecutive Leq,5min readings)
|
Once every week throughout the construction phase
|
Remark:
(1) The noise
monitoring was conducted by First Phase ET during the reporting period.
(2) The noise
monitoring was conducted by Remaining Phase Environmental Team during the
reporting period.
3.4.1 As
referred to the technical memorandum issued under the Noise Control Ordinance
(NCO), sound level meters in compliance with the International Electrotechnical
Commission Publications 651: 1979 (Type 1) and 804: 1985 (Type 1)
specifications were used for carrying out the construction noise monitoring.
3.4.2 Noise
measurements were not made in fog, rain, wind with a steady speed exceeding 5
m/s or wind with gusts exceeding 10 m/s. The wind speed was checked with a
portable wind speed meter capable of measuring the wind speed in m/s.
3.4.3
Sufficient numbers of noise
measuring equipment and associated instrumentation were prepared by the ET. All
the equipment and associated instrumentation were clearly labelled.
3.4.4 The
monitoring procedures are as follows:
·
For faηade
measurement, the monitoring station was set at a point 1 m from the exterior of
the sensitive receivers building faηade and set at a position 1.2 m above the
ground. For free-field measurement, the monitoring station was set at a
position 1.2 m above the ground.
·
The battery
condition was checked to ensure good functioning of the meter.
·
Parameters such
as frequency weighting, the time weighting and the interval were set as
follows:
-
Frequency weighting: A
-
Time weighting: Fast
-
Interval: 30 minutes (Leq(30mins))
·
Prior to and
after each noise measurement, the meter was calibrated using an acoustic
calibrator for 94.0 dB at 1000 Hz. If
the difference in the calibration level before and after measurement is more
than 1.0 dB, the measurement was considered invalid and repeat of noise
measurement will be required after re-calibration or repair the equipment.
·
At the end of
the monitoring period, the values of Leq, L10 and L90
were recorded. In addition, noise
sources were recorded on a standard record sheet.
3.4.5 Table 3.3 summarizes the noise monitoring equipment used
during the reporting period. Copies of the calibration certificates for noise
monitoring are shown in Appendix 3.1
Table
3.3 Construction Noise Monitoring Equipment
|
Equipment
|
Manufacturer
|
Model
|
No. of Equipment
|
Serial
No.
|
|
Sound
Level Meter
|
NTi Audio(2)
|
XL2
|
1
|
A2A-17638-E0
|
|
XL3
|
2
|
A3A-01229-F0
A3A-01220-F0
|
|
BSWA(1)
|
BSWA 308
|
3
|
580006
580011
580013
|
|
Acoustic
Calibrator
|
RION(2)
|
NC-75
|
3
|
34724244
35124527
35124529
|
|
SVANTEK(1)
|
SV30A
|
3
|
24803
24791
24780
|
Remark:
(1)
The noise monitoring
equipment was used by First Phase ET during the reporting period.
(2)
The noise monitoring
equipment was used by Remaining Phase Environmental Team during the reporting
period.
3.5.1 Maintenance
and calibration procedures are as follows:
·
The microphone
head of the sound level meter and calibrator were regularly cleaned with a soft
cloth;
·
The sound level
meter and acoustic calibrator were calibrated annually; and
·
The accuracy of
the sound level meter was checked using an acoustic calibrator generating a
known sound pressure level at a known frequency immediately prior to and
following each noise measurement. Measurements were accepted as valid only if
the calibration level from before and after the noise measurement agree to
within 1.0 dB.
3.6.1 The
Action and Limit levels were established in accordance with the Updated
EM&A Manual. Table 3.4
presents the Action and Limit Levels for construction noise. Should
non-compliance of the criteria occur, action in accordance with the Event and
Action Plan presented in Appendix 3.2 shall be carried out.
Table
3.4 Action and Limit Levels for Construction Noise Monitoring
|
Time Period
|
Action
|
Limit Level
|
|
07:00 19:00 on normal weekdays
|
When one or more documented complaints are received
|
75
dB(A)
|
Remark:
(1)
Time period for
construction noise monitoring during normal construction working hour
(0700-1900 Monday to Saturday).
(2)
If
works are to be carried out during restricted hours, the conditions stipulated
in the Construction Noise Permit (CNP) issued by the Noise Control Authority
have to be followed.
(3)
70 dB(A) and 65 dB(A) for
schools during normal teaching periods and school examination periods,
respectively.
3.7.1 All noise monitoring was conducted as scheduled in
the reporting month. The noise monitoring schedule during the reporting period
is shown in the Appendix 2.1.
3.7.2 No
Action Level or Limit Level exceedance
was recorded in the reporting period.
Details of the results and graphical presentation are shown in Appendix 3.1. The construction noise
monitoring results are summarized in Table 3.5.
The major noise sources observed during impact noise monitoring are summarized
in Table 3.6.
Table
3.5 Summary of Construction Noise Monitoring Results during the Reporting Month
|
Works Contracts
|
Monitoring Stations
|
Noise Levels, Leq(30min), dB(A)
|
Baseline Levels, dB(A)
|
Limit Levels, dB(A)
|
|
ND/2024/01, ND/2024/02
|
CP-KTN-NMS1(1)(3)
|
48.6 52.9
|
65.7
|
75
|
|
CP-KTN-NMS2(1)(2)
|
51.2 64.6
|
58.6
|
|
CP-KTN-NMS3(1)(2)
|
52.0 54.6
|
51.6
|
|
CP-KTN-NMS6(2)
|
55.6 63.9
|
55.1
|
|
CP-KTN-NMS7(1)(3)
|
63.6 68.5
|
64.6
|
|
ND/2024/04
|
CP-FLN-NMS4(A)(1)(3)(4)
|
69.7 72.1
|
72.4
|
|
ND/2024/06
|
CP-KTN-NMS5(1)(2)
|
47.9 65.3
|
57.2
|
|
ND/2024/06, ND/2024/07
|
CP-FLN-NMS1(2)
|
61.5 69.0
|
69.9
|
|
ND/2024/07
|
CP-FLN-NMS5(1)(3)
|
63.6 67.4
|
69.5
|
|
CP-FLN-NMS6(3)
|
53.0 58.8
|
55.0
|
Remarks:
(1) For Free
Field measurement, +3 dB(A) was added to the measured results.
(2) The noise
monitoring was conducted by First Phase ET during the reporting period.
(3) The noise
monitoring was conducted by Remaining Phase Environmental Team during the
reporting period.
(4) Alternative
monitoring stations to the corresponding original monitoring stations.
Table 3.6
Summary of Observations at Noise Monitoring Stations
|
Works Contracts
|
Monitoring Stations
|
Location
|
Major Noise Sources
|
|
ND/2024/01, ND/2024/02
|
CP-KTN-NMS1
|
Residential Building at Ma Tso Lung
|
Household
noise (dog barking) from nearby village house
|
|
CP-KTN-NMS2
|
Residential
Building at Ma Tso Lung
|
Road
Traffic Noise
|
|
CP-KTN-NMS3
|
Fung Kong Garden
|
Road Traffic Noise
|
|
CP-KTN-NMS4
|
Primary School
|
N/A(1)
|
|
CP-KTN-NMS6
|
Ho Sheung Heung, Hau Ku Shek Ancestral Hall, Hung Shing Temple & Pai Fung Temple and Sin
Wai Nunnery
|
Road
Traffic Noise, Dump Truck, Excavator
|
|
CP-KTN-NMS7
|
Oi
Lok Home
|
Road
Traffic Noise
|
|
ND/2024/04
|
CP-FLN-NMS4(A)(2)
|
Choi Ying House,
Choi Po Court
(Choi Yuen Estate)
|
Road
Traffic Noise
|
|
ND/2024/06
|
CP-KTN-NMS5
|
N/A
|
Road
Traffic Noise, Excavator, Roller
|
|
ND/2024/06, ND/2024/07
|
CP-FLN-NMS1
|
Belair Monte
|
Road
Traffic Noise, Excavator, Dump Truck
|
|
CP-FLN-NMS3
|
Secondary School
|
N/A(1)
|
|
ND/2024/07
|
CP-FLN-NMS5
|
Man Kok Village
|
Road
Traffic Noise
|
|
CP-FLN-NMS6
|
Woodland Crest
|
No
construction activity and other noise source was observed
|
Remarks:
(1)
No
impact noise monitoring was carried out at the monitoring station. Thus, not
applicable (N/A).
(2) Alternative
monitoring stations to the corresponding original monitoring stations.
3.7.3 One
noise related complaint was received during the reporting period. The details
of the complaint and investigation result are shown in Appendix 12.1.
4.1.1 In accordance with the approved Updated EM&A
Manual and EM&A Manual, impact water quality monitoring shall be carried
out three days per week at all the designated monitoring stations during the
construction of channel. The measurement periods are specified in Table 4.1. The interval between two
sets of monitoring shall not be less than 36 hours.
Table 4.1 Summary of Water Quality
Monitoring Locations
|
New
Monitoring Station(s)
|
Original
Monitoring Station ID(s)
|
Description
|
Location(s)
|
Measurement
Period
|
|
KTN NDA
|
|
KTN-CS1
|
CS1
|
Control Station for KTN NDA
|
Centreline of river, upstream of the
channel
|
During construction of channel
|
|
KTN-IS1
|
IS1
|
Impact Station
for KTN NDA
|
Centreline of river, downstream of
the channel
|
During construction of channel
|
|
FLN NDA
|
|
FLN-CS1
|
CS2
|
Control Station for FLN NDA
|
Centreline of river, upstream of the
channel
|
During construction of channel
|
|
FLN-IS1
|
IS2
|
Impact Station
for FLN NDA
|
Centreline of river, downstream of
the channel
|
During construction of channel
|
4.2.1 No construction of channelisation work between
KTN-CS1, KTN-IS1, FLN-CS1 and FLN-IS1 were undertaken during the reporting
period. Therefore, no water quality monitoring was carried out.
6
Ecology
6.1.1 This
section was derived from the ecological monitoring conducted during the
construction phase by the Remaining Phase ET, supplemented with findings
retrieved from the First Phase ET under Service Contract No. NDO 04/2019
Environmental Team for Environmental Monitoring and Audit Works in Construction
Phase for the First Phase Development of Kwu Tung North and Fanling North New
Development Areas. This approach was undertaken to prevent redundancy in survey
efforts.
Weekly Site Inspection
6.2.1 Weekly site inspections by the ET from the First
Phase of the KTN/FLN NDAs Project for ecological mitigation measures are
conducted as part of the overall weekly environmental site inspections. These
inspections audit the ecological mitigation measures implemented within the
active works area to ensure that the activities do not significantly impact the
ecologically sensitive receivers in the active works areas.
Monitoring of Measures to Minimise Disturbance to Water Birds in Ng
Tung River, Sheung Yue River, Shek Sheung River and Long Valley
6.2.2 As stipulated in Section 12.3.2.5 of the Updated
EM&A Manual, if development under the NDAs project occurs within 200m of
Sheung Yue River, Ng Tung River, Shek Sheung River and Long Valley, weekly
transect monitoring at high and low tides (above/below 1.5m at Tsim Bei Tsui
Station) should be conducted. The monitoring aims to identify and count bird
species in the river channels and Long Valley Nature Park (LVNP) and detect any
disturbances from construction activities, following the methodology in Table
12.1 of the Updated EM&A Manual. Monitoring in Long Valley should follow
the Hong Kong Bird Watching Society (HKBWS) bird monitoring programme's
methodology for comparable and comprehensive results.
Monitoring of Measures to Minimise Impacts to Ma Tso Lung Stream and
Siu Hang San Tsuen Stream, and Long Valley
6.2.3 As stipulated in Section 12.3.2.14 of the Updated
EM&A Manual, aquatic fauna monitoring should be conducted monthly during
the wet season (April October) of the construction phase.
Monitoring of Measures to Minimise Impacts on Ecological Sensitive
Habitats from Disturbance and Pollution
6.2.4 As stipulated in Section 12.3.2.17 of the Updated
EM&A Manual, measures to minimize impacts should be monitored during the
construction phase. The purpose of these surveys is to assess the effectiveness
of measures aimed at reducing disturbances and pollution in ecologically
sensitive habitats through standard fauna transect surveys.
6.2.5 For this reporting month, only transects that are
relevant to the active works of Works Contract ND/2024/01, Contract No.
ND/2024/02, Contract No. ND/2024/03, Contract No. ND/2024/04, Contract No.
ND/2024/06, Contract No. ND/2024/07 and Contract No. ND/2024/08, were included.
The active works for the mentioned contracts are described in Section 1.3.1 of
this report and shown in Figure 1.1 and Figure 1.2.
6.2.6 Table 6.1 summarizes the relevant transects and monitoring
station to each contract under the remaining phase, categorised under the
column First Phase ET and Remaining Phase ET according to the current
survey efforts. The locations of these contracts relative to the monitoring
locations are shown in Figure 6.1 and Figure 6.2.
Table 6.1 Summary of Monitoring Activities,
Relevant Contracts, and Corresponding Transects
|
Monitoring Activity
|
Relevant
Works Contract(s)
|
Relevant
Transect(s)/Monitoring Station(s)
|
|
First
Phase ET
|
Remaining
Phase ET
|
|
Monitoring of Measures to
Minimise Disturbance to Water Birds on Ng Tung, Sheung Yue, and Shek Sheung
Rivers and Long Valley
|
ND/2024/01*
|
T1, T2, T3, T5
|
-
|
|
ND/2024/02*
|
T1, T2, T3, T5
|
T4
|
|
ND/2024/03*
|
T1, T2, T3, T5
|
-
|
|
ND/2024/04*
|
-
|
T4
|
|
ND/2024/05
|
N/A(1)
|
N/A(1)
|
|
ND/2024/06*
|
T1, T2, T3
|
-
|
|
ND/2024/07*
|
T1, T2, T3
|
T4
|
|
ND/2024/08*
|
T1, T2, T3
|
T4
|
|
Monitoring of
Measures to Minimise Impacts to Ma Tso Lung Stream and Siu Hang San Tsuen
Stream, and Long Valley
|
ND/2024/01*^
|
MS_01,
MS_02, MS_03, MS_04, MS_05, MS_06,
MS_07, MS_08, MS_09, MS_10
|
-
|
|
ND/2024/02*^
|
MS_01,
MS_02, MS_03, MS_04, MS_05, MS_06,
MS_07, MS_08, MS_09, MS_10
|
-
|
|
ND/2024/03*
|
N/A(2)
|
N/A(2)
|
|
ND/2024/04*
|
N/A(2)
|
N/A(2)
|
|
ND/2024/05
|
N/A(2)
|
N/A(2)
|
|
ND/2024/06*
|
N/A(2)
|
N/A(2)
|
|
ND/2024/07*^
|
MS_11,
MS_12, MS_13, MS_14, MS_15
|
-
|
|
ND/2024/08*^
|
MS_11,
MS_12, MS_13, MS_14, MS_15
|
N/A(2)
|
|
|
|
|
|
|
Monitoring
of Measures to Minimise Impacts on Ecological Sensitive Habitats from
Disturbance and Pollution
|
ND/2024/01*
|
T1
|
-
|
|
ND/2024/02*
|
T1, T6
|
-
|
|
ND/2024/03*
|
T4
|
-
|
|
ND/2024/04*
|
N/A(3)
|
N/A(3)
|
|
ND/2024/05
|
T4, T6
|
-
|
|
ND/2024/06*
|
-
|
T2
|
|
ND/2024/07*
|
T3
|
-
|
|
ND/2024/08*
|
T3
|
-
|
Remarks:
(1)
Contracts that are located relatively far from
river channels.
(2)
Contracts that are located relatively far from Ma
Tso Lung and Siu Hang San Tsuen streams.
(3)
Contracts that are located relatively far from the
Ecological Sensitive Habitats as identified in the EIA.
(4)
* = active works contracts (ND/2024/01, ND/2024/02,
ND/2024/03, ND/2024/04, ND/2024/06, ND/2024/07 and ND/2024/08); ^ = monitoring
only in April October.
6.2.7 The details of the relevant
monitoring activities are discussed in the succeeding sections.
Monitoring of Measures to Minimise Disturbance to Water Birds in Ng
Tung River, Sheung Yue River, Shek Sheung River and Long Valley
Monitoring Methodology
6.3.1 Birds identified by their calls but not visually
located were recorded as "heard", while those observed flying over
the survey area were noted as "in flight." Species of conservation
importance were also specified. Additional information at the time of the
survey, such as weather conditions, tidal conditions, tide levels, and
noticeable natural or anthropogenic activities, were documented. For the
avifauna survey, ornithological nomenclature referenced The Avifauna of Hong Kong (Carey
et al., 2001), The Birds of Hong
Kong and South China (Viney et al., 2005), and the most recent
updated lists from other sources (e.g., Hong Kong Bird Watching Society).
Monitoring
Parameters
6.3.2 The monitoring parameters are as follows:
·
Abundance of
birds;
·
Types of
habitats utilized by birds; and
·
Notable bird
behaviours such as roosting, feeding, nesting and presence of juveniles.
Monitoring Location
6.3.3 For this reporting month, First Phase ET conducted
avifauna monitoring at Ng Tung River, Sheung Yue River, and Long Valley, while
the Remaining Phase ET conducted avifauna monitoring at Shek Sheung River.
Relevant transect routes are summarized in Table 6.2 and illustrated in Figure 6.1 and Figure 6.2. As the sensitive
receivers are large waterbirds and are easily visible, the transect routes only
needed to follow one riverbank.
Table 6.2 Summary of Active Works Contracts
and Corresponding Transects
|
Monitoring
Transect(s)
|
Relevant
Works Contract(s)
|
|
ND/2024/01
|
ND/2024/02
|
ND/2024/03
|
ND/2024/04
|
ND/2024/06
|
ND/2024/07
|
ND/2024/08
|
|
T1. Ng Tung River
|
✓
|
✓
|
✓
|
|
✓
|
✓
|
✓
|
|
T2. Ng Tung River
|
✓
|
✓
|
✓
|
|
✓
|
✓
|
✓
|
|
T3. Sheung Yue River
|
✓
|
✓
|
✓
|
|
✓
|
✓
|
✓
|
|
T4. Shek Sheung River
|
|
✓
|
|
✓
|
|
✓
|
✓
|
|
T5. Long Valley
|
✓
|
✓
|
✓
|
|
|
|
|
Monitoring Frequency
6.3.4 Avifauna monitoring at high and low tides should be
conducted weekly. Additionally, nighttime monitoring in Long Valley should be
conducted twice a month from September to April, which is not required for the
reporting month.
6.3.5 For this reporting month, waterbird monitoring was
conducted by both the First Phase ET (T1, T2, T3 and T5) and Remaining Phase ET
(T4). Survey date for each monitoring is shown in Table 6.3.
Table 6.3 Monitoring Programme for Waterbirds Monitoring, March 2026
|
Week
|
Date
|
Transect(1)
|
|
1
|
2 Mar 26
|
T1, T2
|
|
3 Mar 26
|
T4
|
|
5 Mar 26
|
T3, T4, T5
|
|
2
|
9 Mar 26
|
T1, T2
|
|
10 Mar 26
|
T4
|
|
11 Mar 26
|
T3, T5
|
|
12 Mar 26
|
T4
|
|
3
|
17 Mar 26
|
T3, T4, T5
|
|
19 Mar 26
|
T4
|
|
20 Mar 26
|
T1, T2
|
|
4
|
23 Mar 26
|
T3, T5
|
|
24 Mar 26
|
T1, T2, T4
|
|
26 Mar 26
|
T4
|
|
5
|
30 Mar 26
|
T3, T5
|
|
31 Mar 26
|
T1, T2, T4
|
|
Additional Nighttime
Monitoring in Long Valley
|
17 Mar
26
|
T5
|
|
30 Mar
26
|
Remarks:
(1)
Transects T1, T2, T3, and T5 are relevant to Works
Contract ND/2024/01 and ND/2024/03; Transect T4 is relevant to Works Contract
ND/2024/04; Transects T1, T2, and T3 are relevant to Works Contract ND/2024/06;
Transects T1, T2, T3 and T4 are relevant to Works Contract ND/2024/07 and
ND/2024/08; Transect T1, T2, T3, T4 and T5 are relevant to Works Contract No.
ND/2024/02.
Monitoring Results
6.3.6 For this reporting month, only monitoring results in
Transects T1, T2, T3, T4 and T5 are reported as not all of these monitoring
data are relevant to active Works Contract ND/2024/01, ND/2024/02, ND/2024/03,
ND/2024/04, ND/2024/06, ND/2024/07 and ND/2024/08 as summarised in Table 6.1.
6.3.7 Transect T1 and T2 were conducted along the Ng Tung
River. For Transect T1, a total of 4 species of large waterbirds, namely Great
Cormorant (9 individuals), Grey Heron (15 individuals), Great Egret (41
individuals) and Little Egret (46 individuals), were recorded in the reporting month.
For Transect T2, a total of 3 species of large waterbirds, namely Grey Heron (19
individuals), Great Egret (60 individuals) and Little Egret (51 individuals),
were recorded in the reporting month.
6.3.8 Transect T3 was conducted along the Sheung Yue
River. A total of 4 species of large waterbirds, namely Grey Heron (29
individuals), Great Egret (31 individuals), Intermediate Egret (37 individuals)
and Little Egret (151 individuals), were recorded for the reporting month.
6.3.9 Transect T4 was conducted along the Shek Sheung
River. A total of 4 species of large waterbirds, namely Great Cormorant (1
individual), Grey Heron (4 individuals), Great Egret (7 individuals) and Little
Egret (31 individuals), were recorded during the reporting month.
6.3.10 Transect T5 was conducted in Long Valley Nature Park
with the highest species diversity and abundance recorded. A total of 5 species
of large waterbirds, namely Great Cormorant (1 individual), Grey Heron (16
individuals), Great Egret (14 individuals), Intermediate Egret (3 individuals)
and Little Egret (76 individuals), were also found to utilise the habitat.
6.3.11 Chinese Pond Heron, the most abundant waterbird
species recorded during the baseline survey, which is strictly associated with
wetlands, was widely noted across different transect routes in the reporting
month 151 individuals recorded in total. 30 individuals were noted along
Transect T1, 35 individuals along Transect T2, 15 individuals along Transect
T3, 19 individuals along Transect T4, and 52 individuals were noted along
Transect T5.
6.3.12 Relevant
results of the avifauna monitoring conducted by the First Phase ET during this
reporting month are detailed in Appendix 6.1a to
Appendix 6.1l.
Findings of surveys conducted by the Remaining Phase ET during this reporting
month are detailed in Appendix 6.1m to
Appendix 6.1q.
6.3.13 Table 6.4
summarizes the results of the monitoring of measures to minimize disturbance to
waterbirds in Ng Tung River, Sheung Yue River, Shek Sheung River and Long
Valley of the reporting month.
Table 6.4
Summary Table of Waterbird Monitoring Results Relative to Corresponding Action
and Limit Levels, March, Transects T1, T2, T3, T4 and T5
|
Monitoring Parameter
|
Result in Reporting Month
(March 2026)
|
Baseline Level in Corresponding Month
(March 2020)
|
Action
Level (1)
|
Limit
Level (2)
|
|
T1, T2
and T3
|
|
Mean abundance of large waterbirds using Ng
Tung River, Sheung Yue River and Shek Sheung River (3)
|
98
|
26
|
18
|
13
|
|
Mean abundance of Chinese Pond Heron using Ng
Tung River, Sheung Yue River and Shek
Sheung River
|
16
|
12
|
8
|
6
|
|
T4
|
|
Mean abundance of large waterbirds using Shek
Sheung River (3)
|
9
|
5
|
3
|
2
|
|
Mean abundance of Chinese Pond Heron using
Shek Sheung River
|
4
|
4
|
3
|
2
|
|
T5 Long
Valley
|
|
Mean Abundance of birds (all species)
recorded in LVNP
|
1027
|
564
|
395
|
282
|
|
Mean abundance of the Chinese Pond Heron
|
10
|
12
|
9
|
6
|
|
Environmental disturbance and damage from
activities in LVNP
|
-
|
-
|
Activity likely to cause unacceptable
environmental
disturbance or
damage noted in LVNP.
|
Activity likely to cause unacceptable
environmental
disturbance or
damage noted in LVNP.
|
|
|
|
|
|
|
Remarks:
(1)
Exceedance of Action Level occurs when the
monitoring result is lower than the Action Level.
(2)
Exceedance of Limit Level occurs when the
monitoring result is lower than the Limit Level.
(3)
Large waterbird species for mean abundance
calculation include Great Cormorant (Phalacrocorax carbo); Grey Heron (Ardea
cinerea); Great Egret (Ardea alba); Intermediate Egret (Ardea
intermedia); Little Egret (Egretta garzetta) and Chinese Egret (Egretta
eulophotes).
6.3.14
No
exceedance in Action or Limit Level was recorded for the reporting month.
Monitoring of Measures to Minimise Impacts to Ma Tso Lung Stream and
Siu Hang San Tsuen Stream, and Long Valley
6.3.15 As stipulated in Section 12.3.2.14 of the Updated
EM&A Manual, aquatic fauna monitoring should be conducted monthly during
the wet season of the construction phase. Therefore, no aquatic fauna
monitoring was carried out during the reporting month. Monitoring activities
will be resumed in April 2026.
Monitoring of
Measures to Minimise Impacts on Ecological Sensitive Habitats from Disturbance
and Pollution
Monitoring Methodology
Terrestrial Mammal
6.3.16
Mammal
surveys were conducted both during the day and at night along transect routes
that may be potentially utilized by terrestrial mammals. Observations included
field signs such as droppings, footprints, diggings, and burrows left by larger
terrestrial mammals. Any mammals directly observed were recorded, and
identification was as accurate as possible based on the field signs.
6.3.17
Bat
surveys were conducted along the transect routes shortly after sunset using a
bat detector to record echolocation calls. The relative abundance of the
species encountered were estimated with reference to the baseline monitoring
results, using a scale from one (species recorded within transect routes) to
three (dominant species within transect routes), for comparison between
baseline and current monitoring results. Mammal nomenclature followed Shek
(2006).
6.3.18 Echolocation calls of bats were recorded using a bat
detector, which listed possible bat species with similar call patterns and
frequencies. The structure of the recorded echolocation calls was later
analysed to identify species as accurately as possible. Due to the lack of
literature on echolocation call structures, field identification of some bat
species in Hong Kong is challenging, and some species could only be identified
to the genus level or remain unidentified from the recordings.
6.3.19 Identification of bat species encountered in the
surveys was made by considering the possible species suggested by the bat
detector, their distribution in Hong Kong, previous records in the EIA Report
and Baseline Monitoring Report, and the structure of the echolocation calls
(including call structure, frequency, duration, and inter-pulse interval) with
reference to relevant literature.
Herpetofauna (Amphibians and Reptiles)
6.3.20 Both daytime and nighttime amphibian surveys were
conducted whenever possible following or during periods of rainfall, focusing
on areas suitable for amphibians (e.g., forests, shrublands, grasslands,
streams, ponds, marshes, etc.). Calling amphibians were recorded, supplemented
by visual observations of eggs, tadpoles, adult frogs, and toads.
6.3.21 Active searches of appropriate microhabitats, such
as stones, pond bunds, crevices, and leaf debris, was primarily conducted.
Observations of exposed, basking, and foraging reptiles were also carried out.
Nomenclature for amphibians and reptiles followed Chan et al. (2005) and Karsen
et al. (1998), respectively.
Butterfly and Odonates
6.3.22 Butterflies and dragonflies observed along the
transects were identified and counted. Special attention was given to their
preferred habitats, such as watercourses, fishponds, and vegetated areas.
Nomenclature and protection status of the species followed Lo et al. (2005) for
butterflies and Tam et al. (2011) for dragonflies.
Monitoring Parameters
6.3.23 The monitoring parameters are as follows:
·
Species
composition;
·
Abundance;
·
Distribution for
fauna observed; and
·
Species of
conservation importance would be specified.
Monitoring Location
6.3.24 According to the Updated EM&A Manual, the
transect routes for monitoring of ecologically sensitive receivers should
follow the following:
·
T1. Ma Tso Lung
riparian zone and associated wetland habitats; green belt areas E1-8, D1-8 and
G1-3 in KTN NDA; AGR zone C2-4 and C2-2 in
KTN NDA, and area north of Ng Tung River;
·
T2. Fanling
North Freshwater Service Reservoir
·
T3. Area west of
Siu Hang San Tsuen Stream;
·
T4. South side
of Fanling Highway and Castle Peak Road in the vicinity of Pak Shek Au;
·
T5. Area west
and east of the southern limit of the FLN NDA work area; and
·
T6. Areas in the
western part of KTN.
6.3.25 The
above transects are shown in Figure 6.1 and Figure 6.2. Relevant transect to Works Contract ND/2024/01 is
Transect T1 which covers areas of Ma Tso Lung riparian zone and associated
wetland habitats, green belt areas E1-8, D1-8 and G1-3 in KTN NDA, AGR zone
C2-4 and C2-2 in KTN NDA, and areas North of Ng Tung River; relevant transects
to Works Contract ND/2024/02 are Transect T1 and T6, of which the latter covers
areas to the west of the KTN NDA work area; relevant transect to Works Contract
ND/2024/03 is Transect T4 which covers the south side of the Fanling Highway
and Castle Peak Toad in the vicinity of Pak Shek Au; relevant transect to Works
Contract ND/2024/06 is Transect T2 which covers areas of the Fanling North
Freshwater Service Reservoir; Works Contract ND/2024/07 involves Transect T3
which covers the area west of Siu Hang San Tsuen stream; and Works Contract
ND/2024/08 involves Transect T3 as well.
Monitoring Frequency
6.3.26 Monthly
monitoring should be conducted for non-aquatic fauna, including terrestrial
mammals, insects (butterflies and odonates), and herpetofauna. For this reporting month, monthly monitoring for
non-aquatic fauna were conducted by both the First Phase ET (T1, T3, T4 and T6)
and Remaining Phase ET (T2). Survey dates for each monitoring are shown in Table 6.5.
Table
6.5 Monitoring Programme for Non-aquatic Fauna Monitoring, March 2026
|
Responsible ET
|
Date
|
Transect(1)
|
|
First Phase ET
|
3 Mar
26
|
T3, T4
|
|
6 Mar
26
|
T1, T6
|
|
Remaining Phase ET
|
25 Mar
26
|
T2
|
Remarks:
(1)
Transect T1 is relevant to Works Contract
ND/2024/01 and Works Contract ND/2024/02; Transect T2 is relevant to Works
Contract ND/2024/06; Transect T3 is relevant to Works Contracts ND/2024/07 and
ND/2024/08; Transect T4 is relevant to Works Contract ND/2024/03; Transect T6
is relevant to Works Contract ND/2024/02.
Monitoring Results
Terrestrial Mammals
6.3.27 Only 2 introduced species of terrestrial mammals were
recorded along Transect T1 and none of them are of conservation importance. 6 native
bat species of conservation importance, namely Intermediate Horseshoe Bat,
Himalayan Leaf-nosed Bat, Chinese Noctule, Japanese Pipistrelle, Least
Pipistrelle and Lesser Yellow Bat, were recorded along Transect T2 for the
reporting month. 2 species of native terrestrial mammals, namely the Japanese
Pipistrelle and Eurasian Wild Pig, were recorded along Transect T3, with the
former species recognised as of conservation importance. A total of 3 species
of terrestrial mammal species were recorded along Transect T4, with Japanese
Pipistrelle and Pallass Squirrel are of conservation importance. No mammal
species were recorded along Transect T6 for the reporting month. A complete
species list is enclosed as Appendix 6.2.
Herpetofauna (Amphibians and Reptiles)
6.3.28 3 native herpetofauna species were recorded along
Transect T1 with 1 species of amphibians and 2 species of reptile. All species
are common and widespread natives. 3 native herpetofauna species (1 amphibians
and 2 reptile species) were recorded along Transect T2, of which all are
considered common and widespread locally. 1 native and widespread amphibian
species was recorded along Transect T3 for the reporting month. A total of 4
native herpetofauna species (3 amphibians and 1 reptile species) were recorded
along Transect T4, with no species of conservation importance noted. 1 native
and widespread reptile species was recorded along Transect T6. A complete
species list is enclosed as Appendix 6.2.
Butterfly and Odonates
6.3.29 A total of 24 butterfly species were recorded along Transect T1,
with 3 species (Common Cerulean, Swallowtail and Small Cabbage White) are of
conservation importance. 3
odonate species were recorded along Transect T1. All species recorded are
considered as common natives. 18
butterfly species were recorded along Transect T2 for the reporting month, with
1 species, namely the Tiny Grass Blue, is of conservation importance. 3 odonate
species, namely Common Blue Skimmer, Wandering Glider and Saddlebag Glider, were
recorded during the monitoring for the reporting month. None of these are of conservation
importance. A total of 4 butterfly species were recorded along Transect T3. All
species recorded are considered as common and widespread. 8 butterfly
species were recorded along Transect T4 with no species of conservation
importance were noted. 7 butterflies species were recorded along Transect T6
for the reporting month. All species are considered widespread and common
locally with no species of conservation importance noted. Only 1 very common
species of odonate, namely Wandering Glider, was recorded along Transect T3, T4
and T6. A
complete species list is enclosed as Appendix 6.2.
Summary of Monitoring Results
6.3.30 Monitoring for non-aquatic (terrestrial mammals,
butterflies, dragonflies, and herpetofauna) taxa was conducted by both the
First Phase and Remaining Phase ETs. Relevant results of the non-aquatic fauna
monitoring conducted by the First Phase ET during this reporting month are
detailed in Appendix 6.2a to Appendix 6.2d. Findings of surveys
conducted by the Remaining Phase ET during this reporting month are detailed in
Appendix
6.2e to Appendix 6.2h.
6.3.31 Tables 6.6 summarizes the monitoring results of Transect T1,
T2, T3, T4 and T6 for this reporting month.
Table 6.6
Summary Table of Monitoring Results for Non-aquatic Fauna Relative to Action
and Limit Levels, March 2026, Transect T1, T2, T3, T4 and T6
|
Monitoring
Parameter
|
Result
in
Reporting Month
(March 2026) (1)
|
Baseline Level in Corresponding
Month (March 2020) (1)
|
Action Level(2)
|
Limit Level(3)
|
|
T1
|
|
Terrestrial Mammals
|
0
|
1
|
N/A
|
N/A
|
|
Herpetofauna
|
3
|
4
|
3
|
2
|
|
Odonates
|
3
|
5
|
4
|
3
|
|
Butterflies
|
24
|
9
|
6
|
5
|
|
T2
|
|
Terrestrial Mammals
|
6
|
0
|
N/A
|
N/A
|
|
Herpetofauna
|
3
|
0
|
N/A
|
N/A
|
|
Odonates
|
3
|
1
|
N/A
|
N/A
|
|
Butterflies
|
18
|
4
|
3
|
2
|
|
T3
|
|
Terrestrial Mammals
|
2
|
1
|
N/A
|
N/A
|
|
Herpetofauna
|
1
|
2
|
N/A
|
1
|
|
Odonates
|
1
|
4
|
3
|
2
|
|
Butterflies
|
4
|
4
|
3
|
2
|
|
T4
|
|
Terrestrial Mammals
|
1
|
0
|
N/A
|
N/A
|
|
Herpetofauna
|
4
|
3
|
2
|
1
|
|
Odonates
|
1
|
2
|
N/A
|
1
|
|
Butterflies
|
8
|
6
|
4
|
3
|
|
T6
|
|
Terrestrial Mammals
|
0
|
0
|
N/A
|
N/A
|
|
Herpetofauna
|
1
|
2
|
N/A
|
1
|
|
Odonates
|
1
|
3
|
2
|
1
|
|
Butterflies
|
7
|
5
|
4
|
3
|
Remarks:
(1)
Number of species (species richness) recorded; the
results in the reporting month for terrestrial mammals, herpetofauna and
odonates are calculated based on the number of native species recorded along
the transects.
(2)
Exceedance of Action Level occurs when the
monitoring result is lower than the Action Level.
(3)
Exceedance of Limit Level occurs when the
monitoring result is lower than the Limit Level.
6.3.32 2 Action Level exceedances (Odonates for Transect T1
and Transect T6) and 1 Limit Level exceedance (Odonates for Transect T3) were
recorded for Monitoring of Measures to Minimise Impacts on Ecological Sensitive
Habitats from Disturbance and Pollution during the reporting month. All
exceedances were considered non-project related, as no evidence suggested the
exceedances were associated with project activities. Additionally, the low
species diversity of odonate species were impacted by a shift from prolonged dry
conditions to brief, intense rainfall, despite the favourable weather condition
recorded throughout the reporting month. Heavy showers occurred early in the
month had altered the water levels and turbidity, which might have disrupted
odonate breeding habitats and suppressed flight activities, and eventually
influenced the survey findings. As a result, the low species diversity observed
across survey transects reflected the effects of such short-term environmental
fluctuations rather than representing a long-term decline in habitat
quality.
Details of the Influencing
Factors
6.3.33 The
details of the influencing factors were adopted from the observations of the
First Phase ET. During the monitoring of measures to minimize disturbance to
waterbirds in Long Valley and Sheung Yue River, anthropogenic activities such
as excavation and other construction activities were observed near Long Valley.
It should also be noted that the Long
Valley Nature Park has been opened to the public since 09 November 2024. Potential
increase in people visiting the park may potentially impact the habitats in
Long Valley and cause disturbances to the bird communities in this area. Construction
works were also observed along Sheung Yue Riverr.
6.3.34 During
the monitoring of measures to minimize disturbance to waterbirds in Ng Tung
River, various anthropogenic activities were observed, such as construction
works along Transect T2, recreational use of remote-control boats and toy helicopters in
both Transects T1 and T2, and recreational fishing along these two transects.
Survey Summary
6.3.35 All
ecological monitoring surveys for the reporting month have been carried out as
scheduled, with 2 exceedances in Action Levels and 1 exceedance
in Limit Level were reported for odonate species during the non-aquatic fauna
surveys conducted by the First Phase ET. All exceedances were considered as
non-project related.
6.4
Man Kam To Egretry Monitoring
6.4.1
A pre-site clearance check of the Man Kam To Egretry
(MKT Egretry) was undertaken on 13 February 2026 to investigate its status,
extent, and location prior to the commencement of works within 100m of the
egretry, pursuant to EM&A Manual Section 14.3.2.3.
6.4.2
Egretry location was checked on 31 March 2026 for the
reporting month to identify and confirm the presence of any ardeid nests,
covering the previous core extent and its split colonies, prior to the
commencement of works activity within 100m of the egretry.
6.4.3
Egretry monitoring for the MKT Egretry and its split
colonies will be conducted once in April 2026.
6.5.1 Should
non-compliance of the ecological monitoring criteria occur, actions in
accordance with the Event and Action Plan in Appendix 6.4 shall be carried out.
7
Landscape and Visual
7.1.1
According to the approved EM&A
manual and Updated EM&A Manual for the First Phase, site audits should be
undertaken at least once every two weeks during the construction
period, by the Environmental Team. Particularly, to check that the proposed
landscape and visual mitigation measures are properly implemented and
maintained as per their intended objectives. Mitigation measures recommended in
the EIA Report as the audit requirements including, preservation of existing
vegetation, transplanting of affected trees, compensatory tree planting,
control of night-time lighting glare, erection of decorative screen hoarding
and management of construction activities and facilities.
7.2.1 Bi-weekly
landscape and visual site audits were carried out by the ET during the
reporting period. Inspections were carried out on 3 and 19 March 2026 for
ND/2024/01, 3 and 19 March 2026 for
ND/2024/02, 2, 20 and 30 March 2026 for ND/2024/03, 13 and 24 March 2026 for
ND/2024/04, and 23 March 2026 for ND/2024/06, 12 and 26 March 2026 for
ND/2024/07. No particular observation
was recorded in this reporting period.
7.3.1 Should
any non-compliance of the criteria occur, action in accordance with the Event
and Action Plan in Appendix 7.1 shall be followed.
8.1.1 According
to the approved EM&A Manual and Updated EM&A Manual for the First Phase,
an ambient arsenic monitoring is required to be conducted in KTN during the
clean-up processes of arsenic containing soil and the construction phase.
8.1.2 The
RSP concentration was measured by HVS equipped with PM10 selector (PM10 HVS)
following the "Reference Method for the Determination of Particulate
Matter as PM10 in the Atmosphere" Part 50 Chapter 1 Appendix J, Title 40
of the Code of Federal Regulations of the USEPA.
8.1.3 The
Dust-laden air was drawn through PM10 HVS fitted with a conditioned
pre-weighting filter paper, at a controlled rate. After sampling for 24-hour,
the filter paper with retained PM10 particulates was collected and returned to
the laboratory for drying in a desiccator followed by accurate weighting.
24-hour average RSP levels were calculated from the ratio of the mass of PM10
particulates retained on the filter paper to the total volume of air sampled.
8.1.4 The
weighted filter paper was prepared for arsenic testing through a "Hot Acid
Extraction Procedure". The extracted material was tested for arsenic by
using Inductively Coupled Plasma/Mass Spectrometry (ICP/MS). The extraction and
testing were referenced to the following methods:
·
Compendium
Method 1O-3.1 Selection, Preparation and Extraction of Filter Material, Center
for Environmental Research Information, Office of Research and Development,
USEPA, June 1999; and Compendium Method 1O-3.5 determination of Metals in
Ambient Particulate Matter using Inductively Coupled Plasma/Mass Spectrometry
(ICP/MS., Center for Environmental Research Information, Office of Research and
Development, USEPA, June 1999.
8.2.1 Ambient
arsenic monitoring was conducted at the monitoring station(s) under the Work
Contract(s), as shown in Table 8.1 describes the location of the
ambient arsenic monitoring station. The
location of the ambient arsenic monitoring station is presented in Figure 8.1.
Table 8.1 Location of Ambient Arsenic Monitoring station
|
Monitoring Station(s)
|
Location(s)
|
Works Contract(s)
|
|
KTN-DMS-4A(1)(2)
|
Temporary Structure at Pak Shek Au
|
ND/2024/01
|
Remarks:
(1)
Monitoring at the original
location of KTN-DMS-4 (originally proposed in the approved EM&A Manual) was
denied as there was no electricity supply. An alternative location (KTN-DMS-4A)
was proposed by First Phase ET.
(2)
The ambient arsenic
monitoring was conducted by First Phase ET during the reporting period.
8.3.1
Table 8.2
summarises the equipment used in the ambient arsenic monitoring. Copies of the
calibration certificates for ambient arsenic monitoring are shown in Appendix 8.1
Table
8.2 Ambient Arsenic Monitoring Equipment
|
Monitoring
Station
|
Equipment
|
Manufacturer
|
Model
|
No.
of Equipment
|
|
KTN-DMS-4A(1)(2)
|
Calibrator
|
TISCH
|
TE-5025A
|
1
|
|
HVS
Sampler (RSP)
|
TISCH
|
TE-6070X
|
1
|
Remarks:
(1) Monitoring
at the original location of KTN-DMS-4 (originally proposed in the approved
EM&A Manual) was denied as there was no electricity supply. An alternative
location (KTN-DMS-4A) was proposed by First Phase ET.
(2) The ambient arsenic monitoring was conducted by
First Phase ET during the reporting period.
8.4.1 Table 8.3 summarises
the monitoring parameters and frequencies of ambient arsenic during the
clean-up processes of arsenic-containing soil and construction. The ambient
arsenic monitoring schedule for the reporting month shown in Appendix 2.1.
Table
8.3 Impact Ambient Arsenic Monitoring
Parameters, Frequency and Duration
|
Parameters
|
Frequency(1)
|
|
24-hour RSP (Ambient Arsenic)
|
Once/ 6 days
|
Remark:
1. The ambient arsenic monitoring was conducted by
First Phase ET during the reporting period.
Instrumentation
8.5.1 HVS
(GMW PM10 (TE6070X)) complete with appropriate sampling inlets was employed for
24-hour RSP monitoring. The sampler was composed of a motor, a filter holder, a
flow controller and a sampling inlet and its performance specification complied
with that required by USEPA Standard Title 40, Code of Federation Regulations
Chapter 1 (Part 50).
8.5.2 The
following guidelines were adopted during the installation of HVS:
·
a horizontal
platform with appropriate support to secure the samplers against gusty wind was
provided;
·
no two samplers
were placed less than 2 meters apart;
·
the distance
between the sampler and an obstacle, such as buildings, was at least twice the
height that the obstacle protrudes above the sampler;
·
a minimum of 2
meters of separation from walls, parapets and penthouses was required for
rooftop samplers;
·
a minimum of 2
meters separation from any supporting structure, measured horizontally was
required;
·
no furnace or
incinerator flue was nearby;
·
airflow around
the sampler was unrestricted;
·
the sampler was
more than 20 meters from the dripline;
·
any wire fence
and gate, to protect the sampler, were not cause any obstruction during
monitoring;
·
permission was
obtained to set up the samplers and to obtain access to the monitoring
stations; and
·
a secured supply
of electricity was needed to operate the samplers
Operating/analytical
procedures for the operation of HVS
·
Prior to the commencement of
the dust sampling, the flow rate of the high volume sampler was properly set
(between 1.1 m3 /min. and 1.4 m3 /min.) in accordance
with the manufacturer's instruction to within the range recommended in USEPA
Standard Title 40, CFR Part 50;
·
The power supply was checked to
ensure the sampler worked properly. On sampling, the sampler was operated for 5
minutes to establish thermal equilibrium before placing any filter media at the
designated air monitoring station;
·
The filter holding frame was
then removed by loosening the four nuts and a weighted and conditioned filter
was carefully centered with the stamped number upwards, on a supporting screen;
·
The filter was
aligned on the screen so that the gasket formed an airtight seal on the outer
edges of the filter. The filter holding frame was then tightened to the filter
holder with swing bolts. The applied pressure was sufficient to avoid air
leakage at the edges;
·
The shelter lid
was closed and secured with the aluminium strip;
·
The timer was
then programmed. Information was recorded on the record sheet, which included
the starting time, the weather condition and the filter number (the initial
weight of the filter paper can be found out by using the filter number);
·
After sampling,
the filter was removed and sent to the Wellab Ltd. for weighing. The elapsed
time was also recorded; and
·
Before weighing,
all filters were equilibrated in a conditioning environment for 24 hours. The
conditioning environment temperature was between 25°C and 30°C and did not vary
by more than ±3°C; the relative humidity (RH) was < 50% and did not vary by more
than ±5%. A convenient working RH was 40%. Weighing results were further
analysis of RSP concentrations collected by each filter.
8.6.1 The
following maintenance/calibration was required for the HVS:
·
The high volume
motors and their accessories were properly maintained. Appropriate maintenance
such as routine motor brushes replacement and electrical wiring checking were
made to ensure that the equipment and necessary power supply were in good
working condition; and
·
High volume
samplers were calibrated at bi-monthly intervals using TE-5025A Calibration Kit
throughout all stages of the ambient arsenic monitoring.
8.7.1 Quartz
filters of size 8 x 10 were labelled before sampling. A HOKLAS accredited
laboratory, Wellab Ltd., was responsible for the preparation of 24-hour
conditioned and pre-weighed filter papers for the monitoring team. The balance
for weighting filter paper was regularly calibrated against a traceable
standard.
8.7.2 All
filters, which were prepared and equilibrated in the conditioning environment
for 24 hours before weighing. The conditioning environment temperature was
around 25 °C and not variable by more than ±3 °C; the relative humidity (RH)
was < 50% and not variable by more than ±5%. A convenient working RH was
40%.
8.7.3 Wellab
Ltd. (HOKLAS Registration No. HOKLAS083), was responsible for the extraction
and testing procedure for Arsenic and comprehensive quality assurance and
quality control programmes were conducted.
8.8.1 The
ambient arsenic monitoring results are summarised in Table 8.4.
Table
8.4 Result Summary Against Action and Limit
Levels for 24-hour RSP Monitoring Results (Ambient Arsenic)
|
Contract No.
|
Monitoring
Date
|
Monitoring
Station
|
Concentration
(ƞg/m3)
|
AL
(ƞg/m3)
|
LL
(ƞg/m3)
|
|
ND/2024/01
|
3/3/2026
|
KTN-DMS4A*
|
3.37
|
9.36
|
11.7
|
|
9/3/2026
|
5.61
|
|
13/3/2026
|
5.81
|
|
19/3/2026
|
4.50
|
|
25/3/2026
|
4.11
|
|
31/3/2026
|
3.47
|
Remark:
* The 24-hour RSP monitoring
for ambient arsenic was conducted by First Phase ET during the reporting period.
8.8.2 All ambient arsenic monitoring was conducted as
scheduled in the reporting month. During the reporting month, 370.37m3
of arsenic soil transported to soil treatment plant and 2866.74m3
treated. No AL
or LL exceedances were recorded.
8.9.1 Should
any non-compliance of the criteria occur, actions in accordance with the
Event/Action Plan in Appendix 8.2 shall
be carried out.
Works Contract No. ND/2024/01:
· All Site Resumption Area(s)
1.
Tree survey
2.
Site Clearance
· Portion III (3), IV (4), V (5),
VII (7) and XXXV (35)
1.
Site Formation
· Portion VIII (8)
1.
Site Clearance & Demolition
· Portion XVIII (18), XXXVIII (38)
1.
Excavation works
2.
Construction of CHC Box Culvert
· Portion XI (11), XXIII (23)
1.
Erection of Substructure of Metropolis Community Liaison and Visitor
Centre
· Portion XL (40)
1.
Retaining
Wall Construction
2.
Drainages
System Construction
3.
ELS
work
· Portion LIX (59)
1.
Treatment of
High Arsenic-Containing Soil (HAS)
2.
Erection of
Shredding Facility
· Portion XVII (17), XVII (18), XXI (21), XXXIV (34),
XXXV (35), XLI (41), XLII (42)
1.
Excavation
Works
2.
Drainage Pipe
Installation
3.
ELS Works
· Portion XXV (25), XXVII (27), XXXIII (33), XLII
(42) and XLIV (44)
1. Site Clearance
2. Site Formation
3. Construction of Box Culvert
n
Works Contract No.
ND/2024/02:
1.
Site clearance in Area A,
B, C, D, T, L
2.
Site formation works in
Area D
3.
Temporary storage fill bank
in Kwu Tung Grass Soccer Pitch
4.
Demolition works for
Community Sports in Area J
5.
Asbestos Survey
6.
Ground Investigation Works
n
Works Contract No.
ND/2024/03:
Fanling Highway
& Castle Peak Road area
· Pak Sau Road Po Lau Road
1.
Tree Works
· Po Lau Road Sheung Yue River
1.
Asbestos
Removal Works at Portion IX
2.
Box Culvert
Bay 37 Bay 42 ELS
3.
Tree Works
· TTA Stage 1 Works
1.
Tree Works
New Tsung Pak Long Road
·
Box culvert
Bay 10 to 12, 14 to 16 Drainage/Watermains
1.
Drainage,
Sewerage & Watermain with Backfilling at Box Culvert Bay 15 & 16
2.
Box Culvert
Bay 14 ELS
· Box culvert Bay 17 to 19 & Drainage/Watermains
1.
Box Culvert
Bay 17 to 19 ELS, Base Slab, Wall and Top Slab
2.
Box culvert
Bay 17 & 19 Base Slab
· Retaining Wall RW01
1.
Pre-drilling
· Retaining Wall RW05A
1.
RW05A ELS
· Kwu Tung Road Bridge
1.
Site
Clearance and Tree Works
2.
Site
formation and cutback the existing slope
3.
Predrilling
4.
Foundation
& Piling
·
Works Areas
WA1, WA2, WA3, WA4 & WA5
1.
Site
Formation at PMs Site Office
2.
Site
Clearance, haul road and Temporary Drainage
3.
Asbestos
removal
Fanling Highway Cross River
Bridge (along Sheung Yue River)
· Portion XI East Abutment & pier foundation
1.
Trial Pits
for UUs
2.
Piling Works
·
Road L3
Viaduct
1.
Piling Works
2.
Pile Cap
L3A-02
· Kwu Tung Interchange Foundation & Substructure
- Bridge B1 & C1
1.
Piling Works
· Widening of Existing Bridge No.N526
1.
Tree Works
2.
ELS
3.
Pilling
n
n Works Contract No. ND/2024/04:
· Site Clearance
· Site Establishment
· Tree Felling
· Trial Pit
· Pre-drilling
· Ground Investigation
· Existing Sewage Diversion
· Demolition of Existing Structures
· Haul Road Construction
· Bored Piling
· ELS Construction
· Slope Works
· Sheet Piling
n
n Works Contract No. ND/2024/06:
· Portion A
1.
Excavation to +90 mPD of
Portion A
2. Forming Haul Road form Area C to Portion A
· Portion C, D, E
& F
1.
Trench
and Watermans Laying Works
· Area N
1.
Jacking Pit
Excavation
· Pre-boring of Pit B & C
n
Works Contract No. ND/2024/07:
1. Site Clearance
2. Site Formation
3. Ground Investigation
4. Pre-bored Socketed H Pile Construction
5. Bridge Construction
6. Bridge Deck Connection (Footbridge FB5)
7. Lift Tower Construction
8. Sump Pit Construction
9. ABWF Works
10. Drainage Construction
11. Improvement of Junction
12. Road Construction
13. Temporary Road Construction
14. Open Landscaping Works
15. Tree Felling & Transplantation
16. Asbestos Containing Materials Survey & Removal
17. Land Contamination (Environmental Ground Investigation)
18. Internal Movement, Importation & Exportation of C&D materials
19. Sewage Construction
20. Old Shrine Removal and New Shrine
Construction
21. Storm pipe Construction
22. Box Culvert Construction
23. Temporary Drainage Diversion
24. Rebar yard
25. Storage Yard for Concrete Pipe
n
n
Works Contract No.
ND/2024/05 and No. ND/2024/08:
1.
The
construction work has not commenced in the reporting month.
13.1.2 Potential
environmental impacts arising from the above construction activities are mainly
associated with construction noise impact, water quality impact, ecological
impact, waste management, and landscape and visual.
Dust
Regular watering to reduce dust
emissions from exposed site surface;
Stockpile of dusty materials
shall be covered entirely by impervious sheeting;
Provide vehicles washing
facilities at all site exits to wash away any dusty materials from vehicle
body;
NRMM Labels should be displayed
on the applicable equipment on site by the Contractor;
Provision of water sprinklers
along the haul road for dust suppression.
Noise
Only well-maintained plant
should be operated on-site, and plant should be maintained regularly during the
construction programme; and
Quality Powered Mechanical
Equipment (QPME) should be adopted as far as possible.
Water
Quality
No effluent discharge would be
allowed before acquired the effluent discharge license;
Surface run-off from
construction sites should be discharged into dedicated discharge point via
adequately designed sand/ silt removal facilities;
Channels/ earth bunds/ sandbags
barriers should be provided on site to properly direct stormwater to silt
removal facilities;
Silt removal facilities,
channels and manholes should be maintained, and the deposited silt and grit
should be removed regularly;
Open stockpiles of construction
materials on sites should be covered with tarpaulin or similar fabric during
rainstorms; and
Perimeter channels should be
provided on site boundaries where necessary to intercept stormwater run-off
from outside the site so that it will not wash across the site.
Waste
Management
Provision of sufficient waste
disposal points and regular collection of waste;
Regular cleaning and
maintenance programme for drainage system; and
Chemical containers shall be
stored with drip tray underneath.
Landscape
and Visual
Construction activities shall
be carefully designed to minimize impact on existing retained trees.
Land Contamination
Stockpiling site(s) should be
lined with impermeable sheeting and bunded. Stockpiles should be properly
covered by impermeable sheeting to reduce dust emission during dry season or
contaminated run-off during rainy season. Watering should be avoided on stockpiles
of soil to minimise runoff.
Landfill Gas Hazard
No Smoking and No Naked
Flame notices in Chinese and English should be posted prominently around the
construction site.
Ecology
Properly erect and maintain 2m
high solid barriers for protection.
An individual of orchid Eulophia cernua was found growing underneath the
pipeline adjacent to the access road leading to the summit of the Table Hill
Freshwater Service Reservoir for Contract No. ND/2024/06. The species of
conservation importance should be fenced off for protection to minimise the
potential impacts aroused from nearby construction activities as far as
possible.
14.1.1 This is the 15th Monthly EM&A Report
summarizing the findings of EM&A works at Works
Contract No. ND/2024/01, Works Contract No. ND/2024/02, Works Contract No.
ND/2024/03, Works Contract No. ND/2024/04, Works Contract No. ND/2024/06 and
Works Contract No. ND/2024/07 during the reporting month, this report documents
the findings of EM&A works at Works Contract No. ND/2024/01, Works Contract No. ND/2024/02,
Works Contract No. ND/2024/03, Works Contract No. ND/2024/04, Works Contract No. ND/2024/06 and
Works Contract No. ND/2024/07 under the Project during the reporting period
only. No construction works occurred in the remaining contracts during the
reporting period for Works Contract ND/2024/05 and ND/2024/08.
14.1.2 All
air quality monitoring was conducted as scheduled in the report period. No
Action Level or Limit Level exceedance was recorded for air quality monitoring
in the reporting period.
14.1.3 All
construction noise monitoring was conducted as scheduled in the report period. No
Action Level or Limit Level exceedance was recorded for construction
noise monitoring in the reporting period.
14.1.4 All
ambient arsenic monitoring was conducted as scheduled in the reporting
period. No Action or Limit Level exceedance was recorded
during ambient arsenic monitoring in the reporting period.
14.1.5 All
ecological monitoring was conducted as scheduled in the reporting period. 2 Action
Level and 1 Limit Level exceedances were recorded for the monitoring measures
to minimise impacts on ecological sensitive habitats from disturbance and
pollution. All exceedances were deemed as non-project related with potential
influences by abiotic factors.
14.1.6 No exceedance of limits was recorded for built heritage
monitoring (vibration monitoring) in the
reporting period.
14.1.7 Environmental
site inspections were conducted at
Works Contract No. ND/2024/01 on 3, 10, 19 and
27 March 2026. For Works Contact No. ND/2024/02 were carried out on
3, 10, 19 and 27 March 2026. For
Works Contact No. ND/2024/03 were carried out on 2, 9, 20, 25 and 30 March 2026.
For Works Contact No. ND/2024/04 were carried out on 6, 13, 20 and 24 March 2026. For
Works Contact No. ND/2024/06 were carried out on 2, 9, 16, 23 and 30 March 2026.
For Works Contract No. ND/2024/07 were carried out on 5, 12, 19 and 26 March 2026.
_R5_(Verified)_files/image002.jpg)
_R5_(Verified)_files/image004.jpg)
_R5_(Verified)_files/image006.jpg)
_R5_(Verified)_files/image008.jpg)
_R5_(Verified)_files/image010.png)
