Introduction
A1.
This is the 16th Monthly Environment Monitoring and
Audit (EM&A) Report for Remaining Phase Development of Kwu Tung North and
Fanling North New Development Areas (the Project) for the reporting period
between 1 and 30 April 2026. This report was prepared by Aurecon Hong Kong
Limited (Aurecon) under Service Contract No. NDO 05/2024 Remaining Phase
Development of Kwu Tung North and Fanling North New Development Areas -
Environmental Team (hereinafter called the “Service Contract”).
A2.
Since only construction works were undertaken
under Works Contract No. ND/2024/01, Works Contract No. ND/2024/02, Works
Contract No. ND/2024/03, Works Contract No. ND/2024/04, Works Contract No.
ND/2024/06 and Works Contract No. ND/2024/07 during the reporting month, this
report documents the findings of EM&A works at Works Contract No.
ND/2024/01, Works Contract No. ND/2024/02, Works Contract No. ND/2024/03, Works
Contract No. ND/2024/04, Works Contract No. ND/2024/06 and Works Contract No.
ND/2024/07 under the Project during the reporting period only. No construction
works occurred in the remaining contracts during the reporting period for Works
Contract ND/2024/05 and ND/2024/08.
A3.
This Project involves eight (8) Environmental
Permits (EPs) (i.e. EP-465/2013/A, EP-466/2013/A, EP-467/2013/A, EP-468/2013/A,
EP-470/2013/A, EP-471/2013/A, EP-472/2013/A and EP-476/2013). Details of each
EPs are summarised in Table A1.
Table A1 Works Contracts under relevant
Environmental Permits in the Reporting Month
|
Environmental Permit No.
|
Works Contracts
|
Title of Designated Project
|
Designated Project (DP)
|
|
EP-465/2013/A
|
ND/2024/03
ND/2024/04
ND/2024/05
|
San Tin Highway and Fanling Highway Kwu
Tung Section Widening (Between San Tin Interchange and Po Shek Wu
Interchange)
|
DP1
|
|
EP-466/2013/A
|
ND/2024/03
ND/2024/05
|
Castle Peak
Road Diversion
|
DP2
|
|
EP-467/2013/A
|
ND/2024/01
ND/2024/02
ND/2024/03
ND/2024/05
|
Kwu Tung
North New Development Area Road P1 and P2 and Associated New Kwu Tung
Interchange and Pak Shek Au Interchange Improvement
|
DP3
|
|
EP-468/2013/A
|
ND/2024/01
ND/2024/02
|
Kwu Tung
North New Development Area Road D1 to D5
|
DP4
|
|
EP-469/2013
|
-
|
Sewage Pumping Stations in Kwu Tung North
New Development Area
|
DP5
|
|
EP-470/2013/A
|
ND/2024/06
|
Utilization
of Treated Sewage Effluent (TSE) from Shek Wu Hui Sewage Treatment Works
|
DP7
|
|
EP-471/2013/A
|
ND/2024/04
|
Po Shek Wu
Interchange Improvement
|
DP8
|
|
EP-472/2013/A
|
ND/2024/08
|
Fanling
Bypass Western Section
|
DP9
|
|
EP-473/2013/A
|
-
|
Fanling
Bypass Eastern Section
|
DP10
|
|
EP-474/2013
|
-
|
Shek Wu Hui
Sewage Treatment Works - Further Expansion at Fanling North New Development
Area
|
DP11
|
|
EP-476/2013
|
ND/2024/07
ND/2024/08
|
Sewage
Pumping Stations in Fanling North New Development Area (FLNDA)
|
DP13
|
1.1.1.1
Key Construction Works in the Reporting
Period
A4.
Apart from the construction works undertaken
under Works Contract No. ND/2024/01 since 20 January 2025, construction works under
Works Contract No. ND/2024/07 commenced since 27 February 2025, construction
works under Works Contract No. ND/2024/06 commenced since 10 March 2025, construction
works under Works Contract No. ND/2024/04 commenced since 10 May 2025, construction
works under Works Contract No. ND/2024/03 commenced since 2 June 2025, construction
works under Works Contract No. ND/2024/02 has also been commenced since 9 February
2026. No construction works occurred in the remaining Works Contracts (i.e. Works
Contract ND/2024/05 and ND/2024/08) during the reporting period. The
commencement dates of each Works Contracts are summarized in Table A2.
Table A2
Commencement Dates of Each Works Contracts
|
Works
Contracts
|
Commencement
Dates
|
|
ND/2024/01
|
20 January 2025
|
|
ND/2024/02
|
9 February
2026
|
|
ND/2024/03
|
2 June 2025
|
|
ND/2024/04
|
10 May 2025
|
|
ND/2024/05
|
11 May 2026
|
|
ND/2024/06
|
10 March 2025
|
|
ND/2024/07
|
27 February 2025
|
|
ND/2024/08
|
May 2026
(Tentatively)
|
A5.
A summary of construction activities undertaken
during the reporting period is presented below:
Works Contract No. ND/2024/01:
· All Site Resumption Area(s)
1. Tree survey
2. Site Clearance
· Portion III (3), IV (4), V (5), VII (7) and XXXV (35)
1. Site Formation
· Portion XVIII (18),
XXXVIII (38)
1. Site Clearance
2. Excavation Works
3. Construction of CHC Box Culvert
· Portion VI (6)
1. Site Clearance
2. Excavation Works
· Portion VIII (8)
1. Site Clearance &
Demolition
2. Asbestos Abatement Works
· Portion XI (11), XXIII (23)
1. Formwork Erection, Rebar Fixing, Concreting Works
· Portion XII (12), XV (15), XXX (30), XXXI (31) and XLIV(44)
1. Site Clearance
· Portion XVI (16), XLII (42), LI (51) and LIII (53)
1. Site Clearance and Demolition
· Portion XL (40)
1. Retaining Wall Construction
2. Drainages System Construction
3. ELS work
· Portion LIX (59)
1. Treatment of High Arsenic-Containing Soil (HAS)
· Portion XVII (17), XVII (18), XXI (21), XXXIV (34), XXXV (35), XLI
(41), XLII (42)
1. Excavation works
2. Drainage Pipe Installation
3. ELS Works
· Portion XXV (25), XXVII (27), XXXII (33) and XLII (42)
1. Site Clearance
2. Site Formation
3. Construction of Box Culvert
Works Contract No. ND/2024/02:
· Site clearance in Area A, B, C, D, T, L
· Site formation works in Area D
· Temporary storage fill bank in Kwu Tung Grass Soccer Pitch
· Demolition works for Community Sports in Area J
· Ground Investigation Works in Area B&L
Works Contract No. ND/2024/03:
Fanling
Highway & Castle Peak Road area
· Pak Sau Road – Po Lau Road
1. Tree Works
2. Relocation/Reprovision/removal of existing TCSS, fire hydrant,
signage & streetligting
· Po Lau Road – Sheung Yue River
1. Asbestos Removal Works at Portion IX
2. Box Culvert Bay 37 – Bay 42 ELS
3. Tree Works
· TTA Stage 1 Works
1. Tree Works
2. Relocation/Reprovision/removal of existing TCSS, Fire Hydrant,
Telecom post, High Voltage Post, Signage & Streetligting
New Tsung Pak
Long Road
· Box culvert Bay 10 to 12, 14 to 16 Drainage/Watermains
1. Drainage, Sewerage & Watermain with Backfilling at Box Culvert
Bay 15 & 16
2. Box Culvert Bay 14 ELS
· Box culvert Bay 17 to 19 & Drainage/Watermains
1. Box Culvert Bay 17 to 19 ELS, Base Slab, Wall and Top Slab
2. Box culvert Bay 17 & 19 Base Slab
· Retaining Wall RW01
1. Pre-drilling
· Retaining Wall RW05A
1. RW05A Bay 12, 14 & 16 Base Slab
2. RW05A Bay 12, 14 & 16 Wall
· Kwu Tung Road Bridge
1. Site Clearance and Tree Works
2. Site formation and cutback the existing slope
3. Predrilling
4. Foundation & Piling
· Works Areas – WA1, WA2, WA3, WA4 & WA5
1. Site Formation at PM’s Site Office
2. Site Clearance, haul road and Temporary Drainage
3. Asbestos removal
Fanling Highway
Cross River Bridge (along Sheung Yue River)
· Portion XI – East Abutment & pier foundation
1. Trial Pits for UUs
2. Piling Works
· Road L3 Viaduct
1. Piling Works
2. Pile Cap L3A-02
· Kwu Tung Interchange Foundation & Substructure - Bridge B1 &
C1
1. Piling Works
· Widening of Existing Bridge No.N526
1. Tree Works
2. Pre-drilling
3. Piling
Works Contract No. ND/2024/04:
· Site Clearance
· Site Establishment
· Tree Felling
· Trial Pit
· Ground Investigation
· Existing Sewage Diversion
· Demolition of Existing Structures
· Haul Road Construction
· Bored Piling
· ELS Construction
· Slope Works
Works Contract No. ND/2024/06:
· Portion A
1. Excavation to +84 mPD of Portion A
2. Carry Out Soil Nails of Portion A
· Portion C, Portion E and Portion F
1. Trench and Watermains Laying Works
· Portion D
1. Trench and Watermains Laying Works
2. Demolition of DN2000 associated thrust blocks of Portion D
· Pit B and Pit C
1. Pre-boring
Works
Contract No. ND/2024/07:
· Area C
1. Tree Felling
2. Site Formation
· Area D and Area E
1. Site Formation
2. Asbestos Removal
· Area F
1. Tree Felling
· Area G
1. Site Clearance
2. Site Formation
3. Asbestos Removal
· Area H, Area I and Area R
1. Asbestos Removal
· Area J
1. Road Construction
· Area K
1. Sewerage (DN1350) Construction
2. Road Construction
3. Site Clearance
· Area O
1. New Shrine Construction
· Area P
1. Site Formation
2. Drainage Construction
· Area Q
1. Temporary Road Construction
2. Drainage Construction
3. Tree Transplant (2nd Pruning)
4. Storm Pipe (DN1650) Construction
5. Tree Felling
· Portion 1b
1. Assembly Yard for Bridge Construction
2. Storage Yard for Concrete Pipe
· Portion 3b
1. Sewerage Construction
· Portion 6c
1. Improvement of Junction
· Portion 9b
1. Rebar Yard
· Footbridge FB-4 (North)
1. Lift Tower Construction
2. ABWF Works
· Footbridge FB-4 (South)
1. Piling Works
2. ABWF Works
· Footbridge FB-5
1. Pier Head Construction
2. Lift Tower Construction
3. Sump Pit Construction
Works Contract No. ND/2024/05 and ND/2024/08:
· No construction work during the reporting period.
1.1.1.2
Environmental Monitoring and Audit Programme
A6.
The environmental monitoring activities,
including 1-hour Total Suspended Particulates (TSP) monitoring, 24-hour TSP
monitoring, noise monitoring, ecological survey, 24-hour Respirable Suspended
Particulates (RSP) (Ambient Arsenic) monitoring for land contamination and
environmental site inspection, were undertaken by Environmental Team (ET) under
Service Contract No. NDO 04/2019 (i.e. First Phase ET – Wellab) and under
Service Contract No. NDO 05/2024 (i.e. Remaining Phase ET - Aurecon) during the
reporting period in accordance with the approved Updated EM&A Manual. A
summary of the monitoring and audit activities during the reporting period is
presented in Table A3.
Table A3 Summary of
EM&A Activities in the Reporting Period
|
EM&A
Activities
|
Monitoring
Station(s)
|
Works
Contract(s)(5)
|
|
ND/2024/01
|
ND/2024/02
|
ND/2024/03
|
ND/2024/04
|
ND/2024/05
|
ND/2024/06
|
ND/2024/07
|
ND/2024/08
|
|
1-hour TSP Monitoring(1)
|
KTN-DMS1(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
KTN-DMS2(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
KTN-DMS3(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
KTN-DMS4(B)(2)(3)
|
6, 10, 16, 22, 28 April 2026
|
N/A
|
6, 10, 16, 22, 28 April
2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS1(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
1, 7, 13, 17, 23, 29 April
2026
|
N/A
|
|
FLN-DMS2(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS3(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS4(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS5(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
6, 10, 16, 22, 28 April
2026
|
N/A
|
|
FLN-DMS6(A)(2)(3)
|
N/A
|
N/A
|
2, 8, 14, 20, 25, 30
April 2026(6)
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS7(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
24-hour TSP Monitoring(1)
|
KTN-DMS1(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
KTN-DMS2(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
KTN-DMS3(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
KTN-DMS4(B)(2)(3)
|
6, 10, 16, 22, 28 April
2026
|
N/A
|
6, 10, 16, 22, 28 April
2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS1(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
6, 10, 16, 22, 28 April
2026
|
N/A
|
|
FLN-DMS2(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS3(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS4(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS5(A)(2)(3)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
6, 10, 16, 22, 28 April
2026
|
N/A
|
|
FLN-DMS6(A)(2)(3)
|
N/A
|
N/A
|
2, 8, 14, 20, 25, 30
April 2026(6)
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-DMS7(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Noise Monitoring(1)
|
CP-KTN-NMS1(2)
|
2, 8, 14, 20, 30 April 2026(6)
|
2, 8, 14, 20, 30 April 2026(6)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-KTN-NMS2(2)
|
10, 16, 22, 28 April 2026
|
10, 16, 22, 28 April 2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-KTN-NMS3(2)
|
10, 16, 22, 28 April 2026
|
10, 16, 22, 28 April 2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-KTN-NMS4(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-KTN-NMS5(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
10, 16, 22, 28 April 2026
|
N/A
|
N/A
|
|
CP-KTN-NMS6(2)
|
10, 16, 22, 28 April 2026
|
10, 16, 22, 28 April 2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-KTN-NMS7(2)
|
2, 8, 14, 20, 30 April 2026(6)
|
2, 8, 14, 20, 30 April 2026(6)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-FLN-NMS1(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
1, 10, 13, 23, 29 April
2026
|
N/A
|
|
CP-FLN-NMS3(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-FLN-NMS4(A)(2)(3)
|
N/A
|
N/A
|
N/A
|
9, 15, 21, 27 April 2026(6)
|
N/A
|
N/A
|
N/A
|
N/A
|
|
CP-FLN-NMS5(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
9, 15, 21, 27 April 2026(6)
|
N/A
|
|
CP-FLN-NMS6(2)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
9, 15, 21, 27 April 2026(6)
|
N/A
|
|
Ecological Monitoring (4)
|
Monitoring of Measures to Minimise
Disturbance to Water Birds on Ng Tung River, Sheung Yue River, and Long
Valley
|
Weekly Monitoring: 9, 10, 14, 17, 20, 23, 28, 30
April 2026 (Transect T1, T2, T3 and T5)
Additional Nighttime Monitoring at Long Valley:
20, 30
April 2026 (Transect T5)
|
Weekly Monitoring: 1, 8, 9, 10, 14,
16, 17, 20, 21, 22, 23, 28, 30 April 2026 (Transect T1, T2, T3, T4 and T5)
Additional Nighttime Monitoring at Long Valley:
20, 30
April 2026 (Transect T5)
|
Weekly Monitoring: 9, 10, 14, 17, 20, 23, 28, 30
April 2026 (Transect T1, T2, T3 and T5)
Additional Nighttime Monitoring at Long Valley:
20, 30
April 2026 (Transect T5)
|
Weekly Monitoring: 1, 8,
10, 14, 16, 21, 22, 28, 30 April 2026 (Transect T4)
|
N/A
|
Weekly Monitoring: 9, 10, 14, 17, 20, 23, 28, 30 April
2026 (Transect T1, T2 and T3)
|
Weekly Monitoring: 1, 8,
9, 10, 14, 16, 17, 20, 21, 22, 23, 28, 30 April 2026 (Transect T1, T2, T3 and
T4)
|
Weekly Monitoring: 1, 8,
9, 10, 14, 16, 17, 20, 21, 22, 23, 28, 30 April 2026 (Transect T1, T2, T3 and
T4)
|
|
Monitoring of Measures to Minimise
Impacts to Ma Tso Lung Stream and Siu Hang San Tsuen Stream
|
Monthly Monitoring: 22
April 2026 (MS_01 – MS_10)
|
Monthly Monitoring: 22
April 2026 (MS_01 – MS_10)
|
N/A
|
N/A
|
N/A
|
N/A
|
Monthly Monitoring: 22
April 2026 (MS_11 – MS_15)
|
Monthly Monitoring: 22
April 2026 (MS_11 – MS_15)
|
|
Monitoring of Measures to Minimise
Impacts on Ecological Sensitive Habitats from Disturbance and Pollution
|
Monthly Monitoring: 21
April 2026 (Transect T1)
|
Monthly Monitoring: 21
April 2026 (Transect T1 and T6)
|
Monthly Monitoring: 15
April 2026 (Transect
T4)
|
N/A
|
N/A
|
Monthly Monitoring: 23,
27 April 2026 (Transect
T2)
|
Monthly Monitoring: 15
April 2026 (Transect T3)
|
Monthly Monitoring: 15
April 2026 (Transect T3)
|
|
24-hour RSP (Ambient Arsenic)
Monitoring for Land Contamination (1)
|
KTN-DMS-4A(2)(3)
|
6, 10, 16, 22, 28 April
2026
|
N/A
|
6, 10, 16, 22, 28 April
2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Water Quality Monitoring(1)
|
KTN-IS1
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
KTN-CS1
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-IS1
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
FLN-CS1
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Landfill Gas Monitoring
|
250m Landfill Consultation Zone of
Ma Tso Lung Landfill
|
N/A(7)
|
N/A(7)
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Environmental Site Inspection
|
Site Area under Works Contract No.
ND/2024/01
|
2, 9, 16, 21, 28 April
2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Site Area under Works Contract No.
ND/2024/02
|
N/A
|
2, 9, 17, 21, 28 April
2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Site Area under Works Contract No.
ND/2024/03
|
N/A
|
N/A
|
8, 15, 20, 27 April 2026
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Site Area under Works Contract No.
ND/2024/04
|
N/A
|
N/A
|
N/A
|
2, 10, 17, 24, 30 April
2026
|
N/A
|
N/A
|
N/A
|
N/A
|
|
Site Area under Works Contract No.
ND/2024/06
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
9, 15, 21,
28 April 2026
|
N/A
|
N/A
|
|
Site Area under Works Contract No.
ND/2024/07
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
N/A
|
2, 9, 16, 23, 30 April
2026
|
N/A
|
Remarks:
(1)
For 1-hour and 24-hour TSP & 24-hour RSP
(Ambient Arsenic) monitoring, monitoring
stations that are specifically within the 500m buffer area projected from the
site boundary of works contract(s) will be considered being the representative monitoring stations for the
corresponding works contract(s) and the associated impact monitoring exercises
will be kicked off once the nearest works contracts have been commenced and
undertaken during the reporting period/month.
For
Noise Monitoring, monitoring stations that are specifically within the 300m
buffer area projected from the site boundary of works contract(s) will be
considered being the representative monitoring stations for the corresponding
works contract(s) and the associated impact monitoring exercises will be kicked
off once the nearest works contracts have been commenced and undertaken during
the reporting period/month.
(2)
New monitoring station
IDs are presented. The corresponding monitoring station IDs are as follows:
|
1-hour and 24-hour
TSP / 24-hour RSP (Ambient Arsenic)
KTN-DMS1 = DMS1
KTN-DMS2 = DMS2
KTN-DMS3 = DMS3
KTN-DMS4(A)/4(B) = DMS4
FLN-DMS1 = DMS7
FLN-DMS2 = DMS9
FLN-DMS3 = DMS11
FLN-DMS4 = DMS6
FLN-DMS5/5(A) = DMS8
FLN-DMS6(A) = DMS10
FLN-DMS7 = DMS5
|
Noise
CP-KTN-NMS1 = CP-NMS1
CP-KTN-NMS2 = CP-NMS2
CP-KTN-NMS3 = CP-NMS3
CP-KTN-NMS4 = CP-NMS5
CP-KTN-NMS5 = CP-NMS7
CP-KTN-NMS6 = N/A
CP-KTN-NMS7 = CP-NMS4
CP-FLN-NMS1 = CP-NMS10
CP-FLN-NMS3 = CP-NMS12
CP-FLN-NMS4(A) = CP-NMS6
CP-FLN-NMS5 = CP-NMS8
CP-FLN-NMS6 = CP-NMS9
|
(3)
Alternative monitoring
stations to the corresponding original monitoring stations.
(4)
The monitoring date for the
reporting month was conducted by the ET from the First Phase of KTN/FLN NDAs
Project, except Transect T4 for the ecological monitoring item Monitoring of Measures to Minimise
Disturbance to Water Birds on Ng Tung River, Sheung Yue River, and Long Valley,
and Transect T2 for the ecological monitoring item Monitoring of Measures to
Minimise Impacts on Ecological Sensitive Habitats from Disturbance and
Pollution. No ecological
monitoring was conducted for the Monitoring of Measures to Minimise Impacts to
Ma Tso Lung Stream and Siu Hang San Tsuen Stream for this reporting month as
this monitoring is only conducted during wet season (April – October). Detailed
divisions of work between First Phase ET and Remaining Phase can be referred to
Section 6 and relevant appendix.
(5)
N/A – No relevant
monitoring is required according to the approved updated EM&A Manual.
(6)
The monitoring date for the
reporting month was conducted by the ET from the Remaining Phase of KTN/FLN
NDAs Project.
(7)
As confirmed by the Supervisor Team, no ground
disturbance works were carried out in the work area within 250m Landfill
Consultation Zone of Ma Tso Lung Landfill including construction of the
infrastructure, development works, excavation works and works involve confined
spaces. Routine gas monitoring should be undertaken during groundwork
construction and in all excavations.
1.1.1.3
Breaches of Action Levels (AL) and Limit
Levels (LL)
A7.
Summary of the environmental exceedances of the
reporting period is tabulated in Table A4.
Table A4 Summary of
Exceedances in the Reporting Period
|
Environmental
Monitoring
|
Parameter(s)
|
No.
of Exceedances
|
Total
No. of
Exceedances
|
No.
of Non-project Related Exceedances
|
Total No. of Non-project Related
Exceedances
|
No. of Exceedances
Related to the Project
|
Total No. of Exceedances
Related to the Project
|
|
AL
|
LL
|
AL
|
LL
|
AL
|
LL
|
|
Air Quality
|
1-hour TSP
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
|
24-hourTSP
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
|
24-hour RSP
(Ambient Arsenic)
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
|
Noise
|
Leq(30mins)
|
3
|
0
|
3
|
3
|
0
|
3
|
0
|
0
|
0
|
|
Ecological Monitoring
|
Avifauna
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
|
Non-aquatic fauna
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
Air Quality
A8. No AL or LL exceedance was recorded for air
quality monitoring in the reporting period.
Noise
A9. Three AL exceedances for construction noise were recorded during the
reporting month, corresponding to three noise-related complaints received. No LL exceedance was recorded for construction noise monitoring in
the reporting period.
Ambient
Arsenic
A10. No AL or LL exceedance was recorded for ambient arsenic monitoring in
the reporting period.
Ecological Monitoring
A11. No AL or LL exceedance was recorded for ecological monitoring in the
reporting period.
Built Heritage Monitoring (Vibration
Monitoring)
A12. No exceedance of limits was recorded for vibration monitoring in the reporting period.
1.1.1.4
Complaint Log
A13. Total
of 5 complaints were received
during the reporting period.
A14.
The first environmental complaint was related to
construction dust and construction waste generated from FLN NDA construction
sites, particularly at Ma Sik Road on 8 April 2026 under works contract
ND/2024/07. The complaint was received by EPD on 8 April 2026 and referred to
CEDD, ET and IEC on 15 April 2026. The complaint case has been investigated by
the Contractor and ET, and the investigation was closed out on 22 April 2026. The
investigation findings indicate that there was no non-compliance by the
contractor.
A15.
The second environmental complaint was related
to construction noise generated from FLN NDA construction sites, particularly
at Po Shek Wu Road North Bound near Tai Tau Leng Village Vehicular Access on 22
April 2026 under works contract ND/2024/04. The complaint was received by 1823
on 22 April 2026 and referred to CEDD, ET and IEC on 24 April 2026. The
complaint case has been investigated by the Contractor and ET, and the
investigation was closed out on 03 May 2026. The investigation findings
indicate no non-compliance on conditions stipulated on the valid Construction
Noise Permit (CNP).
A16.
The third environmental complaint was related to
construction noise generated from FLN NDA construction sites, particularly at Po
Shek Wu Road North Bound near Tai Tau Leng Village Vehicular Access on 22 April
2026 under works contract ND/2024/04. The complaint was received by 1823 on 22
April 2026 and referred to CEDD, ET and IEC on 24 April 2026. The complaint
case has been investigated by the Contractor and ET, and the investigation was
closed out on 03 May 2026. The investigation findings indicate no non-compliance
on conditions stipulated on the valid Construction Noise Permit (CNP).
A17.
The fourth environmental complaint was related
to construction dust and noise generated from KTN construction sites,
particularly at Kwu Tung Yin Liu on 28 April 2026 under works contract ND/2024/03.
The complaint was received by EPD on 28 April 2026 and referred to CEDD, ET and
IEC on 28 April 2026. The complaint case has been investigated by the
Contractor and ET, and the investigation was closed out on 11 May 2026. The investigation
findings indicate that the complaint was not project related.
A18.
The fifth complaint was related to sand and
muddy water deposited on the carriageway caused by KTN construction sites,
particularly at Castle Peak Road between Sheung Pak Nai Sewage Pumping Station
and Pak Sau Road on 25 April 2026 under works contract ND/2024/03. The complaint
was received by EPD on 25 April 2026 and referred to CEDD, ET and IEC on 29
April 2026. The complaint case has been investigated by the Contractor and ET,
and the investigation was closed out on 11 May 2026. The investigation findings
indicate that there was no non-compliance by the contractor.
A19.
The details of the complaints and investigation results are shown in Appendix 12.1.
1.1.1.5
Notification of Summons and Successful
Prosecutions
A20.
No notification of summons or successful
prosecutions was received in the reporting period.
1.1.1.6
Reporting Changes
A21. There was no change to be reported that may affect the on-going
EM&A programme.
1.1.1.7
Future Key Issues
A22.
The major site activities for the next reporting
period are summarized below and shown in Appendix 1.1:
Works Contract No. ND/2024/01:
· All Site Resumption Area(s)
1. Tree survey
2. Site Clearance
· Portion III (3), IV (4), V (5) and XXXV (35)
1. Site Formation
· Portion VIII (8), XVI (16), XXXII (31) and LVIII (58)
1. Site Clearance & Demolition
· Portion XVIII (18), XXXVIII (38)
1. Excavation works
2. Construction of CHC Box Culvert
· Portion XI (11),
XXIII (23)
1. Formwork Erection, Rebar Fixing, Concreting Works
2. Erection of Substructure of Metropolis Community Liaison and Visitor
Centre
· Portion XL (40)
1. Retaining Wall Construction
2. Drainages System Construction
3. ELS work
· Portion LIX (59)
1. Treatment of High Arsenic-Containing Soil (HAS)
2. Erection of Shredding Facility
· Portion XVII (17), XVII (18), XXI (21), XXXIV (34), XXXV (35), XLI
(41), XLII (42)
1. Excavation Works
2. Drainage Pipe Installation
3. ELS Works
· Portion XXV (25), XXVII (27), XXXIII (33), XLII (42) and XLIV (44)
1. Site Clearance
2. Site Formation
3.
Construction of Box Culvert
Works Contract No. ND/2024/02:
1. Site
clearance in Area A, B, C, D, T, L
2. Site formation works in Area D
3. Temporary storage fill bank in Kwu Tung Grass
Soccer Pitch
4. Demolition works for Community Sports in Area
J
5. Ground Investigation Works in Area B & L
6. Asbestos Removal Works in Area C
Works Contract No. ND/2024/03:
Fanling Highway
& Castle Peak Road area
· Pak Sau Road – Po Lau Road
1. Relocation/Reprovision/Removal of Existing TCSS, Fire Hydrant,
Signage & Streetlighting
2. Tree Works
· Po Lau Road – Sheung Yue River
1. Asbestos Removal Works at Portion IX
2. Box Culvert Bay 37 – Bay 42 ELS
· TTA Stage 1 Works
1. Tree Works
2. Removal or relocation of
directly impacted Shrine/historical building at HKT08 & KT72
3. Demolish of Central Divider & Barrier along FL Highway E/B
New Tsung Pak
Long Road
· Box culvert Bay 10 to 12, 14 to 16 Drainage/Watermains
1. Drainage, Sewerage & Watermain with Backfilling at Box Culvert
Bay 15 & 16
2. Box Culvert Bay 10-13 & 14 ELS
3. Removal of ELS and Temp Road Diversion
· Box culvert Bay 17 to 19 & Drainage/Watermains
1. Box Culvert Bay 17 to 19 ELS, Base Slab, Wall and Top Slab
· TTA Stage 1B
1. Box Culvert Bay 3, 5 to 7, 7A ELS
2. Box Culvert Base Slab
· Retaining Wall RW05A
1. RW05A ELS
2. Base Slab and Wall
· Kwu Tung Road Bridge
1. Site Clearance and Tree Works
2. Site formation and cutback the existing slope
3. Foundation & Piling
· Works Areas – WA1, WA2, WA3, WA4 & WA5
1. Temporary Drainage
2. Asbestos removal
Fanling Highway
Cross River Bridge (along Sheung Yue River)
· Portion XI – East Abutment & pier foundation (No works at wet season between 1 Apr 2026 and 31 Oct 2026)
1. Trial Pits for UUs
2. Piling Works
· Road L3 Viaduct
1. Piling Works
2. Pile Cap L3A-02
Kwu Tung
Interchange Foundation & Substructure
· Bridge B1 & C1
1. Piling Works
2. ELS
· Bridge B2 & C2
1. Piling Work
· Footbridges No. 4 at TTA Stage 1
1. Ground Investigation
2. Underground Utilities Works
3. Piling
· Footbridges No. 5 at TTA Stage 2
1. Predrilling
· Widening of Existing Bridge No.N526
1. Tree Works
2.
Pilling
Works Contract No. ND/2024/04:
1. Site Clearance
2. Site Establishment
3. Tree Felling
4. Trial Pit
5. Existing Sewage Diversion
6.
Haul Road Construction
7. Bored Piling
8. ELS Construction
9. Slope Works
10.Road Diversion Works
11.Demolition of Existing Structures
Works Contract No. ND/2024/06:
· Portion A
1. Excavation to +84 mPD of Portion A
2. Carry Out Soil Nail of Portion A
· Portion C, D, E & F
1.
Trench and Watermans
Laying Works
· Area N
1. Jacking Pit Excavation
·
Pre-boring of Pit B &
C
Works Contract No. ND/2024/07:
1. Site Clearance
2. Site Formation
3. Ground Investigation
4. Pre-bored Socketed H Pile
Construction
5. Bridge Construction
6. Bridge Deck Connection (Footbridge
FB5)
7. Lift Tower Construction
8. Sump Pit Construction
9. ABWF Works
10.Drainage Construction
11.Improvement of Junction
12.Road Construction
13.Temporary Road Construction
14.Open Landscaping Works
15.Tree Felling & Transplantation
16.Asbestos Containing Materials Survey &
Removal
17.Land Contamination (Environmental Ground
Investigation)
18.Internal Movement, Importation &
Exportation of C&D materials
19.Sewerage Construction
20. Old Shrine Removal and New Shrine
Construction
21. Storm pipe Construction
22. Box Culvert Construction
23.Temporary Drainage Diversion
24. Rebar Yard
25.Storage Yard for Concrete Pipe
Works Contract No. ND/2024/05 and ND/2024/08:
1. The construction work has not commenced in the
reporting month.
1
Introduction
1.1
Project Background
1.1.1
The Kwu Tung North and
Fanling North New Development Areas (KTN and FLN NDAs)
development are implemented in two phases, comprising First Phase and Remaining
Phase developments. The construction works for the First Phase
development commenced in December 2019. The construction works for the
Remaining Phase development (the Project), including site clearance and formation, roads, drainage, sewerage
and water supply systems, commenced progressively from the January 2025.
1.1.2 The Project is delivered under eight (8) Works Contracts as below.
·
Contract No. ND/2024/01: Site Formation and
Infrastructure Works (South);
·
Contract No. ND/2024/02: Site Formation and
Infrastructure Works (North);
·
Contract No. ND/2024/03: Improvement Works of
Fanling Highway (Kwu Tung Portion) and Associated Works;
·
Contract No. ND/2024/04: Improvement Works of
Tai Tau Leng Roundabout and Po Shek Wu Road and Associated Works;
·
Contract No. ND/2024/05: Improvement Works of
Fanling Highway (Pak Shek Au Portion) and Associated Works;
·
Contract No. ND/2024/06: Fresh Water and
Flushing Water Service Reservoirs and Associated Works;
·
Contract No. ND/2024/07: Site Formation and
Infrastructure Works (East); and
·
Contract No. ND/2024/08: Site Formation and
Infrastructure Works (West).
1.1.3
The EIA Report (AEIAR-175/2013) for NENT NDA was
approved with conditions under EIAO in 2013. The Environmental Permits for
corresponding Designated Projects were also issued by DEP in November 2013.
Subsequent to the findings of preliminary design and P&E Review for
accommodating additional population in KTN and FLN NDAs, VEP were subsequently
applied for eight EPs under the Project (i.e. EP-465/2013/A, EP-466/2013/A,
EP-467/2013/A, EP-468/2013/A, EP-470/2013/A, EP-471/2013/A, EP-472/2013/A and
EP-476/2013).
1.1.4 Aurecon was commissioned by Civil
Engineering and Development Department (CEDD) to
provide EM&A services for the works contracts in relation to the Project
pursuant to the requirements as specified in relevant EPs, the EM&A Manual
issued in the EIA stage, the Updated EM&A Manual prepared for Contract No.
NDO 14/2018 and the approved EIA Report for the Project to discharge the duties
of the ET for the Project.
1.1.5 This is the 16th Monthly EM&A Report summarizing the
findings of EM&A works at Works Contract No. ND/2024/01 under the Project with
EP-467/2013/A and EP-468/2013/A, Works Contract No. ND/2024/02 under the
Project with EP-467/2013/A and EP-468/2013/A, Works Contract No. ND/2024/03
under the Project with EP-465/2013/A, EP-466/2013/A and EP-467/2023/A, Works
Contract No. ND/2024/04 under the Project with EP-465/2013/A and EP-471/2013/A,
Works Contract No. ND/2024/06 under Environmental Permit No. EP-470/2013/A and
for Contract No. ND/2024/07 under Environmental Permit No. EP-476/2013 during
the reporting period from 1 to 30 April 2026. No construction works occur in
the remaining contracts during the reporting period for Contract No. ND/2024/05
and ND/2024/08.
Table 1.1 Parties
Involved in Project Organization for all Works Contracts
|
|
Works
Contract(s)
|
|
Parties
|
ND/2024/01
|
ND/2024/02
|
ND/2024/03
|
ND/2024/04
|
ND/2024/05
|
ND/2024/06
|
ND/2024/07
|
ND/2024/08
|
|
Project Proponent
|
CEDD
|
|
Supervisor / Engineer’s
Representative (ER)
|
AECOM Asia Co. Ltd.
|
AECOM Asia Co. Ltd.
|
AECOM Asia Co. Ltd
|
AECOM Asia Co. Ltd
|
AECOM Asia Co. Ltd
|
Binnies Hong Kong Limited
|
AtkinsRéalis
|
AtkinsRéalis
|
|
Contractor
|
Build King - Richwell
Engineering Joint Venture
|
Build King –
Richwell Civil Joint Venture
|
China State - STEC Joint
Venture
|
CW – CRCC (ND202404) Joint
Venture
|
Lanon – Sinohydro – Excel JV
|
Wo Hing-Tsun Yip Joint
Venture
|
Build King – Richwell Civil
Joint Venture
|
Gammon - STEC Joint Venture
|
|
ET
|
Aurecon Hong Kong Limited
|
|
Independent Environmental
Checker (IEC)
|
Mott MacDonald Hong Kong
Limited
|
|
|
|
|
|
|
|
|
|
|
Works Contract No. ND/2024/01:
· All Site Resumption Area(s)
1. Tree survey
2. Site Clearance
· Portion III (3), IV (4), V (5), VII (7) and XXXV (35)
1. Site Formation
· Portion XVIII (18),
XXXVIII (38)
1. Site Clearance
2. Excavation Works
3. Construction of CHC Box Culvert
· Portion VI (6)
1. Site Clearance
2. Excavation Works
· Portion VIII (8)
1. Site Clearance &
Demolition
2. Asbestos Abatement Works
· Portion XI (11), XXIII (23)
1. Formwork Erection, Rebar Fixing, Concreting Works
· Portion XII (12), XV (15), XXX (30), XXXI (31) and XLIV(44)
1. Site Clearance
· Portion XVI (16), XLII (42), LI (51) and LIII (53)
1. Site Clearance and Demolition
· Portion XL (40)
1. Retaining Wall Construction
2. Drainages System Construction
3. ELS work
· Portion LIX (59)
1. Treatment of High Arsenic-Containing Soil (HAS)
· Portion XVII (17), XVII (18), XXI (21), XXXIV (34), XXXV (35), XLI
(41), XLII (42)
1. Excavation works
2. Drainage Pipe Installation
3. ELS Works
· Portion XXV (25), XXVII (27), XXXII (33) and XLII (42)
1. Site Clearance
2. Site Formation
3. Construction of Box Culvert
Works Contract No. ND/2024/02:
· Site clearance in Area A, B, C, D, T, L
· Site formation works in Area D
· Temporary storage fill bank in Kwu Tung Grass Soccer Pitch
· Demolition works for Community Sports in Area J
· Ground Investigation Works in Area B & L
Works Contract No. ND/2024/03:
Fanling
Highway & Castle Peak Road area
· Pak Sau Road – Po Lau Road
1. Tree Works
2. Relocation/Reprovision/removal of existing TCSS, fire hydrant,
signage & streetligting
· Po Lau Road – Sheung Yue River
1. Asbestos Removal Works at Portion IX
2. Box Culvert Bay 37 – Bay 42 ELS
3. Tree Works
· TTA Stage 1 Works
1. Tree Works
2. Relocation/Reprovision/removal of existing TCSS, Fire Hydrant,
Telecom post, High Voltage Post, Signage & Streetligting
New Tsung Pak
Long Road
1. Box culvert Bay 10 to 12, 14 to 16 Drainage/Watermains
2. Drainage, Sewerage & Watermain with Backfilling at Box Culvert
Bay 15 & 16
3. Box Culvert Bay 14 ELS
· Box culvert Bay 17 to 19 & Drainage/Watermains
1. Box Culvert Bay 17 to 19 ELS, Base Slab, Wall and Top Slab
2. Box culvert Bay 17 & 19 Base Slab
· Retaining Wall RW01
1. Pre-drilling
· Retaining Wall RW05A
1. RW05A Bay 12, 14 & 16 Base Slab
2. RW05A Bay 12, 14 & 16 Wall
· Kwu Tung Road Bridge
1. Site Clearance and Tree Works
2. Site formation and cutback the existing slope
3. Predrilling
4. Foundation & Piling
· Works Areas – WA1, WA2, WA3, WA4 & WA5
1. Site Formation at PM’s Site Office
2. Site Clearance, haul road and Temporary Drainage
3. Asbestos removal
Fanling Highway
Cross River Bridge (along Sheung Yue River)
· Portion XI – East Abutment & pier foundation
1. Trial Pits for UUs
2. Piling Works
· Road L3 Viaduct
1. Piling Works
2. Pile Cap L3A-02
· Kwu Tung Interchange Foundation & Substructure - Bridge B1 &
C1
1. Piling Works
· Widening of Existing Bridge No.N526
1. Tree Works
2. Pre-drilling
3. Piling
Works Contract No. ND/2024/04:
· Site Clearance
· Site Establishment
· Tree Felling
· Trial Pit
· Ground Investigation
· Existing Sewage Diversion
· Demolition of Existing Structures
· Haul Road Construction
· Bored Piling
· ELS Construction
· Slope Works
Works Contract No. ND/2024/06:
· Portion A
1. Excavation to +84 mPD of Portion A
2. Carry Out Soil Nail of Portion A
· Portion C, Portion D, Portion E and Portion F
1. Trench and Watermains Laying Works
· Portion D
1. Trench and Watermains Laying Works
2. Demolition of DN2000 Associated Thrust Blocks of Portion D
· Pit B and Pit C
1. Pre-boring
Works
Contract No. ND/2024/07:
· Area C
1. Tree Felling
2. Site Formation
· Area D and Area E
1. Site Formation
2. Asbestos Removal
· Area F
1. Tree Felling
· Area G
1. Site Clearance
2. Site Formation
3. Asbestos Removal
· Area H, Area I and Area R
1. Asbestos Removal
· Area J
1. Road Construction
· Area K
1. Sewerage (DN1350) Construction
2. Road Construction
3. Site Clearance
· Area O
1. New Shrine Construction
· Area P
1. Site Formation
2. Drainage Construction
· Area Q
1. Temporary Road Construction
2. Drainage Construction
3. Tree Transplant (2nd Pruning)
4. Storm Pipe (DN1650) Construction
5. Tree Felling
· Portion 1b
1. Assembly Yard for Bridge Construction
2. Storage Yard for Concrete Pipe
· Portion 3b
1. Sewerage Construction
· Portion 6c
1. Improvement of Junction
· Portion 9b
1. Rebar Yard
· Footbridge FB-4 (North)
1. Lift Tower Construction
2. ABWF Works
· Footbridge FB-4 (South)
1. Piling Works
2. ABWF Works
· Footbridge FB-5
1. Pier Head Construction
2. Lift Tower Construction
3. Sump Pit Construction
Works Contract No. ND/2024/05 and ND/2024/08:
· No construction work during the reporting period.
Table 1.2 Status of Environmental License, Notifications and Permits for Works Contract No. ND/2024/01
|
Permit / License Name/No.
|
Valid Period
|
Status
|
|
From
|
To
|
|
Environmental Permit
|
|
EP-467/2013/A
|
27/01/2017
|
N/A
|
Valid
|
|
EP-468/2013/A
|
27/01/2017
|
N/A
|
Valid
|
|
Notification pursuant to Air Pollution Control
(Construction Dust) Regulation
|
|
10008709
|
02/09/2024
|
N/A
|
Valid
|
|
Billing Account for Disposal of Construction Waste
|
|
7052236
|
20/09/2024
|
N/A
|
Valid
|
|
Registration of Chemical Waste Producer
|
|
WPN: 5213-548-B2781-01
|
06/12/2024
|
N/A
|
Valid
|
|
Effluent Discharge License under Water Pollution
Control Ordinance
|
|
WT00045924-2024
|
15/01/2025
|
31/01/2030
|
Valid
|
|
WT00046627-2025
|
03/06/2025
|
30/06/2030
|
Valid
|
|
WT00046736-2025
|
10/06/2025
|
30/06/2030
|
Valid
|
|
WT00046982-2025
|
03/10/2025
|
31/10/2030
|
Valid
|
|
WT00047583-2025
|
19/01/2026
|
31/01/2031
|
Valid
|
|
WT00048070-2025
|
28/01/2026
|
31/01/2031
|
Valid
|
|
WT00048369-2026
|
14/04/2026
|
30/04/2031
|
Valid
|
|
Construction Noise Permit (CNP)
|
|
|
|
|
GW-RN0390-26
|
26/03/2026
|
25/07/2026
|
Valid
|
|
GW-RN1593-25
|
04/01/2026
|
30/06/2026
|
Valid
|
|
GW-RN0041-26
|
16/01/2026
|
15/04/2026
|
Valid until 15/04/2026
|
|
GW-RN0254-26
|
27/02/2026
|
26/05/2026
|
Valid
|
|
GW-RN0166-26
|
08/02/2026
|
07/05/2026
|
Valid
|
|
GW-RN0512-26
|
20/04/2026
|
19/07/2026
|
Valid
|
Table 1.3 Status of Environmental License, Notifications and Permits for Works Contract No. ND/2024/02
|
Permit / License Name/No.
|
Valid Period
|
Status
|
|
From
|
To
|
|
Environmental Permit
|
|
EP-467/2013/A
|
27/01/2017
|
N/A
|
Valid
|
|
EP-468/2013/A
|
27/01/2017
|
N/A
|
Valid
|
|
Notification pursuant to Air Pollution Control
(Construction Dust) Regulation
|
|
10024940
|
23/12/2025
|
N/A
|
Valid
|
|
Billing Account for Disposal of Construction Waste
|
|
7057203
|
05/01/2026
|
N/A
|
Valid
|
|
Registration of Chemical Waste Producer
|
|
WPN:5213-545-B2803-01
|
11/02/2026
|
N/A
|
Valid
|
|
Effluent Discharge License under Water Pollution
Control Ordinance
|
|
WT00048304-2026
|
18/03/2026
|
31/03/2031
|
Valid
|
|
Application Ref. No.10027555
|
Applied on 11/03/2026
|
N/A
|
Under application
|
|
Construction Noise Permit (CNP)
|
|
|
|
|
Application Ref. No.10029112
|
Applied on 20/04/2026
|
N/A
|
Under application
|
Table 1.4 Status of Environmental License, Notifications and Permits for Works Contract No. ND/2024/03
|
Permit / License Name/No.
|
Valid Period
|
Status
|
|
From
|
To
|
|
Environmental Permit
|
|
EP-465/2013/A
|
20/01/2017
|
N/A
|
Valid
|
|
EP-466/2013/A
|
18/08/2022
|
N/A
|
Valid
|
|
EP-467/2013/A
|
27/01/2017
|
N/A
|
Valid
|
|
Notification pursuant to Air Pollution Control
(Construction Dust) Regulation
|
|
10008101
|
15/08/2024
|
N/A
|
Valid
|
|
Billing Account for Disposal of Construction Waste
|
|
7052008
|
21/08/2024
|
N/A
|
Valid
|
|
Registration of Chemical Waste Producer
|
|
WPN:5213-548-C5047-01
|
22/01/2025
|
N/A
|
Valid
|
|
Effluent Discharge License under Water Pollution
Control Ordinance
|
|
WT00046044-2025
|
07/11/2025
|
28/02/2030
|
Valid
|
|
Construction Noise Permit (CNP)
|
|
|
|
|
GW-RN0243-26
|
19/03/2026
|
18/06/2026
|
Valid
|
|
GW-RN0398-26
|
03/04/2026
|
02/07/2026
|
Valid
|
Table 1.5 Status of Environmental License, Notifications and Permits for Works Contract No. ND/2024/04
|
Permit / License Name/No.
|
Valid Period
|
Status
|
|
From
|
To
|
|
Environmental Permit
|
|
EP-465/2013/A
|
20/01/2017
|
N/A
|
Valid
|
|
EP-471/2013/A
|
10/10/2022
|
N/A
|
Valid
|
|
Notification pursuant to Air Pollution Control
(Construction Dust) Regulation
|
|
10012919
|
06/01/2025
|
N/A
|
Valid
|
|
Billing Account for Disposal of Construction Waste
|
|
7053746
|
13/02/2025
|
N/A
|
Valid
|
|
Registration of Chemical Waste Producer
|
|
WPN:5213-626-C5043-01
|
28/01/2025
|
N/A
|
Valid
|
|
Effluent Discharge License under Water Pollution
Control Ordinance
|
|
WT00047165-2025
|
15/12/2025
|
31/08/2030
|
Valid
|
|
WT00048247-2026
|
18/03/2026
|
31/03/2031
|
Valid (Variation of WT00048247-2026 was
applied on 15 April 2026)
|
|
Construction Noise Permit (CNP)
|
|
|
|
|
GW-RN1510-25
|
01/01/2026
|
30/04/2026
|
Valid
|
|
GW-RN0230-26
|
24/02/2026
|
31/05/2026
|
Valid
|
|
GW-RN0251-26
|
28/02/2026
|
27/05/2026
|
Valid
|
|
GW-RN0201-26
|
01/03/2026
|
31/05/2026
|
Valid
|
|
GW-RN0205-26
|
01/03/2026
|
31/05/2026
|
Valid
|
|
GW-RN0381-26
|
24/03/2026
|
23/07/2026
|
Valid
|
|
GW-RN0426-26
|
01/04/2026
|
30/06/2026
|
Valid
|
|
GW-RN0402-26
|
03/04/2026
|
02/07/2026
|
Valid
|
|
GW-RN0401-26
|
03/04/2026
|
02/07/2026
|
Valid
|
|
GW-RN0461-26
|
07/04/2026
|
06/07/2026
|
Valid
|
Table 1.6 Status of Environmental License, Notifications and Permits for Works Contract No. ND/2024/06
|
Permit / License Name/No.
|
Valid Period
|
Status
|
|
From
|
To
|
|
Environmental Permit
|
|
EP-470/2013/A
|
13/05/2022
|
N/A
|
Valid
|
|
Notification pursuant to Air Pollution Control
(Construction Dust) Regulation
|
|
10007695
|
06/08/2024
|
N/A
|
Valid
|
|
Billing Account for Disposal of Construction Waste
|
|
7051899
|
28/08/2024
|
N/A
|
Valid
|
|
Registration of Chemical Waste Producer
|
|
WPN:5213-624-W3824-01
|
04/09/2024
|
N/A
|
Valid
|
|
Effluent Discharge License under Water Pollution
Control Ordinance
|
|
WT00046560-2025
|
15/05/2025
|
31/05/2030
|
Valid
|
|
WT00046847-2025
|
11/07/2025
|
31/07/2030
|
Valid
|
|
WT00046588-2025
|
29/05/2025
|
31/05/2030
|
Valid
|
|
Construction Noise Permit (CNP)
|
|
|
|
|
GW-RN1439-25
|
29/12/2025
|
28/04/2026
|
Valid until 28/04/2026
|
Table 1.7 Status of Environmental License, Notifications and Permits for Works Contract No. ND/2024/07
|
Permit / License Name/No.
|
Valid Period
|
Status
|
|
From
|
To
|
|
Environmental Permit
|
|
EP-476/2013
|
21/11/2013
|
N/A
|
Valid
|
|
Notification pursuant to Air Pollution Control
(Construction Dust) Regulation
|
|
10007874
|
09/08/2024
|
N/A
|
Valid
|
|
Billing Account for Disposal of Construction Waste
|
|
7051974
|
20/08/2024
|
N/A
|
Valid
|
|
Registration of Chemical Waste Producer
|
|
WPN:5213-625-B2775-01
|
19/08/2024
|
N/A
|
Valid
|
|
Effluent Discharge License under Water Pollution
Control Ordinance
|
|
WT00045532-2024
|
10/12/2024
|
31/12/2029
|
Valid
|
|
WT00046059-2025 (Part 1)
|
17/06/2025
|
28/02/2030
|
Valid
|
|
WT00046059-2025 (Part 2)
|
17/06/2025
|
28/02/2030
|
Valid
|
|
WT00046342-2025
|
15/05/2025
|
31/05/2030
|
Valid
|
|
WT00046692-2025
|
29/05/2025
|
31/05/2030
|
Valid
|
|
WT00046655-2025
|
03/06/2025
|
30/06/2030
|
Valid
|
|
WT00046819-2025
|
31/07/2025
|
31/07/2030
|
Valid
|
|
WT00047343-2025
|
29/09/2025
|
30/09/2030
|
Valid
|
|
WT00047250-2025
|
12/11/2025
|
30/11/2030
|
Valid
|
|
WT00048473-2026
|
17/04/2026
|
30/04/2031
|
Valid
|
|
WT00048492-2026
|
30/04/2026
|
30/04/2031
|
Valid
|
|
Construction Noise Permit (CNP)
|
|
|
|
|
GW-RN1224-25
|
01/11/2025
|
30/04/2026
|
Valid
|
|
GW-RN1473-25
|
12/12/2025
|
31/05/2026
|
Valid
|
|
GW-RN0069-26
|
19/01/2026
|
18/06/2026
|
Valid
|
|
GW-RN0168-26
|
18/02/2026
|
17/06/2026
|
Valid
|
|
GW-RN0179-26
|
23/02/2026
|
22/08/2026
|
Valid
|
2.1.1
In
accordance with the EM&A Manual, the approved updated EM&A Manual for
the First Phase, the ET shall carry out impact monitoring during the
construction phase of the Project. 1-hour and 24-hour TSP to monitor the air
quality for the Works Contacts.
2.1.2
Impact
1-hour TSP monitoring was conducted for at least three times every 6 days,
while the impact 24-hour TSP monitoring was conducted for at least once every 6
days at the designated air quality monitoring stations.
2.2.1 According to the EM&A Manual, the
approved updated EM&A Manual for the First Phase, the designated locations
for impact air quality monitoring in related to the work contracts in the reporting
period are listed in Table 2.1 and their locations are shown in Figure
2.1 and Figure 2.2.
Table 2.1 Summary of
Impact Air Quality Monitoring Stations in related to the Works Contracts in the
Reporting Period
|
Monitoring Station(s)
|
Works Contract(s)
|
ASR ID in EIA
|
Planned(3) or Existing
|
Monitoring Location(s)
|
|
KTN-DMS1
|
ND/2024/01,
ND/2024/02,
ND/2024/03
|
KTN-19
|
Planned
|
Nursery Classes and Kindergarten; Post
Offices
|
|
KTN-DMS2
|
ND/2024/01,
ND/2024/02
|
KTN-90
|
Planned
|
Nursery Classes and Kindergarten (2 nos); District
Elderly Community Centre
|
|
KTN-DMS3
|
ND/2024/01,
ND/2024/02,
ND/2024/03
|
KTN-326
|
Planned
|
Village Resite
|
|
KTN-DMS4(B)(1)(2)
|
ND/2024/01,
ND/2024/03
|
KTN-E70
|
Existing
|
Temporary Structure at Pak Shek Au
|
|
FLN-DMS1
|
ND/2024/07
|
FLN-E62
|
Existing
|
Scattered Village Houses North of Proposed
Potential Ecopark
|
|
FLN-DMS2
|
ND/2024/06, ND/2024/07
|
FLN-E243
|
Planned
|
Residential Building, Nursery Classes and
Kindergartens, Neighbourhood Elderly Community Centre, Residential Home for
the Elderly, Post Office
|
|
FLN-DMS5, FLN-DMS5(A)
|
ND/2024/07
|
FLN-E124
|
Existing
|
Noble Hill / Good View New Village
|
|
FLN-DMS6(A)
|
ND/2024/03,
ND/2024/04
|
DMS-10
|
Existing
|
Choi Ngan House, Choi Po Court
|
|
FLN-DMS7
|
ND/2024/06, ND/2024/07
|
FLN-20
|
Planned
|
Planned premise for Weapon Training
Division
|
Remarks:
(1) KTN-DMS4(B) is the alternative air
monitoring stations proposed to replace KTN-DMS4.
(2) As KTN-DMS4 - Temporary structure near
Fanling Highway (near Pak Shek Au) is no longer as existing ASR, air quality
monitoring station should be relocated to the alternative dust monitoring
location according to the updated EM&A Manual, Section 2.6.2. According to
Figure 3.1 of Approved EIA report and site visits conducted in June 2022, ASR
at near KTN-E70 – Temporary Structure near Fanling Highway near Pak Shek Au is
considered as the most representative alternative station KTN-DMS4(B) for air
quality monitoring for KTN-DMS4 (i.e. KTN-E162).
(3) Impact monitoring will be carried out when
the planned sensitive receivers are commissioned.
2.3.1
In
accordance with the requirements for placement of equipment, as set out of the EM&A
Manual of the Project, the approved updated EM&A Manual for the First
Phase, the monitoring parameter, frequency and duration of impact air quality
monitoring are listed in Table
2.2.
Table 2.2 Parameters
Measured in the Impact Air Quality Monitoring
|
Parameter(s)
|
Frequency(1)(2)
|
|
1-hour TSP
|
Three times / 6 days
|
|
24-hour TSP
|
Once / 6 days
|
Remarks:
(1) The air quality monitoring (1-hour and
24-hour TSP) was conducted by First Phase ET during the reporting period.
(2) The air quality monitoring (1-hour and
24-hour TSP) was conducted by Remaining Phase ET during the reporting period.
2.4.1
Direct
reading dust meters and High-Volume TSP Samplers were used for measuring the
impact air quality monitoring (i.e. 1-hour TSP and 24-hour TSP) during the reporting
period in accordance with the Service Contract No. NDO 04/2019 Monthly EM&A
Report. According to Section 2.4.5 of the EM&A Manual, the approved
updated EM&A Manual for First Phase ET, the proposed use of direct reading
dust meter was submitted to and agreed by the First Phase IEC. HVS for 24-hour
TSP monitoring will be adopted once secured supply of electricity become
available at FLN-DMS5(A) and KTN-DMS4(B).
2.4.2
Table 2.3 summarizes the
equipment used in the air quality monitoring programme. Copies of the
calibration certificates for air quality monitoring equipment are shown in Appendix 2.2.
|
Monitoring
Station(s)
|
Equipment
|
Model
|
Manufacturer
|
Quantity
|
|
KTN-DMS4(B)(1), FLN-DMS5(1),
FLN-DMS5(A)(1)
|
Dust Monitor
(1-hour and 24-hour TSP)
|
AEROCET-831
|
Met One Instruments
|
8
|
|
FLN-DMS1(1)
|
Dust Monitor
(1-hour TSP)
|
|
HVS Sampler
(24-hour TSP)
|
TE-5170
|
Tisch
|
1
|
|
FLN-DMS6(A)(2)
|
Dust Monitor
(1-hour and 24-hour TSP)
|
LD-5R
|
Sibata
|
1
|
Table 2.3 Air Quality Monitoring
Equipment
Remarks:
(1) The air quality monitoring (1-hour and
24-hour TSP) was conducted by First Phase ET during the reporting period.
(2) The air quality monitoring (1-hour and
24-hour TSP) was conducted by Remaining Phase ET during the reporting period.
2.5
Monitoring Methodology and QA/QC Procedure
2.5.1
Direct
reading dust meter was deployed for the air quality monitoring as shown in Table 2.3.
Instrumentation
(AEROCET-831)
2.5.2
The
measuring procedures of the dust meters were in accordance with the
Manufacturer’s Instruction Manual as follows:
· Place the dust meter at least 1.3 meters above
ground;
· Press and hold the Power key momentarily to
power on the unit and make sure that the battery level was not flash or in low
level;
· Allow the instrument to stand for about 3
second to display the Sample Screen minutes;
· Press the START / STOP key to run the internal
vacuum pump for 1 minute and be ready to use;
· Use the select dial to select the PM range and
press the START / STOP key to start a measurement;
· Finally, push the START/STOP key to stop the
measurement after 24-hour sampling;
· Information such as sampling date, time, value
and site condition were recorded during the monitoring period; and
· All data were recorded in the data logger for
further data processing.
Maintenance/Calibration
2.5.3
The
following maintenance/calibration was required for the HVS:
·
Check and calibrate the
meters by High Volume Sampler (HVS) to check the validity and accuracy of the
results measured by direct reading method at 2-month intervals throughout all
stages of the air quality monitoring.
Instrumentation
(TISCH Model: TE-5170 / TE-5170X)
2.5.4
The
following guidelines were adopted during the installation of HVS:
·
A horizontal platform with
appropriate support was provided to secure the samplers against gusty wind. the
dust meter at least 1.3 meters above ground;
·
No two samplers were
placed less than 2 metres apart.
·
The distance between the
sampler and an obstacle, such as buildings, was at least twice the height that
the obstacle protrudes above the sampler.
·
A minimum of 2 metres of
separation from walls, parapets and penthouses was required for rooftop
samples.
·
A minimum of 2 metres
separation from any supporting structure, measured horizontally was required.
·
No furnaces or
incineration flues were nearby.
·
Airflow around the sampler
was unrestricted.
·
The sampler were more than
20 metres from the drip line.
·
Any wire fence and gate,
to protect the sampler, should not cause any obstruction during monitoring.
·
Permission and access to
monitoring stations have been obtained to set up the samplers.
·
A secured supply of
electricity was provided to operate the samplers.
Filters Preparation
2.5.5
Wellab
Limited (HOKLAS Registration No. HOKLAS083) is a HOKLAS accredited laboratory
and responsible for the preparation of 24-hour conditioned and pre-weighed
filter papers for the monitoring team.
2.5.6
All filters
were equilibrated in the conditioning environment for 24 hours before weighing.
The conditioning environment temperature was around 25°C and not variable by
more than ±3°C; the relative humidity (RH) was < 50% and not variable by
more than ±5%. A convenient working RH was 40%.
Operating/Analytical
Procedures
2.5.7
Operating/analytical
procedures for the air quality monitoring were highlighted as follows:
·
Prior to the commencement
of dust sampling, the flow rate of the HVS was properly set (between 1.1 m3
/min. and 1.4 m3 /min.) in accordance with the manufacturer's
instruction to within the range recommended in USEPA Standard Title 40, CFR
Part 50;
·
The power supply was
checked to ensure the sampler worked properly;
·
On sampling, the sampler
was operated for 5 minutes to establish thermal equilibrium before placing any
filter media at the designated air quality monitoring station;
·
The filter holding frame
was then removed by loosening the four nuts and carefully a weighted and
conditioned filter was centered with the stamped number upwards, on a
supporting screen;
·
The filter was aligned on
the screen so that the gasket formed an airtight seal on the outer edges of the
filter. The filter holding frame was then tightened to the filter holder with
swing bolts. The applied pressure should be sufficient to avoid air leakage at
the edges;
·
The shelter lid was closed
and secured with the aluminium strip;
·
The timer was then
programmed. Information was recorded on the record sheet, which included the
starting time, the weather condition and the filter number (the initial weight
of the filter paper can be found out by using the filter number);
·
After sampling, the filter
was removed and kept in a clean and tightly sealed plastic bag. The filter
paper was then returned to the HOKLAS accredited laboratory (Wellab Ltd.) for
reconditioning in the humidity-controlled chamber followed by accurate weighting
by an electronic balance with a readout down to 0.1mg. The elapsed time was
also recorded; and
·
Before weighing, all
filters were equilibrated in a conditioning environment for 24 hours. The
conditioning environment temperature should be between 25°C and 30°C and did
not vary by more than ±3°C; the RH should be < 50% and did not vary by more
than ±5%. A convenient working RH is 40%. Weighing results were returned for
further analysis of TSP concentrations collected by each filter
Maintenance/Calibration
2.5.8
The
following maintenance/calibration was required for the HVS:
·
The high-volume motors and
their accessories were properly maintained. Appropriate maintenance such as
routine motor brushes replacement and electrical wiring checking were made to
ensure that the equipment and necessary power supply are in good working
conditions; and
·
All HVS were calibrated
(five point calibration) using Calibration Kit prior to the commencement of
baseline monitoring and thereafter at bi-monthly intervals.
Instrumentation
(Sibata Model: LD-5R)
2.5.9
The
measuring procedures of the dust meters were in accordance with the
Manufacturer’s Instruction Manual as follows:
·
Placed the dust meters at
least 1.3m above ground
·
Set POWER to “ON” and make
sure that the battery level not flashed or in low level;
·
Pulled the air sampling
inlet cover up;
·
Pushed the knob at MEASURE
position;
·
Set time/mode setting to
[BG] by pushing the time setting switch. Then, started the background
measurement by pushing the start/stop switch once. It took 6 sec. to complete
the background measurement;
·
Turned knob to SENSI. ADJ
position and pressed in;
·
Pushed Start/Stop switch
once;
·
Gently returned knob to
the MEASURE position;
·
Pushed the time setting
switch to change the time setting display to [LOG] at the bottom left of the
liquid crystal display;
·
Removed the cap and
started measurement; and
·
Information such as
sampling date, time, count value and site condition were recorded during the
monitoring period.
Maintenance/Calibration
2.5.10 The following
maintenance/calibration was required for the direct reading dust meter:
·
Direct reading dust meter
shall be used in determining 1-hour TSP and 24-hour TSP at air quality
monitoring points. The direct reading dust meters have been calibrated against
high volume samplers (HVSs) bi-monthly. A 2-day, three 3-hour measurement results per day from
direct reading dust meters were taken to compare with the sampling results from
the HVSs. The correlation between the direct reading dust meters and the HVSs
were then concluded. By accounting for the correlation factor, the direct
reading dust meters are considered to achieve comparable results as that of the
HVSs.
·
The HVS used to calibrate
the direct dust monitor will need to be calibrated bi-monthly. Details of maintenance
and calibration for the HVS refers to Section 2.5.8. Calibration for the
air quality monitoring equipment is attached to the Appendix 2.2.
Table 2.4 Action and Limit Levels for 1-hour TSP Air Quality Monitoring
|
Monitoring Station
|
AL (μg/m3)
|
LL (μg/m3)
|
|
KTN-DMS4(B)
|
297
|
500
|
|
FLN-DMS1
|
303
|
500
|
|
FLN-DMS5
|
279
|
500
|
|
FLN-DMS6(A)
|
286
|
500
|
Table 2.5 Action and Limit Levels for 24-hour of TSP Air Quality Monitoring
|
Monitoring Station
|
AL (μg/m3)
|
LL (μg/m3)
|
|
KTN-DMS4(B)
|
192
|
260
|
|
FLN-DMS1
|
150
|
260
|
|
FLN-DMS5(A)
|
153
|
260
|
|
FLN-DMS6(A)
|
157
|
260
|
2.7.1
Air
quality monitoring was conducted as scheduled in the reporting period. The air quality
monitoring schedule during the reporting period is shown in the Appendix 2.1.
2.7.2
The 1-hour
and 24-hour TSP air quality monitoring result in the reporting period are
summarized in Table 2.6 and
2.7. No
Action or Limit levels exceedance was recorded in the reporting period.
Details of the results and graphical presentation are shown in Appendix 2.2.
The
weather information during the reporting period is presented in Appendix 2.3.
Table 2.6 Summary Table
of 1-hour TSP Monitoring Result during the Reporting Month
|
Monitoring
Station
|
Averaged Measured Value (μg/m3)
|
Maximum Measured
Value (μg/m3)
|
Minimum Measured Value (μg/m3)
|
Action Level (μg/m3)
|
Limit Level, (μg/m3)
|
|
KTN-DMS4(B)(1)
|
43
|
67
|
26
|
297
|
500
|
|
FLN-DMS1(1)
|
56
|
106
|
25
|
303
|
500
|
|
FLN-DMS5(1)
|
39
|
55
|
22
|
279
|
500
|
|
FLN-DMS6(A)(2)
|
60
|
75
|
47
|
286
|
500
|
Remarks:
(1) The air quality monitoring (1-hour and
24-hour TSP) was conducted by First Phase ET during the reporting period.
(2) The air quality monitoring (1-hour and
24-hour TSP) was conducted by Remaining Phase ET during the reporting period.
Table 2.7
Summary Table of 24-hour TSP Monitoring Result during the Reporting Month
|
Monitoring
Station
|
Averaged Measured Value (μg/m3)
|
Maximum Measured
Value (μg/m3)
|
Minimum Measured
Value (μg/m3)
|
Action Level (μg/m3)
|
Limit Level, (μg/m3)
|
|
KTN-DMS4(B)(1)
|
50
|
59
|
43
|
192
|
260
|
|
FLN-DMS1(1)
|
26
|
31
|
24
|
150
|
260
|
|
FLN-DMS5(A) (1)
|
60
|
76
|
42
|
153
|
260
|
|
FLN-DMS6(A)(2)
|
70
|
81
|
56
|
157
|
260
|
Remarks:
(1) The air quality monitoring (1-hour and
24-hour TSP) was conducted by First Phase ET during the reporting period.
(2) The air quality monitoring (1-hour and
24-hour TSP) was conducted by Remaining Phase ET during the reporting period.
2.7.3
According
to the observation record from Monthly EM&A Report
(April 2026) prepared under Service Contract No. NDO 04/2019, the major dust source KTN-DMS4(B), FLN-DMS1,
FLN-DMS5 and FLN-DMS5(A) included excavator, concrete mixer truck, crane, road traffic, dump truck
and road
traffic etc. For station conducted
by Remaining Phase ET, the major dust source for FLN-DMS6(A) is from road
traffic.
2.8
Event and Action Plan
2.8.1
Should
any non-compliance of the criteria occur, action in accordance with the Event
and Action Plan in Appendix 2.4 shall be followed. Investigation of the exceedances of
environmental quality performance limits should be conducted, and the ET will
immediately notify the IEC and EPD, as appropriate. The notification should be
followed up with advice to the IEC and EPD on the results of the investigation,
proposed actions and success of the action taken, with any necessary follow-up
proposals.
3
Construction Noise Monitoring
3.1.1
In
accordance with the approved Updated EM&A Manual, the ET shall carry out
impact monitoring during the construction phase of the Project in terms of the
A-weighted equivalent continuous sound pressure level (Leq) to
monitor the construction noise arising from the construction activities. The
regular monitoring frequency for each monitoring station was on a weekly basis
and one set of measurements between 0700 and 1900 hours on normal weekdays
shall be conducted.
3.2.1
According
to the approved Updated EM&A Manual, the monitoring designated locations
for construction noise monitoring in related to the works contracts in the
reporting period are listed in Table
3.1 and
shown in Figure 3.1 and Figure 3.2.
Table 3.1
Construction Noise Monitoring Stations near in related to the Works Contracts
in the Reporting period
|
Monitoring Station(s)
|
Works Contract(s)
|
NSR
EIA ID(s)
|
Location(s)
|
Planned(2)
Or
Existing
|
Type of Measurement
|
|
CP-KTN-NMS1
|
ND/2024/01,
ND/2024/02
|
CP-NMS1
|
Residential Building at Ma Tso Lung
|
Existing
|
Free-Field(1)
|
|
CP-KTN-NMS2
|
ND/2024/01,
ND/2024/02
|
CP-NMS2
|
Residential Building at Ma Tso Lung
|
Existing
|
Free-Field(1)
|
|
CP-KTN-NMS3
|
ND/2024/01,
|
CP-NMS3
|
Fung Kong Garden
|
Existing
|
|
CP-KTN-NMS4(3)
|
ND/2024/01,
ND/2024/02,
ND/2024/03
|
CP-NMS5
|
Primary School
|
Planned
|
|
CP-KTN-NMS5
|
ND/2024/06
|
CP-NMS7
|
N/A
|
Existing
|
Free-Field(1)
|
|
CP-KTN-NMS6
|
ND/2024/01,
ND/2024/02
|
N/A
|
Ho Sheung Heung, Hau Ku ShekAncestral Hall, Hung Shing Temple &
Pai Fung Temple and Sin Wai Nunnery
|
Existing
|
Façade
|
|
CP-KTN-NMS7
|
ND/2024/01, ND/2024/02
|
CP-NMS4
|
Oi Lok Home
|
Existing
|
Free-Field(1)
|
|
CP-FLN-NMS4(A)(4)
|
ND/2024/04
|
CP-NMS6
|
Choi Ying House,
Choi Po Court
(Choi Yuen Estate)
|
Existing
|
Free-Field(1)
|
|
CP-FLN-NMS1
|
ND/2024/06, ND/2024/07
|
CP-NMS10
|
Belair Monte
|
Existing
|
Facade
|
|
CP-FLN-NMS3(3)
|
ND/2024/06,
ND/2024/07
|
CP-NMS12
|
Secondary School
|
Planned
|
Free-Field(1)
|
|
CP-FLN-NMS5
|
ND/2024/07
|
CP-NMS8
|
Man Kok Village
|
Existing
|
Free-Field(1)
|
|
CP-FLN-NMS6
|
ND/2024/07
|
CP-NMS9
|
Woodland Crest
|
Existing
|
Façade
|
Remarks:
(1) For Free Field measurement,
+3 dB(A) should be added to the measured results.
(2) Impact monitoring will be
carried out when the planned sensitive receivers are commissioned.
(3) As confirmed with Engineer
Representative, the planned school at CP-KTN-NMS4 and CP-FLN-NMS3 are not
constructed yet. Thus, the impact noise monitoring will be carried out at
monitoring station CP-KTN-NMS4 and CP-FLN-NMS3 after the construction and
occupation of the planned school. No noise monitoring of the mentioned station
was carried out in this reporting period.
(4) Alternative monitoring
stations to the corresponding original monitoring stations.
3.3
Noise Monitoring Parameter, Frequency and
Duration
3.3.1
Construction
noise level was measured by the ET and measured in terms of the A-weighted
equivalent continuous sound pressure level (Leq). Leq(30mins)
used as the monitoring parameter for the construction noise monitoring.
3.3.2
As
supplementary information for data auditing, statistical results such as L10
and L90 were also obtained for reference.
3.3.3
Table 3.2 summarizes the
monitoring parameters, duration, and frequency of construction noise
monitoring.
Table 3.2
Construction Noise Monitoring Parameter, Frequency and Duration
|
Monitoring Station
|
Parameter
|
Frequency and Duration
|
|
CP-KTN-NMS1(2), CP-KTN-NMS2(1), CP-KTN-NMS3(1), CP-KTN-NMS5(1), CP-KTN-NMS6(1),CP-KTN-NMS7(2),CP-FLN-NMS1(1), CP-FLN-NMS4(A)(2), CP-FLN-NMS5(2), CP-FLN-NMS6(2)
|
Leq(30mins), L10 and
L90 (as six consecutive Leq,5min
readings)
|
Once every week throughout the
construction phase
|
Remark:
(1) The noise monitoring was conducted by First
Phase ET during the reporting period.
(2) The noise monitoring was conducted by
Remaining Phase Environmental Team during the reporting period.
3.4.1
As
referred to the technical memorandum issued under the Noise Control Ordinance
(NCO), sound level meters in compliance with the International Electrotechnical
Commission Publications 651: 1979 (Type 1) and 804: 1985 (Type 1)
specifications were used for carrying out the construction noise monitoring.
3.4.2
Noise
measurements were not made in fog, rain, wind with a steady speed exceeding 5
m/s or wind with gusts exceeding 10 m/s. The wind speed was checked with a
portable wind speed meter capable of measuring the wind speed in m/s.
3.4.3
Sufficient
numbers of noise measuring equipment and associated instrumentation were
prepared by the ET. All the equipment and associated instrumentation were
clearly labelled.
3.4.4
The
monitoring procedures are as follows:
·
For façade measurement,
the monitoring station was set at a point 1 m from the exterior of the
sensitive receivers building façade and set at a position 1.2 m above the
ground. For free-field measurement, the monitoring station was set at a
position 1.2 m above the ground.
·
The battery condition was
checked to ensure good functioning of the meter.
·
Parameters such as
frequency weighting, the time weighting and the interval were set as follows:
-
Frequency weighting: A
-
Time weighting: Fast
-
Interval: 30 minutes (Leq(30mins))
·
Prior to and after each
noise measurement, the meter was calibrated using an acoustic calibrator for
94.0 dB at 1000 Hz. If the difference in the calibration level before and
after measurement is more than 1.0 dB, the measurement was considered invalid and
repeat of noise measurement will be required after re-calibration or repair the
equipment.
·
At the end of the
monitoring period, the values of Leq, L10 and L90
were recorded. In addition, noise sources were recorded on a standard record
sheet.
3.4.5 Table 3.3 summarizes the noise monitoring
equipment used during the reporting period. Copies of the calibration
certificates for noise monitoring are shown in Appendix 3.1
Table 3.3
Construction Noise Monitoring Equipment
|
Equipment
|
Manufacturer
|
Model
|
No. of Equipment
|
Serial No.
|
|
Sound Level Meter
|
NTi Audio(2)
|
XL2
|
2
|
A2A-17638-E0
A2A-13661-E0
|
|
XL3
|
1
|
A3A-01220-F0
|
|
BSWA(1)
|
BSWA 308
|
3
|
580006
580011
580013
|
|
Acoustic Calibrator
|
RION(2)
|
NC-75
|
2
|
35124527
35124529
|
|
SVANTEK(1)
|
SV30A
|
3
|
24803
24791
24780
|
Remark:
(1)
The noise monitoring
equipment was used by First Phase ET during the reporting period.
(2)
The noise monitoring
equipment was used by Remaining Phase Environmental Team during the reporting
period.
3.5.1
Maintenance
and calibration procedures are as follows:
·
The microphone head of the
sound level meter and calibrator were regularly cleaned with a soft cloth;
·
The sound level meter and
acoustic calibrator were calibrated annually; and
·
The accuracy of the sound
level meter was checked using an acoustic calibrator generating a known sound
pressure level at a known frequency immediately prior to and following each
noise measurement. Measurements were accepted as valid only if the calibration
level from before and after the noise measurement agree to within 1.0 dB.
3.6.1
The
Action and Limit levels were established in accordance with the Updated
EM&A Manual. Table 3.4 presents the Action and
Limit Levels for construction noise. Should non-compliance of the criteria
occur, action in accordance with the Event and Action Plan presented in Appendix 3.2 shall be carried out.
Table 3.4 Action and
Limit Levels for Construction Noise Monitoring
|
Time Period
|
Action
|
Limit Level
|
|
07:00 – 19:00 on normal
weekdays
|
When one or more documented complaints are
received
|
75 dB(A)
|
Remark:
(1)
Time period for
construction noise monitoring during normal construction working hour
(0700-1900 Monday to Saturday).
(2)
If works are to be
carried out during restricted hours, the conditions stipulated in the
Construction Noise Permit (CNP) issued by the Noise Control Authority have to
be followed.
(3)
70 dB(A) and 65 dB(A)
for schools during normal teaching periods and school examination periods,
respectively.
3.7.1
All
noise monitoring was conducted as scheduled in the reporting month. The noise
monitoring schedule during the reporting period is shown in the Appendix 2.1.
3.7.2
Three
Action Level exceedances for construction noise were recorded during the
reporting month, corresponding to three noise-related complaints received. No
Limit Level exceedance was recorded for construction noise monitoring in the
reporting period. Details of the results and graphical presentation are shown
in Appendix 3.1. The construction noise monitoring results are summarized
in Table 3.5. The major noise sources
observed during impact noise monitoring are summarized in Table 3.6.
Table 3.5 Summary of
Construction Noise Monitoring Results during the Reporting Month
|
Works Contracts
|
Monitoring Stations
|
Noise Levels, Leq(30min), dB(A)
|
Baseline Levels, dB(A)
|
Limit Levels, dB(A)
|
|
ND/2024/01, ND/2024/02
|
CP-KTN-NMS1(1)(3)
|
51.7 – 59.5
|
65.7
|
75
|
|
CP-KTN-NMS2(1)(2)
|
52.5 – 65.2
|
58.6
|
|
CP-KTN-NMS3(1)(2)
|
52.1 – 60.5
|
51.6
|
|
CP-KTN-NMS6(2)
|
54.4 – 68.1
|
55.1
|
|
CP-KTN-NMS7(1)(3)
|
63.2 – 66.5
|
64.6
|
|
ND/2024/04
|
CP-FLN-NMS4(A)(1)(3)(4)
|
70.6 – 73.9
|
72.4
|
|
ND/2024/06
|
CP-KTN-NMS5(1)(2)
|
50.9 – 64.7
|
57.2
|
|
ND/2024/06, ND/2024/07
|
CP-FLN-NMS1(2)
|
65.1 – 68.6
|
69.9
|
|
ND/2024/07
|
CP-FLN-NMS5(1)(3)
|
65.7 – 67.7
|
69.5
|
|
CP-FLN-NMS6(3)
|
51.9 – 60.1
|
55.0
|
Remarks:
(1) For Free Field measurement, +3 dB(A) was
added to the measured results.
(2) The noise monitoring was conducted by First
Phase ET during the reporting period.
(3) The noise monitoring was conducted by
Remaining Phase Environmental Team during the reporting period.
(4) Alternative monitoring stations to the
corresponding original monitoring stations.
Table 3.6 Summary of Observations at Noise Monitoring Stations
|
Works Contracts
|
Monitoring Stations
|
Location
|
Major Noise Sources
|
|
ND/2024/01, ND/2024/02
|
CP-KTN-NMS1
|
Residential Building at Ma Tso Lung
|
Household noise (dog barking) from
nearby village house
|
|
CP-KTN-NMS2
|
Residential Building at Ma Tso Lung
|
Road Traffic Noise
|
|
CP-KTN-NMS3
|
Fung Kong Garden
|
Road Traffic Noise,
Excavator, Dump Truck, Crane
|
|
CP-KTN-NMS4
|
Primary School
|
N/A(1)
|
|
CP-KTN-NMS6
|
Ho Sheung Heung, Hau Ku Shek Ancestral Hall, Hung Shing Temple &
Pai Fung Temple and Sin Wai Nunnery
|
Road Traffic Noise
|
|
CP-KTN-NMS7
|
Oi Lok Home
|
Road Traffic Noise
|
|
ND/2024/04
|
CP-FLN-NMS4(A)(2)
|
Choi Ying House,
Choi Po Court
(Choi Yuen Estate)
|
Road Traffic Noise
|
|
ND/2024/06
|
CP-KTN-NMS5
|
N/A
|
Road Traffic Noise
|
|
ND/2024/06, ND/2024/07
|
CP-FLN-NMS1
|
Belair Monte
|
Road Traffic Noise, Excavator, Dump
Truck, Crane Truck, Hand Breaker
|
|
CP-FLN-NMS3
|
Secondary School
|
N/A(1)
|
|
ND/2024/07
|
CP-FLN-NMS5
|
Man Kok Village
|
Road Traffic Noise
|
|
CP-FLN-NMS6
|
Woodland Crest
|
No construction activity and other
noise source was observed
|
Remarks:
(1)
No impact noise
monitoring was carried out at the monitoring station. Thus, not applicable
(N/A).
(2) Alternative monitoring
stations to the corresponding original monitoring stations.
3.7.3
Three
noise related complaints were received during the reporting period. The details
of the complaints and investigation results are shown in Appendix 12.1.
4.1.1
In
accordance with the approved Updated EM&A Manual and EM&A Manual, impact
water quality monitoring shall be carried out three days per week at all the
designated monitoring stations during the construction of channel. The
measurement periods are specified in
Table 4.1. The
interval between two sets of monitoring shall not be less than 36 hours.
Table
4.1 Summary of Water Quality Monitoring Locations
|
New Monitoring Station(s)
|
Original Monitoring Station ID(s)
|
Description
|
Location(s)
|
Measurement
Period
|
|
KTN NDA
|
|
KTN-CS1
|
CS1
|
Control Station for KTN NDA
|
Centreline of river, upstream of the
channel
|
During construction of channel
|
|
KTN-IS1
|
IS1
|
Impact Station for KTN NDA
|
Centreline of river, downstream of the
channel
|
During construction of channel
|
|
FLN NDA
|
|
FLN-CS1
|
CS2
|
Control Station for FLN NDA
|
Centreline of river, upstream of the
channel
|
During construction of channel
|
|
FLN-IS1
|
IS2
|
Impact Station for FLN NDA
|
Centreline of river, downstream of the
channel
|
During construction of channel
|
4.2.1
No
construction of channelisation work between KTN-CS1, KTN-IS1, FLN-CS1 and
FLN-IS1 were undertaken during the reporting period. Therefore, no water quality
monitoring was carried out.
6
Ecology
6.1.1
This
section was derived from the ecological monitoring conducted during the
construction phase by the Remaining Phase ET, supplemented with findings
retrieved from the First Phase ET under Service Contract No. NDO 04/2019
Environmental Team for Environmental Monitoring and Audit Works in Construction
Phase for the First Phase Development of Kwu Tung North and Fanling North New
Development Areas. This approach was undertaken to prevent redundancy in survey
efforts.
Weekly Site
Inspection
6.2.1
Weekly
site inspections by the ET from the First Phase of the KTN/FLN NDAs Project for
ecological mitigation measures are conducted as part of the overall weekly
environmental site inspections. These inspections audit the ecological
mitigation measures implemented within the active works area to ensure that the
activities do not significantly impact the ecologically sensitive receivers in
the active works areas.
Monitoring of
Measures to Minimise Disturbance to Water Birds in Ng Tung River, Sheung Yue
River, Shek Sheung River and Long Valley
6.2.2
As
stipulated in Section 12.3.2.5 of the Updated EM&A Manual, if development
under the NDAs project occurs within 200m of Sheung Yue River, Ng Tung River,
Shek Sheung River and Long Valley, weekly transect monitoring at high and low
tides (above/below 1.5m at Tsim Bei Tsui Station) should be conducted. The
monitoring aims to identify and count bird species in the river channels and
Long Valley Nature Park (LVNP) and detect any disturbances from construction
activities, following the methodology in Table 12.1 of the Updated EM&A
Manual. Monitoring in Long Valley should follow the Hong Kong Bird Watching
Society (HKBWS) bird monitoring programme's methodology for comparable and
comprehensive results.
Monitoring of
Measures to Minimise Impacts to Ma Tso Lung Stream and Siu Hang San Tsuen
Stream, and Long Valley
6.2.3
As
stipulated in Section 12.3.2.14 of the Updated EM&A Manual, aquatic fauna
monitoring should be conducted monthly during the wet season (April – October) of
the construction phase.
Monitoring of
Measures to Minimise Impacts on Ecological Sensitive Habitats from Disturbance
and Pollution
6.2.4
As
stipulated in Section 12.3.2.17 of the Updated EM&A Manual, measures to
minimize impacts should be monitored during the construction phase. The purpose
of these surveys is to assess the effectiveness of measures aimed at reducing
disturbances and pollution in ecologically sensitive habitats through standard
fauna transect surveys.
6.2.5
For
this reporting month, only transects that are relevant to the active works of
Works Contract ND/2024/01, Contract No. ND/2024/02, Contract No. ND/2024/03,
Contract No. ND/2024/04, Contract No. ND/2024/06, Contract No. ND/2024/07 and
Contract No. ND/2024/08, were included. The active works for the mentioned
contracts are described in Section
1.3.1 of
this report and shown in Figure
1.1 and Figure 1.2.
6.2.6
Table 6.1 summarizes the relevant
transects and monitoring station to each contract under the remaining phase,
categorised under the column “First Phase ET” and “Remaining Phase ET”
according to the current survey efforts. The locations of these contracts
relative to the monitoring locations are shown in Figure 6.1 and Figure
6.2.
Table 6.1 Summary of
Monitoring Activities, Relevant Contracts, and Corresponding Transects
|
Monitoring
Activity
|
Relevant Works Contract(s)
|
Relevant
Transect(s)/Monitoring Station(s)
|
|
First Phase ET
|
Remaining Phase ET
|
|
Monitoring of
Measures to Minimise Disturbance to Water Birds on Ng Tung, Sheung Yue, and
Shek Sheung Rivers and Long Valley
|
ND/2024/01*
|
T1, T2, T3, T5
|
-
|
|
ND/2024/02*
|
T1, T2, T3, T5
|
T4
|
|
ND/2024/03*
|
T1, T2, T3, T5
|
-
|
|
ND/2024/04*
|
-
|
T4
|
|
ND/2024/05
|
N/A(1)
|
N/A(1)
|
|
ND/2024/06*
|
T1, T2, T3
|
-
|
|
ND/2024/07*
|
T1, T2, T3
|
T4
|
|
ND/2024/08*
|
T1, T2, T3
|
T4
|
|
Monitoring of Measures to Minimise Impacts to Ma Tso Lung Stream and
Siu Hang San Tsuen Stream, and Long Valley
|
ND/2024/01*^
|
MS_01, MS_02, MS_03, MS_04, MS_05, MS_06, MS_07,
MS_08, MS_09, MS_10
|
-
|
|
ND/2024/02*^
|
MS_01, MS_02, MS_03, MS_04, MS_05, MS_06, MS_07,
MS_08, MS_09, MS_10
|
-
|
|
ND/2024/03*
|
N/A(2)
|
N/A(2)
|
|
ND/2024/04*
|
N/A(2)
|
N/A(2)
|
|
ND/2024/05
|
N/A(2)
|
N/A(2)
|
|
ND/2024/06*
|
N/A(2)
|
N/A(2)
|
|
ND/2024/07*^
|
MS_11, MS_12, MS_13, MS_14, MS_15
|
-
|
|
ND/2024/08*^
|
MS_11, MS_12, MS_13, MS_14, MS_15
|
N/A(2)
|
|
|
|
|
|
|
Monitoring of Measures to Minimise Impacts on Ecological Sensitive
Habitats from Disturbance and Pollution
|
ND/2024/01*
|
T1
|
-
|
|
ND/2024/02*
|
T1, T6
|
-
|
|
ND/2024/03*
|
T4
|
-
|
|
ND/2024/04*
|
N/A(3)
|
N/A(3)
|
|
ND/2024/05
|
T4, T6
|
-
|
|
ND/2024/06*
|
-
|
T2
|
|
ND/2024/07*
|
T3
|
-
|
|
ND/2024/08*
|
T3
|
-
|
Remarks:
(1) Contracts that are located relatively far
from river channels.
(2) Contracts that are located relatively far
from Ma Tso Lung and Siu Hang San Tsuen streams.
(3) Contracts that are located relatively far
from the Ecological Sensitive Habitats as identified in the EIA.
(4) * = active works contracts (ND/2024/01, ND/2024/02,
ND/2024/03, ND/2024/04, ND/2024/06, ND/2024/07 and ND/2024/08); ^ = monitoring
only in April – October’.
6.2.7
The details of the relevant
monitoring activities are discussed in the succeeding sections.
Monitoring of
Measures to Minimise Disturbance to Water Birds in Ng Tung River, Sheung Yue
River, Shek Sheung River and Long Valley
Monitoring Methodology
6.3.1
Birds
identified by their calls but not visually located were recorded as
"heard", while those observed flying over the survey area were noted
as "in flight." Species of conservation importance were also
specified. Additional information at the time of the survey, such as weather
conditions, tidal conditions, tide levels, and noticeable natural or
anthropogenic activities, were documented. For the avifauna survey,
ornithological nomenclature referenced The Avifauna of Hong Kong (Carey
et al., 2001), The Birds of Hong Kong and South China (Viney et al.,
2005), and the most recent updated lists from other sources (e.g., Hong Kong
Bird Watching Society).
Monitoring
Parameters
6.3.2
The
monitoring parameters are as follows:
·
Abundance of birds;
·
Types of habitats utilized
by birds; and
·
Notable bird behaviours
such as roosting, feeding, nesting and presence of juveniles.
Monitoring Location
6.3.3
For
this reporting month, First Phase ET conducted avifauna monitoring at Ng Tung
River, Sheung Yue River, and Long Valley, while the Remaining Phase ET
conducted avifauna monitoring at Shek Sheung River. Relevant transect routes
are summarized in Table 6.2 and illustrated in Figure 6.1 and Figure 6.2. As the sensitive receivers are large waterbirds and are
easily visible, the transect routes only needed to follow one riverbank.
Table 6.2 Summary of
Active Works Contracts and Corresponding Transects
|
Monitoring
Transect(s)
|
Relevant Works Contract(s)
|
|
ND/2024/01
|
ND/2024/02
|
ND/2024/03
|
ND/2024/04
|
ND/2024/06
|
ND/2024/07
|
ND/2024/08
|
|
T1. Ng Tung River
|
✓
|
✓
|
✓
|
|
✓
|
✓
|
✓
|
|
T2. Ng Tung River
|
✓
|
✓
|
✓
|
|
✓
|
✓
|
✓
|
|
T3. Sheung Yue River
|
✓
|
✓
|
✓
|
|
✓
|
✓
|
✓
|
|
T4. Shek Sheung River
|
|
✓
|
|
✓
|
|
✓
|
✓
|
|
T5. Long Valley
|
✓
|
✓
|
✓
|
|
|
|
|
Monitoring Frequency
6.3.4
Avifauna
monitoring at high and low tides should be conducted weekly. Additionally,
nighttime monitoring in Long Valley should be conducted twice a month from
September to April, which is not required for the reporting month.
6.3.5
For
this reporting month, waterbird monitoring was conducted by both the First
Phase ET (T1, T2, T3 and T5) and Remaining Phase ET (T4). Survey date for each
monitoring is shown in Table
6.3.
Table 6.3 Monitoring Programme for
Waterbirds Monitoring, April 2026
|
Week
|
Date
|
Transect(1)
|
|
1
|
1 April 2026
|
T4
|
|
2
|
8 April 2026
|
T4
|
|
9 April 2026
|
T3, T5
|
|
10 April 2026
|
T1, T2, T4
|
|
3
|
14 April 2026
|
T3, T4, T5
|
|
16 April 2026
|
T4
|
|
17 April 2026
|
T1, T2
|
|
4
|
20 April 2026
|
T3, T5
|
|
21 April 2026
|
T4
|
|
22 April 2026
|
T4
|
|
23 April 2026
|
T1, T2
|
|
5
|
28 April 2026
|
T1, T2, T4
|
|
30 April 2026
|
T3, T4, T5
|
|
Additional Nighttime
Monitoring in Long Valley
|
20 April 2026
|
T5
|
|
30 April 2026
|
Remarks:
(1) Transects T1, T2, T3, and T5 are relevant to
Works Contract ND/2024/01 and ND/2024/03; Transect T4 is relevant to Works
Contract ND/2024/04; Transects T1, T2, and T3 are relevant to Works Contract
ND/2024/06; Transects T1, T2, T3 and T4 are relevant to Works Contract
ND/2024/07 and ND/2024/08; Transect T1, T2, T3, T4 and T5 are relevant to Works
Contract No. ND/2024/02.
Monitoring Results
6.3.6
For
this reporting month, only monitoring results in Transects T1, T2, T3, T4 and
T5 are reported as not all of these monitoring data are relevant to active Works
Contract ND/2024/01, ND/2024/02, ND/2024/03, ND/2024/04, ND/2024/06, ND/2024/07
and ND/2024/08 as summarised in Table
6.1.
6.3.7
Transect
T1 and T2 were conducted along the Ng Tung River. For Transect T1, a total of 3
species of large waterbirds, namely Grey Heron (4 individuals), Great Egret (7 individuals)
and Little Egret (39 individuals), were recorded in the reporting month. For
Transect T2, a total of 3 species of large waterbirds, namely Grey Heron (11 individuals),
Great Egret (12 individuals) and Little Egret (56 individuals), were recorded
in the reporting month.
6.3.8
Transect
T3 was conducted along the Sheung Yue River. A total of 3 species of large
waterbirds, namely Grey Heron (2 individuals), Great Egret (7 individuals) and
Little Egret (122 individuals), were recorded for the reporting month.
6.3.9
Transect
T4 was conducted along the Shek Sheung River. A total of 2 species of large
waterbirds, namely Great Egret (4 individuals) and Little Egret (19 individuals),
were recorded during the reporting month.
6.3.10
Transect
T5 was conducted in Long Valley Nature Park with the highest species diversity
and abundance recorded. A total of 4 species of large waterbirds, namely Grey
Heron (1 individual), Great Egret (3 individuals), Intermediate Egret (6 individuals)
and Little Egret (32 individuals), were also found to utilise the habitat.
6.3.11
Chinese
Pond Heron, the most abundant waterbird species recorded during the baseline
survey, which is strictly associated with wetlands, was widely noted across
different transect routes in the reporting month 148 individuals recorded in
total. 21 individuals were noted along Transect T1, 29 individuals along
Transect T2, 20 individuals along Transect T3, 18 individuals along Transect
T4, and 60 individuals were noted along Transect T5.
6.3.12
Relevant
results of the avifauna monitoring conducted by the First Phase ET during this
reporting month are detailed in Appendix
6.1a to Appendix 6.1j. Findings of surveys conducted by the Remaining Phase ET
during this reporting month are detailed in Appendix 6.1k to Appendix 6.1o.
6.3.13 Table 6.4 summarizes the results of the
monitoring of measures to minimize disturbance to waterbirds in Ng Tung River,
Sheung Yue River, Shek Sheung River and Long Valley of the reporting month.
Table
6.4 Summary Table of Waterbird Monitoring Results Relative to Corresponding
Action and Limit Levels, April, Transects T1, T2, T3, T4 and T5
|
Monitoring Parameter
|
Result in Reporting Month
(April 2026)
|
Baseline Level in Corresponding Month
(April 2020)
|
Action
Level (1)
|
Limit
Level (2)
|
|
T1, T2 and T3
|
|
Mean abundance of large waterbirds using
Ng Tung River, Sheung Yue River and Shek Sheung River (3)
|
65
|
19
|
13
|
9
|
|
Mean abundance of Chinese Pond Heron using
Ng Tung River, Sheung Yue River and Shek Sheung River
|
18
|
15
|
10
|
7
|
|
T4
|
|
Mean abundance of large waterbirds using Shek Sheung
River (3)
|
5
|
4
|
3
|
2
|
|
Mean abundance of Chinese Pond Heron using Shek
Sheung River
|
4
|
5
|
3
|
2
|
|
T5 Long Valley
|
|
Mean Abundance of birds (all species)
recorded in LVNP
|
574
|
496
|
347
|
248
|
|
Mean abundance of the Chinese Pond Heron
|
15
|
12
|
8
|
6
|
|
Environmental disturbance and damage from
activities in LVNP
|
-
|
-
|
Activity likely to cause unacceptable
environmental
disturbance or
damage noted in LVNP.
|
Activity likely to cause unacceptable
environmental
disturbance or
damage noted in LVNP.
|
|
|
|
|
|
|
Remarks:
(1) Exceedance of Action Level occurs when the
monitoring result is lower than the Action Level.
(2) Exceedance of Limit Level occurs when the
monitoring result is lower than the Limit Level.
(3) Large waterbird species for mean abundance
calculation include Great Cormorant (Phalacrocorax carbo); Grey Heron (Ardea
cinerea); Great Egret (Ardea alba); Intermediate Egret (Ardea
intermedia); Little Egret (Egretta garzetta) and Chinese Egret (Egretta
eulophotes).
6.3.14 No exceedance in Action or
Limit Level was recorded for the reporting month.
Monitoring of
Measures to Minimise Impacts to Ma Tso Lung Stream and Siu Hang San Tsuen
Stream, and Long Valley
6.3.15 Monitoring of larger
organisms such as fish species will be carried out through direct counting,
while sampling aquatic invertebrates will involve kick-netting and
sweep-netting. Three replicates will be conducted for invertebrate sampling at
each sampling point. During kick-netting, the net will be positioned at a
location with the opening facing the water current while disturbing the
substrate through kicking to dislodge organisms from the stream bed.
Sweep-netting will be applied to water bodies without water current according
to on-site conditions. Species observed will be identified to the lowest
possible taxonomic level with their relative abundance recorded, with the use
of dissecting microscope especially for small organisms not identifiable through
the naked eye.
Monitoring Parameters
6.3.16 The monitoring
parameters are as follows:
·
Species composition and abundance;
·
Distribution of invertebrates and fish fauna;
and
·
Specify species of conservation importance, if
any.
Monitoring Locations
6.3.17 For this reporting
month, the First Phase ET conducted the aquatic fauna monitoring along Ma Tso
Lung Stream and Siu Hang Sang Tsuen Stream. Specifically, the monitoring
stations relevant for the active works under Works Contract ND/2024/01 and
ND/2024/02 are:
|
·
MS_01
|
·
MS_02
|
·
MS_03
|
·
MS_04
|
·
MS_05
|
|
·
MS_06
|
·
MS_07
|
·
MS_08
|
·
MS_09
|
·
MS_10
|
And the relevant monitoring
stations for Works Contract ND/2024/07 and ND/2024/08 are:
|
·
MS_11
|
·
MS_12
|
·
MS_13
|
·
MS_14
|
·
MS_15
|
6.3.18 The above monitoring
stations are shown in Figure
6.1 and Figure 6.2.
Monitoring Frequency
6.3.19
As
stated in Section 12.3.2.14 of the Updated EM&A Manual, aquatic fauna
monitoring should be conducted monthly during the wet season (April – October)
during the construction phase.
6.3.20
For
this reporting month, aquatic fauna monitoring was conducted by the First Phase
ET on 22 April 2026.
Monitoring Results
6.3.21
A
total of 24 species of aquatic invertebrates and 5 species of fish were
recorded along the Ma Tso Lung Stream and Siu Hang San Tsuen Stream for the
reporting month. One native aquatic invertebrate species of conservation
importance (larva of Club-tailed Cruiser) was noted for the reporting month,
according to the findings of the First Phase ET. A complete species list is
enclosed as Appendix 6.2.
6.3.22
4
monitoring stations, namely MS_01, MS_03, MS_05 and MS_12, were found to be
dried-up. Thus, no aquatic fauna species were recorded.
6.3.23
Table 6.5 and Table 6.6 summarized the aquatic monitoring
results for the reporting month.
Table
6.5 Summary Table of Monitoring Results for Aquatic Invertebrates Relative to
Action and Limit Levels, April, Monitoring Station MS_01 – MS_15
|
Monitoring
Station
|
Result
in Reporting Month (April 2026) (1)
|
Baseline Level in
Corresponding Month (April 2020) (1)
|
Action Level(2)
|
Limit Level(3)
|
|
MS_01
|
0
|
0
|
N/A
|
N/A
|
|
MS_02 and MS_03
|
2
|
3
|
2
|
1
|
|
MS_04, MS_06 and MS_07
|
6
|
5
|
4
|
3
|
|
MS_05
|
0
|
0
|
N/A
|
N/A
|
|
MS_08, MS_09 and MS_10
|
7
|
5
|
4
|
3
|
|
MS_11
|
0
|
0
|
N/A
|
N/A
|
|
MS_12
|
0
|
0
|
N/A
|
N/A
|
|
MS_13 and MS_14
|
4
|
3
|
2.1
|
1
|
|
MS_15
|
0
|
0
|
N/A
|
N/A
|
Remarks:
(1) Number of native species (species richness)
recorded.
(2) Exceedance of Action Level occurs when the
monitoring result is lower than the Action Level.
(3)
Exceedance of Limit
Level occurs when the monitoring result is lower than the Limit Level.
Table
6.6 Summary Table of Monitoring Results for Fish Species Relative to Action and
Limit Levels, April, Monitoring Station MS_01 – MS_15
|
Monitoring
Station
|
Result
in Reporting Month (April 2026) (1)
|
Baseline Level in
Corresponding Month (April 2020) (1)
|
Action Level(2)
|
Limit Level(3)
|
|
MS_01
|
0
|
0
|
N/A
|
N/A
|
|
MS_02 and MS_03
|
0
|
1
|
N/A
|
N/A
|
|
MS_04, MS_06 and MS_07
|
1
|
2
|
N/A
|
1
|
|
MS_05
|
0
|
0
|
N/A
|
N/A
|
|
MS_08, MS_09 and MS_10
|
1
|
2
|
N/A
|
1
|
|
MS_11
|
0
|
0
|
N/A
|
N/A
|
|
MS_12
|
0
|
0
|
N/A
|
N/A
|
|
MS_13 and MS_14
|
1
|
1
|
N/A
|
N/A
|
|
MS_15
|
0
|
0
|
N/A
|
N/A
|
Remarks:
(1) Number of native species (species richness)
recorded.
(2) Exceedance of Action Level occurs when the
monitoring result is lower than the Action Level.
(3) Exceedance of Limit Level occurs when the
monitoring result is lower than the Limit Level.
6.3.24 No exceedance in Action
or Limit Level was recorded for the reporting month.
Monitoring of Measures to Minimise Impacts on Ecological Sensitive Habitats
from Disturbance and Pollution
Monitoring Methodology
Terrestrial Mammal
6.3.25
Mammal
surveys were conducted both during the day and at night along transect routes
that may be potentially utilized by terrestrial mammals. Observations included
field signs such as droppings, footprints, diggings, and burrows left by larger
terrestrial mammals. Any mammals directly observed were recorded, and
identification was as accurate as possible based on the field signs.
6.3.26
Bat
surveys were conducted along the transect routes shortly after sunset using a
bat detector to record echolocation calls. The relative abundance of the
species encountered were estimated with reference to the baseline monitoring
results, using a scale from one (species recorded within transect routes) to
three (dominant species within transect routes), for comparison between
baseline and current monitoring results. Mammal nomenclature followed Shek
(2006).
6.3.27
Echolocation
calls of bats were recorded using a bat detector, which listed possible bat
species with similar call patterns and frequencies. The structure of the
recorded echolocation calls was later analysed to identify species as
accurately as possible. Due to the lack of literature on echolocation call
structures, field identification of some bat species in Hong Kong is
challenging, and some species could only be identified to the genus level or
remain unidentified from the recordings.
6.3.28 Identification of bat
species encountered in the surveys was made by considering the possible species
suggested by the bat detector, their distribution in Hong Kong, previous
records in the EIA Report and Baseline Monitoring Report, and the structure of the
echolocation calls (including call structure, frequency, duration, and
inter-pulse interval) with reference to relevant literature.
Herpetofauna (Amphibians and Reptiles)
6.3.29
Both
daytime and nighttime amphibian surveys were conducted whenever possible
following or during periods of rainfall, focusing on areas suitable for
amphibians (e.g., forests, shrublands, grasslands, streams, ponds, marshes,
etc.). Calling amphibians were recorded, supplemented by visual observations of
eggs, tadpoles, adult frogs, and toads.
6.3.30 Active searches of
appropriate microhabitats, such as stones, pond bunds, crevices, and leaf
debris, was primarily conducted. Observations of exposed, basking, and foraging
reptiles were also carried out. Nomenclature for amphibians and reptiles
followed Chan et al. (2005) and Karsen et al. (1998), respectively.
Butterfly and Odonates
6.3.31 Butterflies and
dragonflies observed along the transects were identified and counted. Special
attention was given to their preferred habitats, such as watercourses,
fishponds, and vegetated areas. Nomenclature and protection status of the
species followed Lo et al. (2005) for butterflies and Tam et al. (2011) for
dragonflies.
Monitoring Parameters
6.3.32 The monitoring
parameters are as follows:
·
Species composition;
·
Abundance;
·
Distribution for fauna
observed; and
·
Species of conservation
importance would be specified.
Monitoring Location
6.3.33
According
to the Updated EM&A Manual, the transect routes for monitoring of
ecologically sensitive receivers should follow the following:
·
T1. Ma Tso Lung riparian
zone and associated wetland habitats; green belt areas E1-8, D1-8 and G1-3 in
KTN NDA; AGR zone C2-4 and C2-2
in KTN NDA, and area north of Ng
Tung River;
·
T2. Fanling North
Freshwater Service Reservoir
·
T3. Area west of Siu Hang
San Tsuen Stream;
·
T4. South side of Fanling
Highway and Castle Peak Road in the vicinity of Pak Shek Au;
·
T5. Area west and east of
the southern limit of the FLN NDA work area; and
·
T6. Areas in the western
part of KTN.
6.3.34
The
above transects are shown in Figure
6.1 and Figure 6.2. Relevant transect to Works
Contract ND/2024/01 is Transect T1 which covers areas of Ma Tso Lung riparian zone
and associated wetland habitats, green belt areas E1-8, D1-8 and G1-3 in KTN
NDA, AGR zone C2-4 and C2-2 in KTN NDA, and areas North of Ng Tung River; relevant
transects to Works Contract ND/2024/02 are Transect T1 and T6, of which the
latter covers areas to the west of the KTN NDA work area; relevant transect to
Works Contract ND/2024/03 is Transect T4 which covers the south side of the
Fanling Highway and Castle Peak Toad in the vicinity of Pak Shek Au; relevant
transect to Works Contract ND/2024/06 is Transect T2 which covers areas of the
Fanling North Freshwater Service Reservoir; Works Contract ND/2024/07 involves
Transect T3 which covers the area west of Siu Hang San Tsuen stream; and Works
Contract ND/2024/08 involves Transect T3 as well.
Monitoring Frequency
6.3.35
Monthly
monitoring should be conducted for non-aquatic fauna, including terrestrial
mammals, insects (butterflies and odonates), and herpetofauna. For
this reporting month, monthly monitoring for non-aquatic fauna were conducted
by both the First Phase ET (T1, T3, T4 and T6) and Remaining Phase ET (T2).
Survey dates for each monitoring are shown in Table 6.7.
Table 6.7 Monitoring Programme for Non-aquatic Fauna
Monitoring, April 2026
|
Responsible ET
|
Date
|
Transect(1)
|
|
First Phase ET
|
15 April 2026
|
T3, T4
|
|
21 April 2026
|
T1, T6
|
|
Remaining Phase ET
|
23, 27 April
2026
|
T2
|
Remarks:
(1) Transect T1 is relevant to Works Contract
ND/2024/01 and Works Contract ND/2024/02; Transect T2 is relevant to Works
Contract ND/2024/06; Transect T3 is relevant to Works Contracts ND/2024/07 and
ND/2024/08; Transect T4 is relevant to Works Contract ND/2024/03; Transect T6
is relevant to Works Contract ND/2024/02.
Monitoring Results
Terrestrial Mammals
6.3.36 A total of 4 species of
terrestrial mammals (2 native and 2 introduced) were recorded along Transect T1.
Short-nosed Fruit Bat and Japanese Pipistrelle are native species of
conservation importance. 5 native bat species of conservation importance,
namely Chinese Noctule, Japanese Pipistrelle, Least Pipistrelle, Lesser Yellow
Bat and Lesser Bent-winged Bat, were recorded along Transect T2 for the
reporting month. 1 species of native terrestrial mammal, namely the Short-nosed
Fruit Bat, was recorded along Transect T3. The Bat is recognised as a species
of conservation importance. A total of 5 species of terrestrial mammal species (2
native and 3 introduced) were recorded along Transect T4, with Short-nosed
Fruit Bat, Japanese Pipistrelle and Pallas’s Squirrel are of conservation
importance. A total of 2 mammal species (1 native and 1 introduced) were
recorded along Transect T6 for the reporting month, and either of them is of
conservation importance. A complete species list is enclosed as Appendix 6.3.
Herpetofauna (Amphibians and Reptiles)
6.3.37
8 native
herpetofauna species (6 amphibians and 2 reptiles) were recorded along Transect
T1. All species are common and widespread natives. 8 native herpetofauna
species (5 amphibians and 3 reptile species) and 1 introduced species were recorded
along Transect T2, of which all are considered common and widespread locally. 3
native herpetofauna species (1 amphibians and 2 reptiles) were recorded along
Transect T3 for the reporting month. All species are widespread and locally
common. A total of 7 native herpetofauna species (3 amphibians and 4 reptile
species) were recorded along Transect T4, with no species of conservation
importance noted. 5 native and widespread herpetofauna species (3 amphibians
and 2 reptiles) were recorded along Transect T6. A complete species list is
enclosed as Appendix 6.3.
Butterfly and Odonates
6.3.38
A
total of 27 butterfly species were recorded along Transect T1, with 1 species (Small
Cabbage White) is of conservation importance. 5 odonate species were recorded
along Transect T1. All species recorded are considered as common natives. 9 butterfly species were
recorded along Transect T2 for the reporting month, with 1 species, namely the Danaid
Egg-fly, is of conservation importance. 2 odonate species, namely Common Blue
Skimmer and Common Red Skimmer, were recorded during the monitoring for the
reporting month. Both are common and widespread natives and none are of
conservation importance. A total of 10 butterfly species were recorded along
Transect T3, with 1 species (Yellow Rajah) recorded is of conservation
importance. 5 odonate species were recorded along Transect T3. All species
recorded are considered as common natives. 20 butterfly species were recorded along Transect T4 with 1
species of conservation importance (Swallowtail) was noted. 4 odonate species
were recorded along Transect T4. All species recorded are considered as common
natives.16 butterflies were recorded along Transect T6 for the reporting month,
with 1 species (Small Cabbage White) is of conservation importance noted. 4 common
species of odonate were recorded along Transect T6, with no species of
conservation importance noted. A complete species list is enclosed as Appendix 6.3.
Summary of Monitoring Results
6.3.39
Monitoring
for non-aquatic (terrestrial mammals, butterflies, dragonflies, and
herpetofauna) taxa was conducted by both the First Phase and Remaining Phase ETs.
Relevant results of the non-aquatic fauna monitoring conducted by the First
Phase ET during this reporting month are detailed in Appendix 6.3a to Appendix 6.3d. Findings of surveys
conducted by the Remaining Phase ET during this reporting month are detailed in
Appendix 6.3e to Appendix 6.3h.
6.3.40
Tables 6.8 summarizes the
monitoring results of Transect T1, T2, T3, T4 and T6 for this reporting month.
Table
6.8 Summary Table of Monitoring Results for Non-aquatic Fauna Relative to
Action and Limit Levels, April 2026, Transect T1, T2, T3, T4 and T6
|
Monitoring
Parameter
|
Result in
Reporting Month
(April 2026) (1)
|
Baseline Level in
Corresponding Month (April 2020) (1)
|
Action Level(2)
|
Limit Level(3)
|
|
T1
|
|
Terrestrial Mammals
|
2
|
2
|
N/A
|
1
|
|
Herpetofauna
|
8
|
8
|
6
|
4
|
|
Odonates
|
5
|
6
|
4
|
3
|
|
Butterflies
|
27
|
10
|
7
|
5
|
|
T2
|
|
Terrestrial Mammals
|
5
|
0
|
N/A
|
N/A
|
|
Herpetofauna
|
8
|
1
|
N/A
|
N/A
|
|
Odonates
|
2
|
3
|
2
|
1
|
|
Butterflies
|
9
|
4
|
3
|
2
|
|
T3
|
|
Terrestrial Mammals
|
1
|
1
|
N/A
|
N/A
|
|
Herpetofauna
|
3
|
4
|
3
|
2
|
|
Odonates
|
5
|
7
|
5
|
4
|
|
Butterflies
|
10
|
4
|
3
|
2
|
|
T4
|
|
Terrestrial Mammals
|
2
|
1
|
N/A
|
N/A
|
|
Herpetofauna
|
7
|
4
|
3
|
2
|
|
Odonates
|
4
|
3
|
2
|
1
|
|
Butterflies
|
20
|
6
|
4
|
3
|
|
T6
|
|
Terrestrial Mammals
|
1
|
0
|
N/A
|
N/A
|
|
Herpetofauna
|
5
|
3
|
2
|
1
|
|
Odonates
|
4
|
5
|
4
|
3
|
|
Butterflies
|
16
|
5
|
4
|
3
|
Remarks:
(1) Number of species (species richness) recorded;
the results in the reporting month for terrestrial mammals, herpetofauna and
odonates are calculated based on the number of native species recorded along
the transects.
(2) Exceedance of Action Level occurs when the
monitoring result is lower than the Action Level.
(3) Exceedance of Limit Level occurs when the
monitoring result is lower than the Limit Level.
6.3.41
No
exceedance in Action or Limit Level was recorded for the reporting month.
Details of the Influencing
Factors
6.3.42
The
details of the influencing factors were adopted from the observations of the
First Phase ET. During the monitoring of measures to minimize disturbance to
waterbirds in Long Valley and Sheung Yue River, anthropogenic activities such
as excavation and other construction activities were observed near Long Valley.
It should also be noted that the Long Valley Nature Park has been opened to
the public since 09 November 2024. Potential increase in people visiting the
park may potentially impact the habitats in Long Valley and cause disturbances
to the bird communities in this area. Construction works were also observed along
Sheung Yue Riverr.
6.3.43
During
the monitoring of measures to minimize disturbance to waterbirds in Ng Tung
River, various anthropogenic activities were observed, such as construction
works along Transect T2, recreational use of remote-control boats and toy helicopters
in both Transects T1 and T2, and recreational fishing along these two transects.
Survey Summary
6.3.44
All
ecological monitoring surveys for the reporting month have been carried out as
scheduled, with
no exceedance reported for the reporting month.
6.4
Man Kam To Egretry Monitoring
6.4.1 A pre-site clearance
check of the Man Kam To Egretry (MKT Egretry) was undertaken on 13 February
2026 to investigate its status, extent, and location prior to the commencement
of works within 100m of the egretry, pursuant to EM&A Manual Section
14.3.2.3.
6.4.2 Following the monitoring
conducted in March, egretry location was checked on 15 April 2026 for the
reporting month to identify and confirm the presence of any ardeid nests,
covering the previous core extent and its split colonies, prior to the
commencement of works activity within 100m of the egretry.
6.5.1
Should
non-compliance of the ecological monitoring criteria occur, actions in
accordance with the Event and Action Plan in Appendix 6.4 shall be carried out.
7
Landscape and Visual
7.1.1
According
to the approved EM&A manual and Updated EM&A Manual for the First Phase,
site audits should be undertaken at least once every two weeks during the construction
period, by the Environmental Team. Particularly, to check that the proposed
landscape and visual mitigation measures are properly implemented and
maintained as per their intended objectives. Mitigation measures recommended in
the EIA Report as the audit requirements including, preservation of existing
vegetation, transplanting of affected trees, compensatory tree planting,
control of night-time lighting glare, erection of decorative screen hoarding
and management of construction activities and facilities.
7.2.1
Bi-weekly
landscape and visual site audits were carried out by the ET during the
reporting period. Inspections were carried out on 2, 16 and 28 April 2026 for
ND/2024/01, 2, 17 and 28 April 2026 for ND/2024/02, 15 and 27 April 2026 for
ND/2024/03, 10 and 24 April 2026 for ND/2024/04, 9 and 21 April 2026 for
ND/2024/06, 9 and 23 April 2026 for ND/2024/07. No particular observation was
recorded in this reporting period.
7.3.1
Should
any non-compliance of the criteria occur, action in accordance with the Event
and Action Plan in Appendix 7.1 shall be followed.
8.1.1
According
to the approved EM&A Manual and Updated EM&A Manual for the First Phase,
an ambient arsenic monitoring is required to be conducted in KTN during the
clean-up processes of arsenic containing soil and the construction phase.
8.1.2
The RSP
concentration was measured by HVS equipped with PM10 selector (PM10 HVS)
following the "Reference Method for the Determination of Particulate
Matter as PM10 in the Atmosphere" Part 50 Chapter 1 Appendix J, Title 40
of the Code of Federal Regulations of the USEPA.
8.1.3
The
Dust-laden air was drawn through PM10 HVS fitted with a conditioned
pre-weighting filter paper, at a controlled rate. After sampling for 24-hour,
the filter paper with retained PM10 particulates was collected and returned to
the laboratory for drying in a desiccator followed by accurate weighting.
24-hour average RSP levels were calculated from the ratio of the mass of PM10
particulates retained on the filter paper to the total volume of air sampled.
8.1.4
The
weighted filter paper was prepared for arsenic testing through a "Hot Acid
Extraction Procedure". The extracted material was tested for arsenic by
using Inductively Coupled Plasma/Mass Spectrometry (ICP/MS). The extraction and
testing were referenced to the following methods:
·
Compendium Method 1O-3.1
Selection, Preparation and Extraction of Filter Material, Center for
Environmental Research Information, Office of Research and Development, USEPA,
June 1999; and Compendium Method 1O-3.5 determination of Metals in Ambient
Particulate Matter using Inductively Coupled Plasma/Mass Spectrometry (ICP/MS.,
Center for Environmental Research Information, Office of Research and
Development, USEPA, June 1999.
8.2.1
Ambient
arsenic monitoring was conducted at the monitoring station(s) under the Work
Contract(s), as shown in Table
8.1
describes the location of the ambient arsenic monitoring station. The location of the
ambient arsenic monitoring station is presented in Figure 8.1.
Table 8.1
Location of Ambient Arsenic Monitoring station
|
Monitoring Station(s)
|
Location(s)
|
Works Contract(s)
|
|
KTN-DMS-4A(1)(2)
|
Temporary Structure at Pak Shek Au
|
ND/2024/01
|
Remarks:
(1) Monitoring at the original
location of KTN-DMS-4 (originally proposed in the approved EM&A Manual) was
denied as there was no electricity supply. An alternative location (KTN-DMS-4A)
was proposed by First Phase ET.
(2)
The ambient
arsenic monitoring was conducted by First Phase ET during the reporting period.
8.3.1
Table 8.2 summarises the
equipment used in the ambient arsenic monitoring. Copies of the calibration
certificates for ambient arsenic monitoring are shown in Appendix 8.1
Table 8.2 Ambient Arsenic Monitoring Equipment
|
Monitoring
Station
|
Equipment
|
Manufacturer
|
Model
|
No. of Equipment
|
|
KTN-DMS-4A(1)(2)
|
Calibrator
|
TISCH
|
TE-5025A
|
1
|
|
HVS Sampler (RSP)
|
TISCH
|
TE-6070X
|
1
|
Remarks:
(1) Monitoring at the original
location of KTN-DMS-4 (originally proposed in the approved EM&A Manual) was
denied as there was no electricity supply. An alternative location (KTN-DMS-4A)
was proposed by First Phase ET.
(2)
The ambient
arsenic monitoring was conducted by First Phase ET during the reporting period.
8.4.1
Table 8.3 summarises the
monitoring parameters and frequencies of ambient arsenic during the clean-up
processes of arsenic-containing soil and construction. The ambient arsenic
monitoring schedule for the reporting month shown in Appendix 2.1.
Table 8.3 Impact Ambient Arsenic Monitoring Parameters, Frequency and Duration
|
Parameters
|
Frequency(1)
|
|
24-hour RSP (Ambient Arsenic)
|
Once/ 6 days
|
Remark:
1.
The ambient
arsenic monitoring was conducted by First Phase ET during the reporting period.
Instrumentation
8.5.1
HVS
(GMW PM10 (TE6070X)) complete with appropriate sampling inlets was employed for
24-hour RSP monitoring. The sampler was composed of a motor, a filter holder, a
flow controller and a sampling inlet and its performance specification complied
with that required by USEPA Standard Title 40, Code of Federation Regulations
Chapter 1 (Part 50).
8.5.2
The
following guidelines were adopted during the installation of HVS:
·
a horizontal platform with
appropriate support to secure the samplers against gusty wind was provided;
·
no two samplers were
placed less than 2 meters apart;
·
the distance between the
sampler and an obstacle, such as buildings, was at least twice the height that
the obstacle protrudes above the sampler;
·
a minimum of 2 meters of
separation from walls, parapets and penthouses was required for rooftop
samplers;
·
a minimum of 2 meters
separation from any supporting structure, measured horizontally was required;
·
no furnace or incinerator
flue was nearby;
·
airflow around the sampler
was unrestricted;
·
the sampler was more than
20 meters from the dripline;
·
any wire fence and gate,
to protect the sampler, were not cause any obstruction during monitoring;
·
permission was obtained to
set up the samplers and to obtain access to the monitoring stations; and
·
a secured supply of
electricity was needed to operate the samplers
Operating/analytical
procedures for the operation of HVS
·
Prior to the commencement of the dust sampling,
the flow rate of the high volume sampler was properly set (between 1.1 m3
/min. and 1.4 m3 /min.) in accordance with the manufacturer's
instruction to within the range recommended in USEPA Standard Title 40, CFR
Part 50;
·
The power supply was checked to ensure the
sampler worked properly. On sampling, the sampler was operated for 5 minutes to
establish thermal equilibrium before placing any filter media at the designated
air monitoring station;
·
The filter holding frame was then removed by
loosening the four nuts and a weighted and conditioned filter was carefully
centered with the stamped number upwards, on a supporting screen;
·
The filter was aligned on
the screen so that the gasket formed an airtight seal on the outer edges of the
filter. The filter holding frame was then tightened to the filter holder with
swing bolts. The applied pressure was sufficient to avoid air leakage at the
edges;
·
The shelter lid was closed
and secured with the aluminium strip;
·
The timer was then
programmed. Information was recorded on the record sheet, which included the
starting time, the weather condition and the filter number (the initial weight
of the filter paper can be found out by using the filter number);
·
After sampling, the filter
was removed and sent to the Wellab Ltd. for weighing. The elapsed time was also
recorded; and
·
Before weighing, all
filters were equilibrated in a conditioning environment for 24 hours. The
conditioning environment temperature was between 25°C and 30°C and did not vary
by more than ±3°C; the relative humidity (RH) was < 50% and did not vary by more
than ±5%. A convenient working RH was 40%. Weighing results were further
analysis of RSP concentrations collected by each filter.
8.6.1
The
following maintenance/calibration was required for the HVS:
·
The high volume motors and
their accessories were properly maintained. Appropriate maintenance such as
routine motor brushes replacement and electrical wiring checking were made to
ensure that the equipment and necessary power supply were in good working
condition; and
·
High volume samplers were
calibrated at bi-monthly intervals using TE-5025A Calibration Kit throughout
all stages of the ambient arsenic monitoring.
8.7.1
Quartz
filters of size 8” x 10” were labelled before sampling. A HOKLAS accredited
laboratory, Wellab Ltd., was responsible for the preparation of 24-hour
conditioned and pre-weighed filter papers for the monitoring team. The balance
for weighting filter paper was regularly calibrated against a traceable
standard.
8.7.2
All
filters, which were prepared and equilibrated in the conditioning environment
for 24 hours before weighing. The conditioning environment temperature was
around 25 °C and not variable by more than ±3 °C; the relative humidity (RH)
was < 50% and not variable by more than ±5%. A convenient working RH was
40%.
8.7.3
Wellab
Ltd. (HOKLAS Registration No. HOKLAS083), was responsible for the extraction
and testing procedure for Arsenic and comprehensive quality assurance and
quality control programmes were conducted.
8.8.1
The
ambient arsenic monitoring results are summarised in Table 8.4.
Table 8.4 Result Summary Against Action and Limit Levels for 24-hour RSP
Monitoring Results (Ambient Arsenic)
|
Contract No.
|
Monitoring
Date
|
Monitoring
Station
|
Concentration
(ƞg/m3)
|
AL
(ƞg/m3)
|
LL
(ƞg/m3)
|
|
ND/2024/01
|
6/4/2026
|
KTN-DMS4A*
|
3.76
|
9.36
|
11.7
|
|
10/4/2026
|
4.76
|
|
16/4/2026
|
3.47
|
|
22/4/2026
|
4.63
|
|
28/4/2026
|
5.46
|
Remark:
* The 24-hour RSP monitoring for ambient
arsenic was conducted by First Phase ET during the reporting period.
8.8.2
All
ambient arsenic monitoring was conducted as scheduled in the reporting month. During
the reporting month, 1,123.58 m3 of arsenic soil transported to soil
treatment plant and treated. No AL or LL exceedances were recorded.
8.9.1
Should
any non-compliance of the criteria occur, actions in accordance with the
Event/Action Plan in Appendix 8.2 shall be carried out.
Works Contract No. ND/2024/01:
· All Site Resumption Area(s)
1. Tree survey
2. Site Clearance
· Portion III (3), IV (4), V (5) and XXXV (35)
1. Site Formation
· Portion VIII (8) , XVI (16), XXXII (31) and LVIII (58)
1. Site Clearance & Demolition
· Portion XVIII (18), XXXVIII (38)
1. Excavation works
2. Construction of CHC Box Culvert
· Portion XI (11),
XXIII (23)
1. Formwork Erection, Rebar Fixing, Concreting Works
2. Erection of Substructure of Metropolis Community Liaison and Visitor
Centre
· Portion XL (40)
1. Retaining Wall Construction
2. Drainages System Construction
3. ELS work
· Portion LIX (59)
1. Treatment of High Arsenic-Containing Soil (HAS)
2. Erection of Shredding Facility
· Portion XVII (17), XVII (18), XXI (21), XXXIV (34), XXXV (35), XLI
(41), XLII (42)
1. Excavation Works
2. Drainage Pipe Installation
3. ELS Works
· Portion XXV (25), XXVII (27), XXXIII (33), XLII (42) and XLIV (44)
1. Site Clearance
2. Site Formation
3.
Construction of Box Culvert
Works Contract No. ND/2024/02:
1. Site clearance in Area A, B, C, D, T, L
2. Site formation works in Area D
3. Temporary storage fill bank in Kwu Tung Grass
Soccer Pitch
4. Demolition works for Community Sports in Area
J
5. Ground Investigation Works in Area B & L
6. Asbestos Removal Works in Area C
Works Contract No. ND/2024/03:
Fanling
Highway & Castle Peak Road area
· Pak Sau Road – Po Lau Road
1. Tree Works
2. Relocation/Reprovision/Removal of Existing TCSS, Fire Hydrant,
Signage & Streetlighting
· Po Lau Road – Sheung Yue River
1. Asbestos Removal Works at Portion IX
2. Box Culvert Bay 37 – Bay 42 ELS
· TTA Stage 1 Works
1. Tree Works
2. Removal or relocation of directly impacted Shrine/historical
building at HKT08 & KT72
3. Demolish of Central Divider & Barrier along FL Highway E/B
New Tsung Pak
Long Road
· Box culvert Bay 10 to 12, 14 to 16 Drainage/Watermains
1. Drainage, Sewerage & Watermain with Backfilling at Box Culvert
Bay 15 & 16
2. Box Culvert Bay 10-13 & 14 ELS
3. Removal of ELS and Temp Road Diversion
· Box culvert Bay 17 to 19 & Drainage/Watermains
1. Box Culvert Bay 17 to 19 ELS, Base Slab, Wall and Top Slab
· TTA Stage 1B
1. Box Culvert Bay 3, 5 to 7, 7A ELS
2. Box Culvert Base Slab
· Retaining Wall RW05A
1. RW05A ELS
2. Base Slab and Wall
· Kwu Tung Road Bridge
1. Site Clearance and Tree Works
2. Site formation and cutback the existing slope
3. Foundation & Piling
· Works Areas – WA1, WA2, WA3, WA4 & WA5
1. Temporary Drainage
2. Asbestos removal
Fanling Highway
Cross River Bridge (along Sheung Yue River)
· Portion XI – East Abutment & pier foundation (No works at wet season between 1 Apr 2026 and 31 Oct 2026)
1. Trial Pits for UUs
2. Piling Works
· Road L3 Viaduct
1. Piling Works
2. Pile Cap L3A-02
Kwu Tung
Interchange Foundation & Substructure
· Bridge B1 & C1
1. Piling Works
2. ELS
· Bridge B2 & C2
1. Piling Work
· Footbridges No. 4 at TTA Stage 1
1. Ground Investigation
2. Underground Utilities Works
3. Piling
· Footbridges No. 5 at TTA Stage 2
1. Predrilling
· Widening of Existing Bridge No.N526
1. Tree Works
2.
Pilling
Works Contract No. ND/2024/04:
1. Site Clearance
2. Site Establishment
3. Tree Felling
4. Trial Pit
5. Existing Sewage Diversion
6.
Haul Road Construction
7. Bored Piling
8. ELS Construction
9. Slope Works
10.Road Diversion Works
11.Demolition of Existing Structures
Works Contract No. ND/2024/06:
· Portion A
1. Excavation to +84 mPD of Portion A
2. Carry of Soil Nail of Portion A
· Portion C, D, E & F
1. Trench and Watermans Laying Works
· Area N
1. Jacking Pit Excavation
· Pre-boring of Pit B & C
Works Contract No. ND/2024/07:
1. Site Clearance
2. Site Formation
3. Ground Investigation
4. Pre-bored Socketed H Pile
Construction
5. Bridge Construction
6. Bridge Deck Connection (Footbridge
FB5)
7. Lift Tower Construction
8. Sump Pit Construction
9. ABWF Works
10. Drainage Construction
11. Improvement of Junction
12. Road Construction
13. Temporary Road Construction
14. Open Landscaping Works
15. Tree Felling & Transplantation
16. Asbestos Containing Materials Survey &
Removal
17. Land Contamination (Environmental Ground
Investigation)
18. Internal Movement, Importation & Exportation of
C&D materials
19. Sewerage Construction
20. Old Shrine Removal and New Shrine Construction
21. Storm pipe Construction
22. Box Culvert Construction
23. Temporary Drainage Diversion
24. Rebar yard
25. Storage Yard for Concrete Pipe
Works Contract No. ND/2024/05 and No. ND/2024/08:
1. The construction work has not commenced in the
reporting month.
13.1.2 Potential environmental
impacts arising from the above construction activities are mainly associated
with construction noise impact, water quality impact, ecological impact, waste
management, and landscape and visual.
Dust
•
Regular watering to reduce dust emissions from
exposed site surface;
•
Stockpile of dusty materials shall be covered
entirely by impervious sheeting;
•
Provide vehicles washing facilities at all site
exits to wash away any dusty materials from vehicle body;
•
NRMM Labels should be displayed on the
applicable equipment on site by the Contractor;
•
Provision of water sprinklers along the haul
road for dust suppression.
Noise
•
Only well-maintained plant should be operated
on-site, and plant should be maintained regularly during the construction
programme; and
•
Quality Powered Mechanical Equipment (QPME)
should be adopted as far as possible.
Water Quality
•
No effluent discharge would be allowed before
acquired the effluent discharge license;
•
Surface run-off from construction sites should
be discharged into dedicated discharge point via adequately designed sand/ silt
removal facilities;
•
Channels/ earth bunds/ sandbags barriers should
be provided on site to properly direct stormwater to silt removal facilities;
•
Silt removal facilities, channels and manholes
should be maintained, and the deposited silt and grit should be removed
regularly;
•
Open stockpiles of construction materials on
sites should be covered with tarpaulin or similar fabric during rainstorms; and
•
Perimeter channels should be provided on site
boundaries where necessary to intercept stormwater run-off from outside the
site so that it will not wash across the site.
Waste Management
•
Provision of sufficient waste disposal points
and regular collection of waste;
•
Regular cleaning and maintenance programme for
drainage system; and
•
Chemical containers shall be stored with drip
tray underneath.
Landscape and Visual
•
Construction activities shall be carefully
designed to minimize impact on existing retained trees.
Land Contamination
•
Stockpiling site(s) should be lined with
impermeable sheeting and bunded. Stockpiles should be properly covered by
impermeable sheeting to reduce dust emission during dry season or contaminated
run-off during rainy season. Watering should be avoided on stockpiles of soil
to minimise runoff.
Landfill Gas Hazard
•
“No Smoking” and “No Naked Flame” notices in
Chinese and English should be posted prominently around the construction site.
Ecology
•
Properly erect and maintain 2m high solid
barriers for protection.
•
An individual of orchid Eulophia cernua was found growing
underneath the pipeline adjacent to the access road leading to the summit of
the Table Hill Freshwater Service Reservoir for Contract No. ND/2024/06. The
species of conservation importance should be fenced off for protection to minimise
the potential impacts aroused from nearby construction activities as far as
possible.
14.1.1
This is
the 16th Monthly EM&A Report summarizing the findings of
EM&A works at Works Contract No. ND/2024/01, Works Contract No. ND/2024/02, Works
Contract No. ND/2024/03, Works Contract No. ND/2024/04, Works Contract No.
ND/2024/06 and Works Contract No. ND/2024/07 during the reporting month, this
report documents the findings of EM&A works at Works Contract No.
ND/2024/01, Works Contract No. ND/2024/02, Works Contract No. ND/2024/03, Works
Contract No. ND/2024/04, Works Contract No. ND/2024/06 and Works Contract No.
ND/2024/07 under the Project during the reporting period only. No construction
works occurred in the remaining contracts during the reporting period for Works
Contract ND/2024/05 and ND/2024/08.
14.1.2 All air quality
monitoring was conducted as scheduled in the report period. No Action Level or
Limit Level exceedance was recorded for air quality monitoring in the reporting
period.
14.1.3 All construction noise
monitoring was conducted as scheduled in the report period. Three Action Level
exceedances for construction noise were recorded during the reporting month,
corresponding to three noise-related complaints received. No Limit Level
exceedance was recorded for construction noise monitoring in the reporting
period.
14.1.4 All ambient arsenic
monitoring was conducted as scheduled in the reporting period. No Action or Limit Level
exceedance was recorded during ambient arsenic monitoring in the reporting
period.
14.1.5 All ecological
monitoring was conducted as scheduled in the reporting period. No Action or Limit Level
exceedance was recorded during ecological monitoring in the reporting period.
14.1.6 No exceedance of limits
was recorded for built
heritage monitoring (vibration monitoring) in the reporting period.
14.1.7
Environmental
site inspections were conducted at Works Contract No. ND/2024/01 on 2, 9, 16, 21 and 28
April 2026. For Works Contact No. ND/2024/02 were carried out on 2 ,9, 17, 21,
28 April 2026. For Works Contact No. ND/2024/03 were carried out on 8, 15, 20
and 27 April 2026. For Works Contact No. ND/2024/04 were carried out on 2, 10,
17, 24 and 30 April 2026. For Works Contact No. ND/2024/06 were carried out on
9, 15, 21 and 28 April 2026. For Works Contract No. ND/2024/07 were carried out
on 2, 9, 16, 23 and 30 April 2026.
_R3_files/image001.jpg)
_R3_files/image002.jpg)
_R3_files/image003.png)
_R3_files/image004.png)
_R3_files/image005.png)
